SGRP-1 Equivalent & Substitute Parts

Part Overview

The SGRP-1 is a Twist On Wire Cap Connector manufactured by TE Connectivity Aerospace, Defense and Marine. This terminal is designed for solder termination applications with wire gauges rated 1400-4800 CMA and features fully insulated heat shrink construction. The part is currently discontinued at DiGi Electronics, necessitating identification of equivalent alternatives for ongoing procurement and system maintenance.

Substiute Parts

SGRP-1

TE Connectivity Aerospace, Defense and MarineIn Stock: 989SGRP-1 Datasheet

Current PartRFQ

SGRS-1

TE Connectivity Aerospace, Defense and MarineIn Stock: 2312SGRS-1 Datasheet

SimilarRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution of the SGRP-1 is based on functional equivalence across the following critical parameters:

• Terminal Type: Twist On Wire Cap configuration must remain consistent
• Wire Gauge Rating: 1400-4800 CMA specification must be maintained
• Termination Method: Solder termination requirement must be preserved
• Insulation Construction: Fully Insulated Heat Shrink design must be retained
• Wire Entry Count: Single wire entry configuration must be matched
• Color Specification: Blue with Green Stripe identification must be preserved

The substitute part SGRS-1 maintains identical electrical and mechanical specifications across all critical parameters, ensuring direct functional compatibility.

Parameter Comparison

Engineering Selection Recommendations

The SGRS-1 serves as the direct equivalent substitute for the discontinued SGRP-1. Both parts are manufactured by TE Connectivity Aerospace, Defense and Marine and maintain identical electrical and mechanical specifications. The SGRS-1 is currently in active product status with 2235 pieces available in inventory, compared to the SGRP-1 which is discontinued.

Both parts share identical compliance certifications: RoHS non-compliant status, REACH Affected designation, EAR99 ECCN classification, and HTSUS code 8546.90.0000. The MSL rating of 1 (Unlimited) is consistent across both parts, indicating no moisture sensitivity constraints.

The primary distinction between the parts is packaging configuration, with SGRS-1 supplied in Bulk packaging. This difference does not affect functional performance or electrical characteristics.

Frequently Asked Questions (FAQ)

Q: Can SGRS-1 be used as a direct replacement for SGRP-1?

A: Yes. The SGRS-1 is functionally equivalent to the SGRP-1 across all critical electrical and mechanical parameters, including terminal type, wire gauge rating, termination method, insulation construction, and color specification.

Q: What is the difference between SGRP-1 and SGRS-1?

A: The primary difference is product status and packaging. SGRP-1 is discontinued at DiGi Electronics, while SGRS-1 is active. SGRS-1 is supplied in Bulk packaging. All electrical and mechanical specifications are identical.

Q: Are there any compliance differences between the two parts?

A: No. Both parts share identical RoHS status (non-compliant), REACH status (Affected), ECCN classification (EAR99), and HTSUS code (8546.90.0000).

Q: Does the packaging difference affect compatibility?

A: No. Packaging configuration does not affect the functional performance or electrical characteristics of the terminal. The Bulk packaging of SGRS-1 is a supply format distinction only.

Q: What wire gauge does this terminal accommodate?

A: Both SGRP-1 and SGRS-1 are rated for wire gauges of 1400-4800 CMA.

Q: Is moisture sensitivity a concern for these terminals?

A: No. Both parts carry an MSL rating of 1 (Unlimited), indicating no moisture sensitivity constraints during storage or handling.
