USB-B-S-S-W-VT-R Equivalent & Substitute Parts
Part Overview
The USB-B-S-S-W-VT-R is a USB 2.0 Type-A receptacle connector manufactured by Samtec Inc., designed for through-hole vertical mounting applications. This 4-position shielded connector features solder termination with board lock functionality and operates across the temperature range of -50°C to 85°C. The part is currently active in production with 922 units in stock.
Equivalent and substitute parts are identified when design requirements permit component interchange based on matching electrical specifications, mechanical form factors, and performance ratings. This reference provides engineering teams with validated alternatives from multiple manufacturers for procurement flexibility, supply chain optimization, and design standardization.
Substiute Parts
Key Parameters
| Parameter | Specification |
|---|---|
| Connector Type | USB-A (USB TYPE-A) |
| Number of Contacts | 4 |
| Gender | Receptacle |
| USB Specification | USB 2.0 |
| Mounting Type | Through Hole |
| Mounting Feature | Vertical |
| Termination | Solder |
| Shielding | Shielded |
| Contact Finish | Gold |
| Voltage Rating | 30VAC |
| Operating Temperature | -50°C to 85°C |
| Material Flammability | UL94 V-0 |
| Features | Board Lock |
Substitute Part Grouping Explanation
Substitution eligibility for USB 2.0 Type-A receptacle connectors is determined by strict alignment of the following parameters:
Primary Substitution Criteria:
- Connector Type: USB-A (USB TYPE-A)
- Number of Contacts: 4 positions
- Gender: Receptacle
- USB Specification: USB 2.0
- Mounting Type: Through Hole
- Mounting Feature: Vertical
- Termination: Solder
- Shielding: Shielded
- Contact Finish: Gold
- Voltage Rating: 30VAC minimum
- Material Flammability Rating: UL94 V-0
Secondary Compatibility Factors:
- Operating Temperature Range: Minimum -40°C to 85°C (main part: -50°C to 85°C)
- Mating Cycles: 1500 cycles (where specified)
- Board Lock Feature: Present on all qualified substitutes
All substitute parts listed below meet or exceed these core parameters. Variations in shell/shielding material (phosphor bronze, steel stainless, brass, copper alloy) and insulation color do not affect electrical or mechanical compatibility within the USB 2.0 Type-A receptacle category.
Parameter Comparison
| Manufacturer Part Number | Manufacturer | Connector Type | Contacts | USB Spec | Mounting | Voltage | Operating Temp | Mating Cycles | Shell Material | Insulation Color |
|---|---|---|---|---|---|---|---|---|---|---|
| USB-B-S-S-W-VT-R | Samtec Inc. | USB-A | 4 | USB 2.0 | Through Hole Vertical | 30VAC | -50°C to 85°C | 1500 | Phosphor Bronze | White |
| USB-B-S-S-B-VT | Samtec Inc. | USB-A | 4 | USB 2.0 | Through Hole Vertical | 30VAC | -50°C to 85°C | 1500 | Phosphor Bronze | Black |
| USB-B-S-S-W-VT | Samtec Inc. | USB-A | 4 | USB 2.0 | Through Hole Vertical | 30VAC | -50°C to 85°C | 1500 | Phosphor Bronze | White |
| 1050570001 | Molex | USB-A | 4 | USB 2.0 | Through Hole Vertical | 30VAC | -40°C to 85°C | Not Specified | Steel, Stainless | Black |
| 1734366-1 | TE Connectivity AMP Connectors | USB-A | 4 | USB 2.0 | Through Hole Vertical | 30VAC | -40°C to 85°C | 1500 | Brass | Black |
| 1734366-2 | TE Connectivity AMP Connectors | USB-A | 4 | USB 2.0 | Through Hole Vertical | 30VAC | -40°C to 85°C | 1500 | Brass | White |
| 1734366-3 | TE Connectivity AMP Connectors | USB-A | 4 | USB 2.0 | Through Hole Vertical | 30VAC | -40°C to 85°C | 1500 | Brass | Blue |
| 1734366-4 | TE Connectivity AMP Connectors | USB-A | 4 | USB 2.0 | Through Hole Vertical | 30VAC | -40°C to 85°C | 1500 | Brass | Black |
| 614004135023 | Würth Elektronik | USB-A | 4 | USB 2.0 | Through Hole Vertical | 30VAC | -40°C to 105°C | 1500 | Brass | White |
| 6140041350231 | Würth Elektronik | USB-A | 4 | USB 2.0 | Through Hole Vertical | 30V | -40°C to 105°C | 1500 | Brass | Black |
| KUSBVX-AS1N-B | Kycon, Inc. | USB-A | 4 | USB 2.0 | Through Hole Vertical | 30VAC | -55°C to 85°C | 1500 | Copper Alloy | Black |
Engineering Selection Recommendations
Samtec Inc. Alternatives (USB-B-S-S-B-VT, USB-B-S-S-W-VT): These parts are direct parametric equivalents to the USB-B-S-S-W-VT-R, differing only in insulation color. Both are ROHS3 Compliant with MSL 1 (Unlimited) and REACH Unaffected status. The USB-B-S-S-B-VT offers higher inventory availability (4166 units) compared to the main part (922 units).
