RFS-6V470ME3#5 Equivalent & Substitute Parts

Part Overview

The RFS-6V470ME3#5 is a 47 µF, 6.3 V aluminum electrolytic capacitor in radial, can package manufactured by Elna America. This component is classified as Obsolete, indicating discontinued production and limited availability. The part operates across a temperature range of -40°C to 85°C with a rated lifetime of 1000 hours at 85°C, making it suitable for audio applications requiring stable capacitance performance in standard operating environments. Due to obsolescence status, equivalent and substitute parts with matching or enhanced electrical characteristics are necessary for design continuity and procurement reliability.

Key Parameters

Parameter	Value	Unit
Capacitance	47	µF
Voltage - Rated	6.3	V
Tolerance	±20%	-
Operating Temperature Range	-40°C ~ 85°C	-
Lifetime @ Temperature	1000 Hrs @ 85°C	-
Ripple Current @ Low Frequency	65	mA @ 120 Hz
Lead Spacing	0.079" (2.00mm)	-
Size / Dimension	0.197" Dia (5.00mm)	-
Height - Seated (Max)	0.492" (12.50mm)	-
Mounting Type	Through Hole	-
Package / Case	Radial, Can	-
Polarization	Polar	-
RoHS Status	ROHS3 Compliant	-

Substitute Part Grouping Explanation

Substitution of the RFS-6V470ME3#5 is determined by the following critical parameters:

Primary Matching Criteria:

Capacitance: 47 µF (exact match required)
Tolerance: ±20% (exact match required)
Mounting Type: Through Hole (exact match required)
Package / Case: Radial, Can (exact match required)
Lead Spacing: 0.079" (2.00mm) (exact match required)
Polarization: Polar (exact match required)

Secondary Compatibility Criteria:

Voltage - Rated: 6.3 V minimum (equal or higher voltage rating acceptable)
Operating Temperature Range: -40°C to 85°C minimum (equal or wider range acceptable)
Ripple Current @ Low Frequency: 65 mA @ 120 Hz minimum (equal or higher acceptable)
RoHS Status: ROHS3 Compliant (required)

Substitute parts are grouped into two categories: Similar Substitutes (matching voltage rating and lifetime specifications) and Upgrade Substitutes (enhanced voltage ratings, temperature ranges, or lifetime ratings that provide superior performance margins while maintaining mechanical and electrical compatibility).

Parameter Comparison

Part Number	Manufacturer	Capacitance (µF)	Voltage (V)	Tolerance	Lifetime @ Temp	Operating Temp Range	Ripple Current @ 120 Hz (mA)	Lead Spacing	Height (Max)	Product Status
RFS-6V470ME3#5	Elna America	47	6.3	±20%	1000 Hrs @ 85°C	-40°C ~ 85°C	65	0.079" (2.00mm)	0.492" (12.50mm)	Obsolete
RFS-6V470MF3#5	Elna America	47	6.3	±20%	1000 Hrs @ 85°C	-40°C ~ 85°C	80	0.098" (2.50mm)	0.433" (11.00mm)	Obsolete
515D476M010JA6AE3	Vishay Sprague	47	10	±20%	2000 Hrs @ 85°C	-40°C ~ 85°C	59	0.079" (2.00mm)	0.433" (11.00mm)	Obsolete
EEU-FC1C470	Panasonic Electronic Components	47	16	±20%	1000 Hrs @ 105°C	-55°C ~ 105°C	113.8	0.079" (2.00mm)	0.472" (12.00mm)	Active
SEK470M010ST	Cornell Dubilier Electronics (CDE)	47	10	±20%	2000 Hrs @ 105°C	-55°C ~ 105°C	75	0.079" (2.00mm)	0.512" (13.00mm)	Active
UFW1E470MDD	Nichicon	47	25	±20%	2000 Hrs @ 85°C	-40°C ~ 85°C	115	0.079" (2.00mm)	0.492" (12.50mm)	Obsolete
UFW1V470MDD	Nichicon	47	35	±20%	2000 Hrs @ 85°C	-40°C ~ 85°C	120	0.079" (2.00mm)	0.492" (12.50mm)	Obsolete
UKT0J470MDD	Nichicon	47	6.3	±20%	1000 Hrs @ 105°C	-55°C ~ 105°C	65	0.079" (2.00mm)	0.433" (11.00mm)	Obsolete
UKT1A470MDD	Nichicon	47	10	±20%	1000 Hrs @ 105°C	-55°C ~ 105°C	68	0.079" (2.00mm)	0.433" (11.00mm)	Obsolete
UKT1C470MDD	Nichicon	47	16	±20%	1000 Hrs @ 105°C	-55°C ~ 105°C	79	0.079" (2.00mm)	0.433" (11.00mm)	Obsolete
UKT1E470MDD	Nichicon	47	25	±20%	1000 Hrs @ 105°C	-55°C ~ 105°C	83	0.079" (2.00mm)	0.433" (11.00mm)	Obsolete

Engineering Selection Recommendations

Direct Mechanical Compatibility: The RFS-6V470MF3#5 (Elna America) shares identical electrical specifications with the main part but features different lead spacing (0.098" vs 0.079") and height dimensions. This part is suitable only if PCB layout accommodates the modified footprint.

