PSMP-MSLD-PCE Equivalent & Substitute Parts

Part Overview

The PSMP-MSLD-PCE is a PSMP Connector Jack with male pin configuration, manufactured by Amphenol RF. This coaxial RF connector is designed for 50 Ohm board edge applications with surface mount solder termination. The component is currently Active in product status and maintains 1082 pieces in new original inventory stock. Equivalent and substitute parts are identified to support procurement flexibility, supply chain continuity, and design alternatives where connector type variations are functionally acceptable within system requirements.

Substiute Parts

PSMP-MSLD-PCE

Amphenol RFIn Stock: 1167PSMP-MSLD-PCE Datasheet

Current PartRFQ

119S202-40ML5

RosenbergerIn Stock: 1739119S202-40ML5 Datasheet

DirectRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution of the PSMP-MSLD-PCE is evaluated based on strict electrical and mechanical parameter alignment within the PSMP connector family. The primary substitute identified is the 119S202-40ML5 manufactured by Rosenberger.

Substitution Criteria (Strictly Based on Provided Parameters):

The 119S202-40ML5 qualifies as a substitute based on the following matching parameters:

• Connector Style: PSMP (identical connector family)
• Impedance: 50 Ohms (identical electrical specification)
• Frequency - Max: 10 GHz (identical frequency rating)
• Mounting Type: Board Edge, Cutout; Surface Mount (identical mechanical mounting)
• Contact Termination: Solder (identical termination method)
• Shield Termination: Solder (identical termination method)
• Operating Temperature: -65°C ~ 165°C (identical temperature range)
• Voltage Rating: 480 V (identical voltage specification)
• Fastening Type: Snap-On (identical fastening mechanism)
• Number of Ports: 1 (identical port configuration)
• Features: Limited Detent (identical feature set)
• Housing Color: Gold (identical finish specification)
• Center Contact Material: Brass (identical material)
• Body Material: Brass (identical material)
• Body Finish: Gold (identical finish)
• Center Contact Plating: Gold (identical plating)
• Dielectric Material: Polytetrafluoroethylene (PTFE) (identical dielectric)
• RoHS Status: ROHS3 Compliant (identical compliance)
• Moisture Sensitivity Level (MSL): 1 (Unlimited) (identical MSL rating)
• REACH Status: REACH Affected (identical regulatory status)
• ECCN: EAR99 (identical export classification)
• HTSUS: 8536.69.4010 (identical tariff classification)

Connector Type Variation:

The primary difference between the main part and substitute is the Connector Type designation: the PSMP-MSLD-PCE is specified as Jack, Male Pin, while the 119S202-40ML5 is specified as Plug, Male Pin. This variation exists within the PSMP connector family and represents a design choice based on mating interface requirements.

Parameter Comparison

Engineering Selection Recommendations

Primary Part: PSMP-MSLD-PCE (Amphenol RF)

The PSMP-MSLD-PCE is the specified component with Active product status and ROHS3 compliance. This part maintains 1082 pieces in new original inventory and supports 500 mating cycles. Selection of this part is appropriate for applications requiring the Jack, Male Pin connector type configuration within the PSMP family.

Substitute Part: 119S202-40ML5 (Rosenberger)

The 119S202-40ML5 is an equivalent substitute within the PSMP connector family, offering identical electrical and mechanical specifications with the exception of connector type designation (Plug, Male Pin versus Jack, Male Pin) and mating cycle rating (100 cycles versus 500 cycles). This part is Active in product status, ROHS3 compliant, and maintains 1692 pieces in new original inventory.

Compliance and Regulatory Status:

Both parts maintain identical compliance certifications: ROHS3 Compliant, REACH Affected status, and EAR99 export classification. Both parts carry MSL 1 (Unlimited) moisture sensitivity rating, indicating no special moisture control requirements during storage or handling.

Mating Cycle Consideration:

The PSMP-MSLD-PCE supports 500 mating cycles, while the 119S202-40ML5 supports 100 mating cycles. Applications requiring frequent connector mating should prioritize the PSMP-MSLD-PCE specification.
