R591302425 RF Switch IC SP4T 6GHz Module – Equivalent & Substitute Parts

Part Overview

The R591302425 is an RF Switch IC module manufactured by Radiall USA, Inc., designed for general-purpose RF switching applications. This SP4T (Single Pole, Four Throw) switch operates across the 0Hz to 6GHz frequency range with 50-ohm impedance and module-level integration featuring SMA connectors. The component is currently in active production status with 842 units available in inventory.

Identifying equivalent and substitute parts is necessary to ensure design flexibility, manage supply chain continuity, and maintain performance specifications across alternative sourcing options. Substitute parts must maintain identical electrical characteristics and mechanical compatibility to ensure direct interchangeability without circuit redesign.

Substiute Parts

R591302425

Radiall USA, Inc.In Stock: 909R591302425 Datasheet

Current PartRFQ

R591362440

Radiall USA, Inc.In Stock: 840R591362440 Datasheet

Parametric EquivalentRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitute parts for the R591302425 are identified based on strict electrical and mechanical parameter matching. The substitution logic is based on the following critical parameters:

Electrical Parameters (Must Match Exactly):

• Circuit topology: SP4T configuration
• Frequency range: 0Hz ~ 6GHz operation
• Impedance: 50-ohm characteristic impedance
• Isolation performance: 70dB minimum
• Insertion loss: 0.3dB maximum
• Supply voltage: 10.2V ~ 13V range
• Operating temperature: -40°C ~ 85°C

Mechanical Parameters (Must Match Exactly):

• Package format: Module with SMA connectors
• Form factor: Supplier device package classification as Module

Compliance Parameters:

• RoHS3 compliance status

Parts meeting all these criteria are classified as direct parametric equivalents and can be substituted without circuit modification or performance degradation.

Parameter Comparison

Engineering Selection Recommendations

The R591362440 is a direct parametric equivalent to the R591302425. Both components are manufactured by Radiall USA, Inc., and share identical electrical specifications, mechanical packaging, and compliance certifications.

Selection Criteria:

Both parts are in active production status and maintain ROHS3 compliance. The R591302425 has 842 units in current inventory, while the R591362440 has 786 units available. Either part can be selected based on supply availability and procurement lead time requirements.

The R591362440 carries additional regulatory documentation including REACH Affected status, ECCN classification (EAR99), and HTSUS code (8543.70.9860), which may be relevant for international distribution or export compliance requirements. The R591302425 does not specify these additional regulatory parameters in the provided data.

Both components are suitable for direct substitution in SP4T RF switching applications requiring 50-ohm impedance, 6GHz frequency operation, and module-level integration with SMA connectors.
