SCSS1/0-X Equivalent & Substitute Parts

Part Overview

The SCSS1/0-X is a terminal butt splice connector manufactured by Panduit Corp, designed for inline, individual openings crimp termination applications. This component is classified as obsolete, which necessitates identification of active equivalent parts to maintain supply chain continuity and ensure project completion without design modifications.

The SCSS1/0-X serves as a non-insulated butt splice terminal for 1/0 AWG wire gauge applications, utilizing crimp termination methodology. The obsolete status of this part requires substitution with functionally equivalent active components to support ongoing procurement and assembly operations.

Substiute Parts

SCSS1/0-X

Panduit CorpIn Stock: 1083SCSS1/0-X Datasheet

Current PartRFQ

SCS1/0-X

Panduit CorpIn Stock: 936SCS1/0-X Datasheet

SimilarRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution of the SCSS1/0-X is determined by strict equivalence across the following critical parameters:

Mandatory Matching Parameters:

• Terminal Type: Butt Splice, Inline, Individual Openings
• Wire Gauge: 1/0 AWG
• Number of Wire Entries: 2
• Termination Method: Crimp
• Insulation Classification: Non-Insulated
• Color: Pink
• Manufacturer: Panduit Corp

The SCS1/0-X meets all mandatory substitution criteria, maintaining identical electrical and mechanical specifications while offering active product status and current manufacturing support.

Parameter Comparison

Engineering Selection Recommendations

The SCS1/0-X is the direct equivalent substitute for the SCSS1/0-X. Both components share identical electrical and mechanical specifications, including terminal configuration, wire gauge capacity, termination methodology, and insulation characteristics.

The SCS1/0-X offers the following advantages for component selection:

Product Status: Active manufacturing status ensures ongoing availability, supply chain reliability, and manufacturer technical support.

Compliance Certification: ROHS3 compliance is maintained across both parts, satisfying environmental and regulatory requirements without modification to existing designs.

Regulatory Classification: Both parts carry identical ECCN (EAR99) and HTSUS (8536.90.4000) classifications, ensuring consistent export and import compliance.

Functional Equivalence: No design modifications, circuit alterations, or assembly procedure changes are required when substituting the SCS1/0-X for the SCSS1/0-X.

Frequently Asked Questions (FAQ)

Q: Can the SCS1/0-X be used as a direct replacement for the SCSS1/0-X without design changes?

A: Yes. The SCS1/0-X is functionally equivalent to the SCSS1/0-X across all electrical and mechanical parameters. No design modifications are required.

Q: What is the primary reason for substituting the SCSS1/0-X?

A: The SCSS1/0-X is classified as obsolete. The SCS1/0-X is the active equivalent part that maintains identical specifications while ensuring continued supply availability.

Q: Are there any differences in wire gauge capacity between these parts?

A: No. Both the SCSS1/0-X and SCS1/0-X are rated for 1/0 AWG wire gauge applications.

Q: Do both parts support the same termination method?

A: Yes. Both components utilize crimp termination methodology and are compatible with identical crimping tools and procedures.

Q: Are the insulation characteristics identical?

A: Yes. Both parts are non-insulated butt splice terminals with identical insulation classification.

Q: What is the wire entry configuration for these parts?

A: Both the SCSS1/0-X and SCS1/0-X feature two wire entries, configured as inline, individual openings butt splice terminals.

Q: Are there any compliance or regulatory differences between these parts?

A: No. Both parts maintain ROHS3 compliance, identical ECCN classification (EAR99), and identical HTSUS codes (8536.90.4000).

Q: What packaging format is available for the SCS1/0-X?

A: The SCS1/0-X is supplied in bulk packaging, consistent with the SCSS1/0-X packaging format.
