PMNF2-6R-L Ring Terminal Connector M6 Equivalent & Substitute Parts

Part Overview

The PMNF2-6R-L is an insulated circular ring terminal connector manufactured by Panduit Corp, designed for 14-16 AWG wire gauges with M6 stud mounting. This component is classified as obsolete, necessitating identification of functionally equivalent alternatives for ongoing procurement and system maintenance. The part features crimp termination with serrated contact surfaces and tin-plated electrolytic copper construction, suitable for free-hanging inline applications requiring reliable electrical connection.

Substiute Parts

PMNF2-6R-L

Panduit CorpIn Stock: 1004PMNF2-6R-L Datasheet

Current PartRFQ

3240025

Phoenix ContactIn Stock: 145783240025 Datasheet

SimilarRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution eligibility for the PMNF2-6R-L is determined by strict equivalence across the following critical parameters:

Mandatory Matching Parameters:

• Terminal Type: Circular
• Stud/Tab Size: M6 Stud
• Wire Gauge: 14-16 AWG
• Termination Method: Crimp
• Insulation: Insulated
• Contact Finish: Tin
• Mounting Type: Free Hanging (In-Line)

The substitute part 3240025 (Phoenix Contact CLIPLINE series) satisfies all mandatory matching parameters. This part maintains functional compatibility with the original PMNF2-6R-L across electrical and mechanical interfaces, enabling direct substitution in applications requiring M6 stud ring terminals for 14-16 AWG wire.

Parameter Comparison

Engineering Selection Recommendations

The Phoenix Contact 3240025 terminal connector serves as the direct functional equivalent for the obsolete PMNF2-6R-L. Selection of this substitute is supported by the following engineering factors:

Product Status Alignment: The PMNF2-6R-L is classified as obsolete, while the 3240025 maintains active product status with confirmed inventory availability (14,485 pieces in stock). This status differential ensures long-term procurement viability for the substitute.

Compliance and Certification: The 3240025 is ROHS3 compliant and REACH unaffected, meeting current regulatory requirements for electronic component procurement. The original PMNF2-6R-L does not specify these compliance certifications, making the substitute the preferred choice for applications subject to modern environmental and safety standards.

Electrical and Mechanical Equivalence: Both terminals maintain identical specifications for the critical functional parameters: M6 stud interface, 14-16 AWG wire accommodation, crimp termination, tin contact finish, and insulated circular configuration. Minor dimensional variations (width and length) fall within acceptable tolerances for free-hanging inline mounting applications and do not compromise functional performance.

Contact Material Specification: The substitute specifies copper contact material (versus electrolytic copper in the original), which maintains equivalent electrical conductivity and corrosion resistance for the intended application.

Frequently Asked Questions (FAQ)

Q: Can the Phoenix Contact 3240025 be used as a direct replacement for the PMNF2-6R-L in existing assemblies?

A: Yes. The 3240025 is functionally equivalent across all critical parameters: M6 stud size, 14-16 AWG wire gauge, crimp termination, tin finish, and insulated circular configuration. The minor dimensional variations do not affect performance in free-hanging inline mounting applications.

Q: What is the significance of the product status difference between the two parts?

A: The PMNF2-6R-L is obsolete, indicating discontinued manufacturing and limited future availability. The 3240025 is active with substantial inventory (14,485 pieces), ensuring reliable procurement for current and future applications.

Q: Are there compliance differences between the original and substitute parts?

A: The 3240025 is certified ROHS3 compliant and REACH unaffected, meeting current regulatory standards. The PMNF2-6R-L does not specify these certifications. For applications requiring compliance documentation, the 3240025 is the appropriate selection.

Q: How do the dimensional differences between these parts affect compatibility?

A: The 3240025 is slightly larger (0.472" width versus 0.430", and 1.106" length versus 1.043"). These minor variations are within acceptable tolerances for M6 stud mounting and do not compromise electrical or mechanical performance in standard applications.

Q: What is the difference between electrolytic copper and copper contact material?

A: Both materials provide equivalent electrical conductivity and corrosion resistance for crimp terminal applications. The specification difference reflects manufacturing process variation rather than functional performance difference.

Q: Is the plastic insulation material of the 3240025 equivalent to the PA66 nylon of the PMNF2-6R-L?

A: Yes. Both materials provide adequate electrical insulation and mechanical protection for 14-16 AWG wire in free-hanging applications. The plastic specification for the 3240025 meets the same functional requirements as the PA66 nylon of the original part.

Q: What packaging format is available for the 3240025?

A: The 3240025 is supplied in bulk packaging, differing from the original part's unspecified packaging. Bulk packaging is standard for active production terminals and does not affect component functionality.
