TFM-130-02-L-D Equivalent & Substitute Parts

Part Overview

The TFM-130-02-L-D is a surface mount rectangular connector header manufactured by Samtec Inc. as part of the Tiger Eye™ TFM series. This 60-position, dual-row connector operates at 0.050" (1.27mm) pitch and is designed for board-to-board or cable applications with push-pull fastening. The part is active in production status with full inventory availability (870 pcs in stock). Equivalent and substitute parts are identified to support design flexibility, supply chain continuity, and application-specific feature requirements while maintaining electrical and mechanical compatibility.

Substiute Parts

TFM-130-02-L-D

Samtec Inc.In Stock: 962TFM-130-02-L-D Datasheet

Current PartRFQ

TFM-130-02-L-D-DS

Samtec Inc.In Stock: 1232TFM-130-02-L-D-DS Datasheet

SimilarRFQ

TFM-130-02-L-D-LC

Samtec Inc.In Stock: 1127TFM-130-02-L-D-LC Datasheet

SimilarRFQ

TFM-130-02-L-D-WT

Samtec Inc.In Stock: 1166TFM-130-02-L-D-WT Datasheet

SimilarRFQ

TFM-130-02-L-D-WT-K

Samtec Inc.In Stock: 1225TFM-130-02-L-D-WT-K Datasheet

SimilarRFQ

TFM-130-02-L-D-A

Samtec Inc.In Stock: 834TFM-130-02-L-D-A Datasheet

SimilarRFQ

Key Parameters

Substitute Part Grouping Explanation

All substitute parts for the TFM-130-02-L-D maintain identical core electrical and mechanical specifications: 60-position, dual-row header with 0.050" (1.27mm) pitch, surface mount solder termination, push-pull fastening, and shrouded 4-wall design. Substitution is determined by feature differentiation rather than performance variation. The following features distinguish substitute variants:

Feature-Based Grouping:

• TFM-130-02-L-D-DS: Mating Flange feature
• TFM-130-02-L-D-LC: Board Lock feature
• TFM-130-02-L-D-WT: Solder Retention feature
• TFM-130-02-L-D-WT-K: Pick and Place and Solder Retention features
• TFM-130-02-L-D-A: Board Guide feature

All substitute parts share the same base product number (TFM-130), series designation, contact configuration, electrical ratings, temperature range, compliance certifications, and packaging specifications as the primary part.

Parameter Comparison

Engineering Selection Recommendations

All substitute parts are active production items manufactured by Samtec Inc. and maintain full compliance with ROHS3 and UL94 V-0 flammability standards. Selection between the primary part and substitutes is based on application-specific feature requirements:

TFM-130-02-L-D-DS (Mating Flange): Select when mechanical alignment and strain relief at the mating interface are required.

TFM-130-02-L-D-LC (Board Lock): Select when positive mechanical retention and prevention of accidental disconnection during operation are design requirements.

TFM-130-02-L-D-WT (Solder Retention): Select when enhanced solder joint reliability and prevention of component shift during reflow processing are necessary.

TFM-130-02-L-D-WT-K (Pick and Place, Solder Retention): Select for automated assembly environments requiring both pick-and-place compatibility and solder retention during thermal processing.

TFM-130-02-L-D-A (Board Guide): Select when guided insertion and alignment during mating operations are required.

All parts share identical electrical performance, thermal ratings, contact specifications, and compliance certifications. Inventory availability is consistent across all variants, with TFM-130-02-L-D-WT-K offering the highest stock level (1187 pcs).
