T3P22MC1LZ Equivalent & Substitute Parts Reference

Part Overview

The T3P22MC1LZ is a machined pin contact manufactured by ITT Cannon, LLC, designed for crimp termination applications with 22 AWG wire. This component is part of the Trident T3P series and features gold plating on brass substrate. The part maintains active product status with RoHS compliance and unlimited moisture sensitivity rating (MSL 1). Substitute parts are identified to provide alternative sourcing options when the primary part is unavailable or when inventory requirements necessitate alternative suppliers.

Substiute Parts

T3P22MC1LZ

ITT Cannon, LLCIn Stock: 853T3P22MC1LZ Datasheet

Current PartRFQ

MP20M23F

Amphenol Sine Systems CorpIn Stock: 13932MP20M23F Datasheet

SimilarRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution eligibility for the T3P22MC1LZ is determined by the following critical parameters:

Wire Gauge Compatibility: The main part accommodates 22 AWG wire. Substitute parts must support 22 AWG within their specified wire gauge range. The MP20M23F accepts 20-22 AWG (0.34 ~ 0.5mm²), which includes 22 AWG compatibility.

Contact Termination Method: Both the main part and substitute must use crimp termination to ensure compatibility with existing assembly processes and tooling.

Contact Finish: Gold plating is required for both parts to maintain electrical performance and corrosion resistance in the intended application.

Contact Type: Both parts are pin contacts, ensuring mechanical and electrical compatibility within connector assemblies.

Compliance Standards: RoHS compliance is maintained across both parts. The substitute part meets ROHS3 compliance, which supersedes earlier RoHS requirements.

Moisture Sensitivity: Both parts carry MSL 1 rating, indicating unlimited shelf life and no special moisture control requirements during storage or handling.

Parameter Comparison

Engineering Selection Recommendations

Primary Part Selection: The T3P22MC1LZ remains the specified component for applications requiring Trident T3P series integration. This part is active in production with confirmed inventory availability (821 pcs in stock).

Substitute Part Consideration: The MP20M23F from Amphenol Sine Systems Corp is qualified as a substitute based on matching electrical and mechanical parameters. This part is also active in production with higher inventory availability (13,873 pcs in stock).

Compliance Alignment: Both parts maintain equivalent compliance status. The T3P22MC1LZ carries RoHS Compliant certification, while the MP20M23F carries ROHS3 Compliant certification. ROHS3 represents current regulatory requirements and supersedes earlier RoHS standards. Both parts are classified under identical ECCN (EAR99) and HTSUS (8536.90.4000) codes, indicating equivalent export and tariff classification.

Moisture and Environmental Conditions: Both parts carry MSL 1 rating, eliminating moisture sensitivity as a differentiation factor. No special storage or handling protocols are required for either part.

Material Consideration: The main part uses brass substrate with gold flash finish, while the substitute uses copper alloy substrate with gold flash finish. Both material compositions support the specified crimp termination and gold plating requirements for the 22 AWG wire gauge application.

Frequently Asked Questions (FAQ)

Q: Can MP20M23F replace T3P22MC1LZ in existing assemblies?

A: The MP20M23F is electrically and mechanically compatible with T3P22MC1LZ based on matching wire gauge (22 AWG within the 20-22 AWG range), crimp termination, gold finish, and MSL 1 rating. However, physical compatibility depends on connector housing design. The MP20M23F is specified for circular connector applications (ecomate® Aquarius™ series), while T3P22MC1LZ is part of the Trident T3P series. Verify mechanical fit within the intended connector housing before substitution.

Q: What is the significance of the wire gauge range difference?

A: The T3P22MC1LZ is specified for 22 AWG wire exclusively. The MP20M23F accommodates a range of 20-22 AWG (0.34 ~ 0.5mm²). For 22 AWG applications, the MP20M23F operates within its specified range and is therefore compatible. The broader range of the substitute part does not compromise performance at 22 AWG.

Q: Are there differences in contact material between these parts?

A: The T3P22MC1LZ uses brass substrate, while MP20M23F uses copper alloy substrate. Both materials are compatible with gold flash plating and crimp termination processes. The material difference does not affect electrical performance or compliance status for this application category.

Q: Do both parts have identical compliance certifications?

A: Both parts are RoHS compliant. T3P22MC1LZ carries RoHS Compliant status, while MP20M23F carries ROHS3 Compliant status. ROHS3 represents the current regulatory standard. Both parts share identical ECCN (EAR99) and HTSUS (8536.90.4000) classifications. The MP20M23F also carries REACH Unaffected status, indicating no REACH substance restrictions.

Q: What inventory considerations apply to these parts?

A: T3P22MC1LZ has 821 pcs available in stock. MP20M23F has 13,873 pcs available in stock. The substitute part offers significantly higher inventory availability, which may be relevant for high-volume production requirements or extended lead time mitigation.

Q: Is the MSL rating identical for both parts?

A: Both parts carry MSL 1 (Unlimited) rating. This indicates unlimited shelf life with no moisture sensitivity concerns. No special desiccant packaging, baking procedures, or moisture control measures are required for either part during storage or handling.

Q: Can these parts be used interchangeably in new designs?

A: Electrical and mechanical compatibility is established based on the provided parameters. However, design decisions should account for series-specific connector housing compatibility. T3P22MC1LZ integrates with Trident T3P series housings, while MP20M23F integrates with ecomate® Aquarius™ series housings. Select the part that matches your connector housing specification.
