VT1697SCFQR Half Bridge Driver - Equivalent & Substitute Parts

Part Overview

The VT1697SCFQR is a half bridge driver IC designed for general purpose power MOSFET applications. It operates as a PWM-controlled driver for inductive loads with integrated fault protection including current limiting, over-temperature shutdown, short circuit protection, and under-voltage lockout (UVLO). The device is packaged in a 16-pin FCQFN form factor (6x3.75mm).

The VT1697SCFQR is classified as obsolete. Identifying equivalent substitute parts is necessary to ensure design continuity, maintain supply chain reliability, and support long-term product availability for applications currently utilizing this component.

Substiute Parts

VT1697SCFQR

Analog Devices Inc./Maxim IntegratedIn Stock: 786VT1697SCFQR Datasheet

Current PartRFQ

VT1697SCFQX

Analog Devices Inc./Maxim IntegratedIn Stock: 2024VT1697SCFQX Datasheet

MFR RecommendedRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution of the VT1697SCFQR is determined by strict equivalence across the following critical parameters:

• Output Configuration: Half Bridge topology
• Peak Output Current: 55A
• Supply Voltage Range: 1.71V ~ 1.98V
• Load Voltage Range: 8.5V ~ 14V
• Operating Temperature Range: -40°C ~ 125°C (TJ)
• Package Type: 16-FCQFN (6x3.75mm)
• Fault Protection Features: Current Limiting, Over Temperature, Short Circuit, UVLO
• Interface: PWM control

The VT1697SCFQX meets all these criteria and is manufactured by the same supplier (Analog Devices Inc./Maxim Integrated) with identical electrical and mechanical specifications. The primary distinction is product status: VT1697SCFQX is active production, whereas VT1697SCFQR is obsolete.

Parameter Comparison

Engineering Selection Recommendations

The VT1697SCFQX is the direct equivalent substitute for the VT1697SCFQR. Both parts are manufactured by Analog Devices Inc./Maxim Integrated and share identical electrical specifications, fault protection architecture, and physical packaging.

The VT1697SCFQX is preferred for new designs and ongoing production due to its active product status. For existing applications currently using the VT1697SCFQR, migration to the VT1697SCFQX provides continuity of supply and maintains full functional compatibility.

Both parts maintain ROHS3 compliance and unlimited moisture sensitivity rating (MSL 1), ensuring compatibility with standard manufacturing and storage protocols.

Frequently Asked Questions (FAQ)

Q: Can the VT1697SCFQX be used as a direct replacement for the VT1697SCFQR?

A: Yes. The VT1697SCFQX is electrically and mechanically identical to the VT1697SCFQR. All electrical parameters, fault protection features, and package specifications are equivalent. No circuit modifications are required.

Q: What is the primary difference between these two part numbers?

A: The VT1697SCFQR is obsolete, while the VT1697SCFQX is in active production. The electrical and mechanical specifications are identical.

Q: Are there any package compatibility concerns?

A: No. Both parts use the 16-FCQFN (6x3.75mm) package. PCB footprints, solder reflow profiles, and handling procedures are identical.

Q: Do both parts meet the same compliance standards?

A: Yes. Both the VT1697SCFQR and VT1697SCFQX are ROHS3 compliant with MSL 1 (unlimited moisture sensitivity). Compliance documentation is equivalent.

Q: What are the critical parameters that define substitution eligibility?

A: Substitution is determined by matching output configuration (half bridge), peak output current (55A), supply voltage range (1.71V ~ 1.98V), load voltage range (8.5V ~ 14V), operating temperature range (-40°C ~ 125°C), package type (16-FCQFN 6x3.75mm), and fault protection features (current limiting, over temperature, short circuit, UVLO).
