SPHD-002T-P0.5 Equivalent & Substitute Parts

Part Overview

The SPHD-002T-P0.5 is a socket contact connector manufactured by JST Sales America Inc., designed for 24-28 AWG wire gauges with crimp termination and tin contact finish. This component belongs to the PHD series of rectangular connectors and is classified as Active product status. Substitute parts are identified when equivalent electrical and mechanical parameters align with the original specification, enabling component interchangeability in applications where the primary part becomes unavailable or inventory constraints require alternative sourcing.

Substiute Parts

SPHD-002T-P0.5

JST Sales America Inc.In Stock: 15425SPHD-002T-P0.5 Datasheet

Current PartRFQ

1470106-1

TE Connectivity AMP ConnectorsIn Stock: 42841470106-1 Datasheet

SimilarRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution eligibility for the SPHD-002T-P0.5 is determined by the following critical parameters:

• Contact Type: Socket configuration required
• Termination Method: Crimp termination only
• Wire Gauge Compatibility: 24-28 AWG (substitute must support this range or broader range encompassing 24-28 AWG)
• Contact Finish: Tin plating required
• Connector Category: Rectangular connectors
• Compliance Requirements: ROHS3 Compliant, REACH Unaffected, MSL 1

The substitute part 1470106-1 (TE Connectivity AMP Connectors) meets these criteria with a wire gauge range of 22-28 AWG, which encompasses the original specification of 24-28 AWG, and maintains identical contact termination, finish, and compliance certifications.

Parameter Comparison

Engineering Selection Recommendations

Both the SPHD-002T-P0.5 and 1470106-1 maintain Active product status, ensuring continued manufacturer support and availability. Both components satisfy ROHS3 compliance and REACH unaffected requirements, making them suitable for regulated applications. The substitute part 1470106-1 provides a broader wire gauge range (22-28 AWG versus 24-28 AWG), which does not compromise compatibility with the original specification. Selection between these parts should be based on inventory availability, lead time requirements, and established supplier relationships, as all critical electrical and mechanical parameters align.

Frequently Asked Questions (FAQ)

Q: Can 1470106-1 replace SPHD-002T-P0.5 in existing designs?

A: Yes. Both parts are socket contacts with crimp termination, tin finish, and identical compliance certifications. The substitute part supports the original 24-28 AWG range within its broader 22-28 AWG specification.

Q: What is the significance of the wire gauge range difference?

A: The SPHD-002T-P0.5 specifies 24-28 AWG, while 1470106-1 specifies 22-28 AWG. The substitute's broader range encompasses the original specification, ensuring compatibility with all wire gauges supported by the primary part.

Q: Are there packaging differences between these parts?

A: Both parts are supplied in Cut Tape (CT) packaging, ensuring identical handling and storage requirements.

Q: Do compliance certifications differ?

A: No. Both parts are ROHS3 Compliant, REACH Unaffected, and classified as Moisture Sensitivity Level 1 (Unlimited), meeting identical regulatory requirements.

Q: What is the contact finish thickness specification?

A: The SPHD-002T-P0.5 does not specify contact finish thickness. The 1470106-1 specifies 60.0µin (1.52µm) tin plating thickness, providing documented finish specification for the substitute part.
