RBQ10BM100AFHTL Equivalent & Substitute Parts

Part Overview

The RBQ10BM100AFHTL is a Schottky diode array manufactured by Rohm Semiconductor, configured as 1 pair common cathode with a maximum reverse voltage of 100 V and average rectified current of 10 A per diode. The device is housed in a TO-252-3 DPAK surface mount package and is qualified to AEC-Q101 automotive standards. This part is currently active in production with 1587 units in stock. Substitute parts are identified when equivalent electrical and mechanical specifications are required due to supply constraints, inventory availability, or design flexibility within the same product family.

Key Parameters

Parameter	Value
Diode Configuration	1 Pair Common Cathode
Technology	Schottky
Voltage - DC Reverse (Vr) (Max)	100 V
Current - Average Rectified (Io) (per Diode)	10 A
Voltage - Forward (Vf) (Max) @ If	770 mV @ 5 A
Speed	Fast Recovery ≤ 500 ns, > 200 mA (Io)
Current - Reverse Leakage @ Vr	80 µA @ 100 V
Operating Temperature - Junction (Max)	150°C
Package / Case	TO-252-3, DPAK (2 Leads + Tab), SC-63
Mounting Type	Surface Mount
Grade	Automotive
Qualification	AEC-Q101
RoHS Status	ROHS3 Compliant
Moisture Sensitivity Level (MSL)	1 (Unlimited)

Substitute Part Grouping Explanation

Substitute parts for the RBQ10BM100AFHTL are identified based on strict electrical and mechanical parameter equivalence. The following criteria determine substitution eligibility:

Electrical Parameters:

Diode configuration: 1 Pair Common Cathode
Technology: Schottky
Maximum reverse voltage (Vr): 100 V
Average rectified current (Io): 10 A per diode
Forward voltage (Vf): 770 mV @ 5 A
Reverse leakage current: 80 µA @ 100 V
Recovery speed: Fast Recovery ≤ 500 ns, > 200 mA (Io)
Maximum junction temperature: 150°C

Mechanical Parameters:

Package type: TO-252-3, DPAK (2 Leads + Tab), SC-63
Mounting type: Surface Mount

Compliance & Environmental:

Grade: Automotive
Qualification: AEC-Q101
RoHS Status: ROHS3 Compliant
Moisture Sensitivity Level: 1 (Unlimited)

Parts meeting all these criteria are classified as parametric equivalents and direct substitutes within the RBQ10 base product family.

Parameter Comparison

Parameter	RBQ10BM100AFHTL	RBQ10BGE10ATL
Manufacturer	Rohm Semiconductor	Rohm Semiconductor
Category	Diodes, Rectifiers	Diodes, Rectifiers
Diode Configuration	1 Pair Common Cathode	1 Pair Common Cathode
Technology	Schottky	Schottky
Voltage - DC Reverse (Vr) (Max)	100 V	100 V
Current - Average Rectified (Io) (per Diode)	10 A	10 A
Voltage - Forward (Vf) (Max) @ If	770 mV @ 5 A	770 mV @ 5 A
Speed	Fast Recovery ≤ 500 ns, > 200 mA (Io)	Fast Recovery ≤ 500 ns, > 200 mA (Io)
Current - Reverse Leakage @ Vr	80 µA @ 100 V	80 µA @ 100 V
Operating Temperature - Junction (Max)	150°C	150°C
Package / Case	TO-252-3, DPAK (2 Leads + Tab), SC-63	TO-252-3, DPAK (2 Leads + Tab), SC-63
Mounting Type	Surface Mount	Surface Mount
Grade	Automotive	Automotive
Qualification	AEC-Q101	AEC-Q101
RoHS Status	ROHS3 Compliant	ROHS3 Compliant
Moisture Sensitivity Level (MSL)	1 (Unlimited)	1 (Unlimited)
Product Status	Active	Active

Engineering Selection Recommendations

Both the RBQ10BM100AFHTL and RBQ10BGE10ATL are active production parts manufactured by Rohm Semiconductor with identical electrical and mechanical specifications. Both devices carry AEC-Q101 automotive qualification and ROHS3 compliance, making them suitable for automotive applications requiring Schottky diode arrays with 100 V reverse voltage and 10 A current ratings.

Selection between these parts is based on availability and supplier device package designation. The RBQ10BM100AFHTL is supplied in TO-252 package configuration with 1587 units currently in stock. The RBQ10BGE10ATL is supplied in TO-252GE package configuration with 2894 units currently in stock. Both parts are interchangeable at the circuit level due to identical electrical performance and physical form factor.

Frequently Asked Questions (FAQ)

Q: Can RBQ10BGE10ATL be used as a direct replacement for RBQ10BM100AFHTL?

A: Yes. Both parts are parametric equivalents with identical electrical specifications, package dimensions, and automotive qualifications. The difference in part number suffix reflects the supplier device package designation (TO-252 versus TO-252GE) but does not affect electrical performance or physical compatibility.

Q: Are there any differences in the TO-252 and TO-252GE package designations?

A: The package case remains TO-252-3, DPAK (2 Leads + Tab), SC-63 for both parts. The suffix designation indicates supplier-specific packaging or tape configuration but does not alter the physical dimensions or electrical characteristics relevant to circuit design.

Q: What are the key electrical parameters that define substitution eligibility?

A: Substitution eligibility is determined by matching: diode configuration (1 Pair Common Cathode), technology (Schottky), maximum reverse voltage (100 V), average rectified current (10 A per diode), forward voltage (770 mV @ 5 A), reverse leakage current (80 µA @ 100 V), and recovery speed (Fast Recovery ≤ 500 ns, > 200 mA).

Q: Are both parts suitable for automotive applications?

A: Yes. Both RBQ10BM100AFHTL and RBQ10BGE10ATL are automotive-grade components with AEC-Q101 qualification, ROHS3 compliance, and unlimited moisture sensitivity level (MSL 1), meeting automotive reliability and environmental standards.

Q: What is the maximum junction temperature for these diodes?

A: The maximum operating junction temperature for both parts is 150°C.

Q: Are these parts RoHS compliant?

A: Yes. Both parts are ROHS3 compliant and REACH unaffected, meeting environmental and regulatory requirements for electronic component manufacturing and use.