Molex 1050570001: This connector meets all core electrical and mechanical requirements with ROHS3 Compliance and MSL 1 rating. Operating temperature range is -40°C to 85°C, which is narrower than the main part by 10°C at the lower limit. Current rating is specified at 1.5A. Mating cycle data is not provided.
TE Connectivity 1734366 Series (1734366-1, 1734366-2, 1734366-3, 1734366-4): All variants in this series are parametrically equivalent with 1A current rating and 1500 mating cycles. Operating temperature range is -40°C to 85°C. Variants differ by insulation color (black, white, blue). ROHS3 Compliance and MSL 1 rating apply to variants 1, 2, and 4. Variant 1734366-3 shows RoHS Compliant status with Vendor Undefined REACH status.
Würth Elektronik 614004135023 and 6140041350231: Both parts feature extended operating temperature range to 105°C and 1.5A current rating. ROHS3 Compliant with MSL 1 and REACH Unaffected. Part 614004135023 specifies 30VAC; part 6140041350231 specifies 30V. Both support 1500 mating cycles.
Kycon KUSBVX-AS1N-B: This connector provides the widest operating temperature range (-55°C to 85°C), exceeding the main part specification. Current rating is 1A with 1500 mating cycles. ROHS3 Compliant, MSL 1, and REACH Unaffected. Copper alloy shell material provides alternative shielding construction.
All listed substitutes carry UL94 V-0 flammability rating and board lock features consistent with the main part specification.
Frequently Asked Questions (FAQ)
Q: Can USB-B-S-S-W-VT-R be directly replaced with USB-B-S-S-B-VT?
A: Yes. Both parts are manufactured by Samtec Inc. with identical electrical specifications, mechanical form factors, and performance ratings. The only difference is insulation color (white versus black), which does not affect electrical or mechanical compatibility. Both are ROHS3 Compliant with MSL 1 (Unlimited).
Q: What is the significance of the operating temperature range difference between the main part (-50°C to 85°C) and most substitutes (-40°C to 85°C)?
A: The main part USB-B-S-S-W-VT-R operates 10°C lower at the minimum temperature. If your application requires operation below -40°C, only the main part, Würth Elektronik alternatives (to -40°C), or Kycon KUSBVX-AS1N-B (to -55°C) are suitable. For applications within -40°C to 85°C, all listed substitutes are acceptable.
Q: Are there differences in current handling capability among the substitutes?
A: Yes. The main part USB-B-S-S-W-VT-R does not specify a current rating. Molex 1050570001 and Würth Elektronik parts (614004135023, 6140041350231) are rated at 1.5A. TE Connectivity 1734366 series and Kycon KUSBVX-AS1N-B are rated at 1A. For applications requiring 1.5A continuous current, select Molex or Würth Elektronik alternatives.
Q: What shell material options are available among the substitutes?
A: The main part uses phosphor bronze. Substitutes employ phosphor bronze (Samtec alternatives), steel stainless (Molex 1050570001), brass (TE Connectivity 1734366 series, Würth Elektronik), or copper alloy (Kycon KUSBVX-AS1N-B). All materials provide equivalent shielding performance for USB 2.0 applications.
Q: Do all substitutes support the same number of mating cycles?
A: Most substitutes support 1500 mating cycles, matching the main part specification. Molex 1050570001 does not specify mating cycle data. For applications requiring documented 1500-cycle rating, avoid the Molex part.
Q: Which substitute offers the best inventory availability?
A: TE Connectivity 1734366-2 has the highest inventory at 58,505 units. Kycon KUSBVX-AS1N-B follows with 14,661 units. Samtec USB-B-S-S-B-VT has 4,166 units. For immediate procurement needs, these three options provide the strongest supply position.
Q: Are all substitutes RoHS and REACH compliant?
A: Most substitutes are ROHS3 Compliant with REACH Unaffected status. TE Connectivity 1734366-3 shows RoHS Compliant (not ROHS3) with Vendor Undefined REACH status. For applications requiring ROHS3 Compliance and confirmed REACH status, verify part-specific documentation or select alternatives with explicit ROHS3 and REACH Unaffected designations.
Q: Can insulation color be used as a selection criterion for substitution?
A: Insulation color is a visual identifier only and does not affect electrical or mechanical performance. Selection by color is permitted for design documentation, assembly traceability, or visual circuit board identification. All color variants (white, black, blue) within each manufacturer series are functionally equivalent.
