Equivalent & Substitute Parts for SLIN-06F1ALG

Part Overview

SLIN-06F1ALG is a DC-DC converter module from Bel Power Solutions, designed for non-isolated, Point-of-Load (PoL) applications with a single output voltage range of 0.6V to 3.6V, up to 6A current, and 22W maximum power. The product status is Active. Engineers may need to identify compatible substitute models due to requirements in supply chain flexibility, multi-source approval, or qualification for additional compliance standards.

Key Parameters

Manufacturer Part Number	Manufacturer	Description	Detailed Description	Product Status	Type	Number of Outputs	Voltage - Input (Min)	Voltage - Input (Max)	Voltage - Output 1	Current - Output (Max)	Power (Watts)	Applications	Features	Operating Temperature	Efficiency	Mounting Type	Package / Case	Size / Dimension	Control Features	RoHS Status	Moisture Sensitivity Level (MSL)	REACH Status	ECCN	HTSUS
SLIN-06F1ALG	Bel Power Solutions	DC DC CONVERTER 0.6-3.6V 22W	Non-Isolated PoL Module DC DC Converter 1 Output 0.6 ~ 3.6V 6A 2.4V - 5.5V Input	Active	Non-Isolated PoL Module	1	2.4V	5.5V	0.6 ~ 3.6V	6A	22 W	ITE (Commercial)	Remote On/Off, OCP, OTP	-40°C ~ 85°C	91%	Surface Mount	Module	0.48" L x 0.48" W x 0.29" H (12.2mm x 12.2mm x 7.3mm)	Enable, Active Low	ROHS3 Compliant	2A (4 Weeks)	REACH Unaffected	EAR99	8504.40.9580

Substitute Part Grouping Explanation

Substitute parts for DC-DC converter modules are identified when all of the following key parameters match or are compatible within manufacturer specifications:

Non-Isolated PoL Module type
Single output topology
Output current capacity: 6A
Output voltage range compatible with 0.6~3.6V
Input voltage range compatible with 2.4V~5.5V or encompassing the main part's range
Power rating meets or exceeds 22W
Features including remote On/Off, OCP, OTP, and control (Enable, Active Low)
Mounting type: Surface Mount
Package/case and mechanical dimensions compatible for system integration
Compliance with ROHS and industry MSL standards

Parameter Comparison

Parameter	SLIN-06F1ALG	APTH006A0X-SRZ	OKL-T/6-W12N-C
Manufacturer	Bel Power Solutions	OmniOn Power	Murata Power Solutions Inc.
Type	Non-Isolated PoL Module	Non-Isolated PoL Module	Non-Isolated PoL Module
Number of Outputs	1	1	1
Voltage - Input (Min)	2.4V	2.4V	4.5V
Voltage - Input (Max)	5.5V	5.5V	14V
Voltage - Output 1	0.6 ~ 3.6V	0.6 ~ 3.63V	0.591 ~ 5.5V
Current - Output (Max)	6A	6A	6A
Power (Watts)	22 W	22 W	30 W
Features	Remote On/Off, OCP, OTP	Remote On/Off, OCP, OTP, UVLO	Remote On/Off, OCP, OTP, SCP, UVLO
Operating Temperature	-40°C ~ 85°C	-40°C ~ 85°C	-
Efficiency	91%	93%	93%
Mounting Type	Surface Mount	Surface Mount	Surface Mount
Package / Case	Module	10-SMD Module	12-BLGA Module
Size / Dimension	0.48" x 0.48" x 0.29"	0.48" x 0.48" x 0.29"	0.48" x 0.48" x 0.28"
Control Features	Enable, Active Low	Enable, Active Low	Enable, Active Low
RoHS Status	ROHS3 Compliant	RoHS Compliant	ROHS3 Compliant
Moisture Sensitivity Level (MSL)	2A (4 Weeks)	2A (4 Weeks)	2 (1 Year)
ECCN	EAR99	EAR99	EAR99
HTSUS	8504.40.9580	8504.40.9580	8504.40.9580

Engineering Selection Recommendations

All candidate substitute models—APTH006A0X-SRZ and OKL-T/6-W12N-C—are marked as Active and meet the required compliance with RoHS and industry MSL standards. ECCN classification and HTSUS codes correspond between the main and substitute parts. When selecting equivalent DC-DC converter modules within this product category, preference is given to models that fulfill application, compliance, and supply chain requirements without deviation from specified standards.

Frequently Asked Questions (FAQ)

Q1: What key electrical parameters determine if a DC-DC converter module is a compatible substitute?
A1: Output voltage range, output current rating, input voltage range, power rating, and features such as remote on/off and protection functionalities are critical for ensuring compatibility.

Q2: Which package and mounting considerations affect compatibility?
A2: Substitute models must have matching or mechanically compatible surface-mount packages, with identical or closely matching dimensions and case types for board-level integration.

Q3: Are all substitute parts RoHS compliant and within the same MSL class?
A3: All listed substitute parts for SLIN-06F1ALG are RoHS compliant. Moisture Sensitivity Level (MSL) ratings are matched or compatible within industry standards.

Q4: How do I ensure application equivalence between substitute DC-DC converter modules?
A4: Verify that substitute modules provide the same number of outputs, output voltage range, maximum output current, and application suitability (such as ITE Commercial).

Q5: What impact does efficiency have in substitute selection?
A5: Substitute efficiency values are provided. Selection depends on whether the efficiency meets or exceeds the main part’s rating and aligns with system requirements.

Q6: Are control features and enable logic compatible across substitutes?
A6: All parts listed include Enable and Active Low control features, ensuring compatibility for system design.
