S2711-06R Equivalent & Substitute Parts

Part Overview

The S2711-06R is an SMT RFI clip from Harwin Inc.'s EZ BoardWare series, designed for RF and wireless shielding applications. This component features a copper alloy construction with tin plating and is rated for operating temperatures from -40°C to 125°C. The part is currently classified as obsolete, making identification of suitable substitutes essential for ongoing design support and production continuity.

Substiute Parts

S2711-06R

Harwin Inc.In Stock: 1111S2711-06R Datasheet

Current PartRFQ

S2711-46R

Harwin Inc.In Stock: 92870S2711-46R Datasheet

DirectRFQ

Key Parameters

Substitute Part Grouping Explanation

The S2711-46R qualifies as a direct substitute for the S2711-06R based on the following matching parameters:

• Identical manufacturer (Harwin Inc.)
• Same series (EZ BoardWare)
• Matching mechanical dimensions: width 0.090" (2.28mm), length 0.346" (8.79mm), height 0.140" (4.65mm)
• Identical material composition (Copper Alloy)
• Identical plating specification (Tin, 118.11µin / 3.00µm thickness)
• Identical attachment method (Solder)
• Identical operating temperature range (-40°C to 125°C)
• Identical moisture sensitivity level (MSL 1)
• Same electrical classification (RF and Wireless)

The primary distinction between these parts is packaging format and product status. The S2711-06R is supplied in bulk reel format and is obsolete, while the S2711-46R is supplied in Tape & Reel (TR) format and maintains active product status.

Parameter Comparison

Engineering Selection Recommendations

The S2711-46R is the appropriate substitute for the obsolete S2711-06R. Both components share identical electrical and mechanical specifications, ensuring functional equivalence in RF and wireless shielding applications. The S2711-46R maintains active product status with current manufacturing support and improved compliance posture (ROHS3 compliant versus RoHS non-compliant). The packaging difference—Tape & Reel format versus bulk reel—reflects modern manufacturing standards and improves component handling efficiency in automated assembly processes. Selection of the S2711-46R eliminates obsolescence risk while maintaining full electrical and mechanical compatibility.
