TSM-150-01-L-DV Equivalent & Substitute Parts

Part Overview

The TSM-150-01-L-DV is a surface mount rectangular connector header manufactured by Samtec Inc., featuring 100 positions arranged in 2 rows with 0.100" (2.54mm) pitch. This cuttable header connector is designed for board-to-board or cable applications with solder termination and push-pull fastening. The part is Active status and ROHS3 compliant, making it suitable for modern electronic assemblies requiring reliable interconnection solutions.

Substitute parts are identified when electrical and mechanical parameters remain identical across the connector series, ensuring direct functional equivalence in circuit design and PCB layout applications.

Substiute Parts

TSM-150-01-L-DV

Samtec Inc.In Stock: 1109TSM-150-01-L-DV Datasheet

Current PartRFQ

TSM-150-01-L-DV-P

Samtec Inc.In Stock: 2659TSM-150-01-L-DV-P Datasheet

SimilarRFQ

TSM-150-01-L-DV-A

Samtec Inc.In Stock: 990TSM-150-01-L-DV-A Datasheet

SimilarRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitute parts for the TSM-150-01-L-DV are identified based on strict equivalence of the following critical parameters:

• Connector Type: Header, Cuttable
• Contact Type: Male Pin
• Number of Positions: 100
• Number of Rows: 2
• Pitch - Mating: 0.100" (2.54mm)
• Row Spacing - Mating: 0.100" (2.54mm)
• Mounting Type: Surface Mount
• Termination: Solder
• Fastening Type: Push-Pull
• Contact Length - Mating: 0.230" (5.84mm)
• Insulation Height: 0.100" (2.54mm)
• Contact Shape: Square
• Contact Finish - Mating: Gold
• Contact Material: Phosphor Bronze
• Insulation Material: Liquid Crystal Polymer (LCP)
• Operating Temperature: -55°C ~ 125°C
• Material Flammability Rating: UL94 V-0
• Product Status: Active
• RoHS Status: ROHS3 Compliant

The identified substitutes differ only in optional features (Pick and Place capability or Board Guide) that do not affect core electrical or mechanical compatibility. All substitute parts maintain identical mating characteristics, contact geometry, and environmental specifications.

Parameter Comparison

Engineering Selection Recommendations

All three parts—TSM-150-01-L-DV, TSM-150-01-L-DV-P, and TSM-150-01-L-DV-A—are Active status products manufactured by Samtec Inc. and maintain full ROHS3 compliance with UL94 V-0 flammability certification. They are electrically and mechanically interchangeable for applications requiring a 100-position, 2-row surface mount header connector with 0.100" (2.54mm) pitch.

Selection between these parts depends on assembly process requirements:

• TSM-150-01-L-DV: Standard configuration for general board-to-board or cable interconnection applications.
• TSM-150-01-L-DV-P: Includes Pick and Place feature for automated assembly processes requiring enhanced handling characteristics.
• TSM-150-01-L-DV-A: Includes Board Guide feature for applications requiring mechanical alignment assistance during mating operations.

All parts share identical electrical performance, environmental ratings, and contact specifications. Inventory availability varies across the three options.

Frequently Asked Questions (FAQ)

Q: Are TSM-150-01-L-DV, TSM-150-01-L-DV-P, and TSM-150-01-L-DV-A electrically interchangeable?

A: Yes. All three parts maintain identical contact geometry, mating pitch, contact material, and finish specifications. They are electrically equivalent and can be substituted without circuit redesign.

Q: What is the difference between the standard TSM-150-01-L-DV and the TSM-150-01-L-DV-P variant?

A: The TSM-150-01-L-DV-P includes Pick and Place capability, which provides enhanced handling characteristics for automated assembly equipment. The core connector specifications remain identical.

Q: What is the Board Guide feature on the TSM-150-01-L-DV-A?

A: The Board Guide feature provides mechanical alignment assistance during mating operations. This does not affect electrical performance but improves mechanical positioning in applications requiring precise connector alignment.

Q: Can these connectors be used in high-temperature applications?

A: Yes. All three parts are rated for operating temperatures from -55°C to 125°C, making them suitable for industrial and automotive applications within this temperature range.

Q: Are all three parts RoHS compliant?

A: Yes. TSM-150-01-L-DV, TSM-150-01-L-DV-P, and TSM-150-01-L-DV-A are all ROHS3 compliant and meet modern environmental regulations for electronic component manufacturing.

Q: What is the moisture sensitivity level for these connectors?

A: All three parts have a Moisture Sensitivity Level (MSL) of 1 (Unlimited), indicating no moisture sensitivity restrictions for storage or handling.

Q: Can these connectors be cut to shorter lengths?

A: Yes. All three parts are classified as cuttable headers, allowing customization to shorter position counts for specific application requirements.