Voltage-Rated Upgrades with Maintained Mechanical Fit: Parts with 0.079" (2.00mm) lead spacing and compatible height dimensions provide direct substitution capability:

UKT0J470MDD (Nichicon): Matches 6.3 V rating with extended operating temperature range (-55°C to 105°C) and identical ripple current specification. Product status is Obsolete.
515D476M010JA6AE3 (Vishay Sprague): 10 V rated upgrade with doubled lifetime (2000 Hrs @ 85°C). Ripple current is lower (59 mA vs 65 mA). Product status is Obsolete.
UKT1A470MDD (Nichicon): 10 V rated with extended temperature range and 1000 Hrs @ 105°C lifetime. Ripple current meets specification (68 mA). Product status is Obsolete.
UKT1C470MDD (Nichicon): 16 V rated with extended temperature range and 1000 Hrs @ 105°C lifetime. Ripple current exceeds specification (79 mA). Product status is Obsolete.
UKT1E470MDD (Nichicon): 25 V rated with extended temperature range and 1000 Hrs @ 105°C lifetime. Ripple current exceeds specification (83 mA). Product status is Obsolete.

Active Product Recommendation:

EEU-FC1C470 (Panasonic Electronic Components): 16 V rated, Active product status, extended operating temperature range (-55°C to 105°C), 1000 Hrs @ 105°C lifetime, and significantly higher ripple current capacity (113.8 mA @ 120 Hz). Mechanical compatibility confirmed with 0.079" lead spacing and 0.472" height. AEC-Q200 rated for automotive applications.
SEK470M010ST (Cornell Dubilier Electronics): 10 V rated, Active product status, extended operating temperature range (-55°C to 105°C), 2000 Hrs @ 105°C lifetime, and ESR specification (6.21 Ohm @ 120 Hz). Mechanical compatibility confirmed with 0.079" lead spacing. Height is 0.512" (13.00mm), requiring PCB layout verification.

Higher Voltage Substitutes for Enhanced Margin:

UFW1E470MDD (Nichicon): 25 V rated with 2000 Hrs @ 85°C lifetime and 115 mA ripple current. Mechanical dimensions match original part exactly (0.079" lead spacing, 0.492" height). Product status is Obsolete.
UFW1V470MDD (Nichicon): 35 V rated with 2000 Hrs @ 85°C lifetime and 120 mA ripple current. Mechanical dimensions match original part exactly (0.079" lead spacing, 0.492" height). Product status is Obsolete.

All substitute parts maintain ROHS3 compliance and polar polarization matching the original specification.

Frequently Asked Questions (FAQ)

Q: Can RFS-6V470MF3#5 be used as a direct replacement for RFS-6V470ME3#5?

A: RFS-6V470MF3#5 shares identical electrical specifications (47 µF, 6.3 V, ±20% tolerance, 1000 Hrs @ 85°C). However, lead spacing differs (0.098" vs 0.079") and height is reduced (0.433" vs 0.492"). Substitution requires PCB layout modification to accommodate the different footprint. Verify pad spacing and component clearance before implementation.

Q: What is the primary advantage of upgrading to EEU-FC1C470?

A: EEU-FC1C470 is an Active product with extended operating temperature range (-55°C to 105°C vs -40°C to 85°C), higher rated voltage (16 V vs 6.3 V), and significantly increased ripple current capacity (113.8 mA @ 120 Hz vs 65 mA @ 120 Hz). It maintains identical mechanical compatibility (0.079" lead spacing, 0.472" height) and provides superior performance margins. AEC-Q200 rating enables automotive applications.

Q: Are there Active product alternatives available?

A: Yes. EEU-FC1C470 (Panasonic) and SEK470M010ST (Cornell Dubilier) are both Active products. EEU-FC1C470 offers 16 V rating with extended temperature range. SEK470M010ST offers 10 V rating with 2000 Hrs @ 105°C lifetime and specified ESR (6.21 Ohm @ 120 Hz). Both maintain 0.079" lead spacing for direct PCB compatibility.

Q: What is the difference between 1000 Hrs @ 85°C and 2000 Hrs @ 105°C lifetime ratings?

A: These represent different thermal stress conditions. 1000 Hrs @ 85°C indicates the capacitor maintains specified performance for 1000 hours at 85°C ambient temperature. 2000 Hrs @ 105°C indicates 2000 hours at the higher 105°C temperature. Higher temperature ratings with extended hour specifications indicate superior thermal stability and longer operational life under elevated conditions.

Q: Can UFW1E470MDD or UFW1V470MDD be used in place of the original part?

A: Yes. Both parts maintain identical mechanical dimensions (0.079" lead spacing, 0.492" height) and operating temperature range (-40°C to 85°C). UFW1E470MDD provides 25 V rating with 2000 Hrs @ 85°C lifetime and 115 mA ripple current. UFW1V470MDD provides 35 V rating with 2000 Hrs @ 85°C lifetime and 120 mA ripple current. Both offer enhanced voltage margins and doubled lifetime compared to the original 6.3 V, 1000 Hrs @ 85°C specification. Both are Obsolete products.

Q: What does ±20% tolerance mean for capacitance?

A: ±20% tolerance indicates the actual capacitance value may vary between 37.6 µF and 56.4 µF (47 µF ± 20%). All listed substitute parts maintain this identical tolerance specification, ensuring equivalent performance characteristics in circuit applications.

Q: Are all substitute parts RoHS3 compliant?

A: Yes. All substitute parts listed maintain ROHS3 Compliant status, matching the environmental compliance requirement of the original RFS-6V470ME3#5.

Q: What is the significance of ripple current specifications?

A: Ripple current indicates the maximum AC current the capacitor can safely handle at specified frequency without exceeding temperature limits. The original part specifies 65 mA @ 120 Hz. Substitute parts with equal or higher ripple current ratings (such as UKT0J470MDD at 65 mA, UKT1A470MDD at 68 mA, or EEU-FC1C470 at 113.8 mA) are compatible. Parts with lower ripple current (such as 515D476M010JA6AE3 at 59 mA) require circuit analysis to confirm adequate margin.
