PJRAS2X1S01 Equivalent & Substitute Parts

Part Overview

The PJRAS2X1S01 is a right-angle RCA jack mono connector manufactured by Switchcraft Inc., designed for audio and signal applications requiring a 3.20mm ID, 9.00mm OD phono jack interface. This connector features solder termination, shielding, and a grounding tab for reliable signal transmission. The part is actively stocked with 622 units available as new original inventory. Substitute parts are identified to provide alternative sourcing options while maintaining electrical and mechanical compatibility within the PJR series.

Substiute Parts

PJRAS2X1S01

Switchcraft Inc.In Stock: 685PJRAS2X1S01 Datasheet

Current PartRFQ

PJRAS2X1S01X

Switchcraft Inc.In Stock: 1427PJRAS2X1S01X Datasheet

DirectRFQ

Key Parameters

Substitute Part Grouping Explanation

The PJRAS2X1S01X qualifies as a direct substitute based on identical electrical and mechanical specifications. Substitution compatibility is determined by the following critical parameters:

• Connector type and gender (Phono RCA Jack, Female)
• Signal configuration (Mono)
• Mating diameter specification (3.20mm ID, 9.00mm OD)
• Mounting orientation (Right Angle, Through Hole)
• Termination method (Solder)
• Shielding configuration (Shielded)
• Contact count and conductor arrangement (2 Sets of 2 Conductors, 4 Contacts)
• Electrical ratings (34VAC/DC, 2 A)
• Operating temperature range (-25°C ~ 85°C)
• Material composition and plating (Tin-plated Copper Alloy contacts, ABS housing)
• Regulatory compliance (ROHS3 Compliant, REACH Unaffected)

The PJRAS2X1S01X maintains full compatibility with applications designed for the PJRAS2X1S01, with the primary difference being packaging format (Bulk versus standard packaging).

Parameter Comparison

Engineering Selection Recommendations

Both the PJRAS2X1S01 and PJRAS2X1S01X are active products from Switchcraft Inc. with full ROHS3 compliance and REACH unaffected status, meeting current regulatory requirements for electronic component manufacturing and use. The parts are electrically and mechanically identical, with substitution decisions based on packaging requirements and inventory availability.

Selection between these parts should be determined by procurement volume and packaging specifications. The PJRAS2X1S01X offers higher inventory availability (1339 units) in bulk packaging format, while the PJRAS2X1S01 is available in standard packaging with 622 units in stock. Both maintain identical performance characteristics and compliance certifications.
