RF292CPC Equivalent & Substitute Parts

Part Overview

The RF292CPC is a 2.92mm coaxial connector plug with male pin configuration, designed for board edge end launch solder termination applications. This connector operates at frequencies up to 40 GHz with 50 ohm impedance, making it suitable for high-frequency RF and microwave circuit implementations. The part is currently active in production status with 1009 units in stock. Substitute parts are identified to provide alternative sourcing options when the primary part number becomes unavailable or when inventory constraints require component flexibility.

Substiute Parts

RF292CPC

BulginIn Stock: 1093RF292CPC Datasheet

Current PartRFQ

RF292CPA

BulginIn Stock: 702RF292CPA Datasheet

Parametric EquivalentRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitute parts for the RF292CPC are identified based on electrical and mechanical parameter equivalence. The substitution logic is based on the following critical parameters that must remain identical:

• Connector style (2.92mm)
• Connector type (Plug, Male Pin)
• Impedance (50 Ohms)
• Mounting configuration (Board Edge, End Launch)
• Contact and shield termination method (Solder)
• Maximum frequency rating (40 GHz)
• Operating temperature range (-40°C ~ 85°C)
• Voltage rating (250 V)
• Mating cycle rating (500)
• Material specifications (Beryllium Copper center contact, Brass body, Gold finish, PEI dielectric)
• Compliance certifications (ROHS3 Compliant, MSL 1)

Parts meeting all these parameters are classified as parametric equivalents and direct substitutes for the RF292CPC.

Parameter Comparison

Engineering Selection Recommendations

The RF292CPA is a direct parametric equivalent to the RF292CPC. Both parts share identical electrical specifications, mechanical configurations, material compositions, and compliance certifications. Selection between these parts is based on inventory availability and supply chain considerations.

The RF292CPC currently maintains higher inventory levels at 1009 units compared to the RF292CPA at 672 units. Both parts are active in production status and carry ROHS3 compliance certification with MSL 1 rating, indicating unlimited shelf life under standard storage conditions.

For applications requiring the 2.92mm coaxial connector plug with 50 ohm impedance, board edge end launch solder termination, and 40 GHz frequency capability, either part number satisfies the electrical and mechanical requirements without design modification.

Frequently Asked Questions (FAQ)

Q: Can RF292CPA be used as a direct replacement for RF292CPC?

A: Yes. The RF292CPA is a parametric equivalent with identical electrical specifications, mechanical configuration, materials, and compliance certifications. No circuit or layout modifications are required for substitution.

Q: What are the key parameters that define substitution compatibility?

A: Substitution compatibility is determined by matching the connector style (2.92mm), connector type (Plug, Male Pin), impedance (50 Ohms), mounting configuration (Board Edge, End Launch), termination method (Solder), frequency rating (40 GHz), operating temperature range (-40°C ~ 85°C), voltage rating (250 V), material specifications, and compliance certifications.

Q: Are there differences in packaging between RF292CPC and RF292CPA?

A: Both parts are supplied in bulk packaging. The primary difference is inventory availability, with RF292CPC at 1009 units and RF292CPA at 672 units in stock.

Q: What is the maximum operating frequency for these connectors?

A: Both the RF292CPC and RF292CPA are rated for operation up to 40 GHz, making them suitable for high-frequency RF and microwave applications.

Q: Are these connectors RoHS compliant?

A: Yes. Both RF292CPC and RF292CPA are ROHS3 compliant and carry MSL 1 rating, indicating unlimited moisture sensitivity level for storage.

Q: What is the mating cycle rating for these connectors?

A: Both parts are rated for 500 mating cycles, defining the mechanical durability specification for repeated connection and disconnection operations.

Q: What materials are used in the connector construction?

A: Both connectors feature a beryllium copper center contact, brass body with gold finish, and polyetherimide (PEI) dielectric material, ensuring consistent electrical performance and environmental resistance.
