PE890206 AC Power Connector - Equivalent & Substitute Parts

Part Overview

The PE890206 is an IEC 320-C14 power entry connector receptacle manufactured by Curtis Industries, designed for AC power applications requiring filtered EMI/RFI protection. This module-style connector features panel mount installation with integrated fuse holder and on-off switch functionality. The part is currently active in production with 969 units in stock inventory.

Substitute parts become necessary when Curtis Industries PE890206 units are unavailable, when alternative sourcing reduces lead times, or when procurement requirements mandate multi-source qualification for supply chain resilience.

Substiute Parts

PE890206

Curtis IndustriesIn Stock: 1018PE890206 Datasheet

Current PartRFQ

FN388-6-22

Schaffner EMC Inc.In Stock: 677FN388-6-22 Datasheet

SimilarRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution eligibility for the PE890206 is determined by strict alignment across the following critical parameters:

• Connector style and type (IEC 320-C14, Receptacle, Male Blades - Module)
• Electrical ratings (6A current, 250VAC voltage, 3 positions)
• Filtering capability (EMI/RFI Commercial grade)
• Switching and fuse holder functionality (On-Off switch, Twin Fused)
• Mounting configuration (Panel Mount, Flange)
• Regulatory compliance (CE, CSA, UL certifications minimum)
• Environmental compliance (ROHS3, REACH Unaffected)

The FN388-6-22 from Schaffner EMC Inc. qualifies as a substitute based on matching connector style, type, position count, filter classification, switch features, fuse accommodation, and mounting type. Differences in termination method (Solder Eyelet vs. Quick Connect) and panel cutout specifications require engineering evaluation for specific application contexts.

Parameter Comparison

Engineering Selection Recommendations

Both PE890206 and FN388-6-22 maintain active product status and satisfy core regulatory requirements (CSA, UL certifications present in both). Both are ROHS3 compliant and REACH unaffected.

Selection between these parts depends on termination compatibility with existing wiring harness infrastructure. The PE890206 uses Quick Connect terminals (0.110" / 2.8mm), while the FN388-6-22 requires solder eyelet termination. Panel cutout dimensions differ: PE890206 specifies a fixed rectangular opening (28.50mm x 55.90mm), whereas FN388-6-22 accommodates variable panel sizes within 0.79mm to 3.20mm thickness range.

The FN388-6-22 offers additional mounting flexibility through front or rear side mount capability. Packaging differs (PE890206 supplied in Bulk; FN388-6-22 in Tray), which may affect inventory management and handling procedures.

Frequently Asked Questions (FAQ)

Q: Can FN388-6-22 directly replace PE890206 in existing assemblies?

A: Direct replacement requires compatibility verification across two critical dimensions: termination method and panel cutout specifications. PE890206 uses quick connect terminals while FN388-6-22 uses solder eyelet termination. Panel mounting geometry differs between the two models. Electrical and filtering characteristics are equivalent.

Q: What are the key electrical equivalencies between these parts?

A: Both connectors operate at 250VAC, 6A current rating, feature IEC 320-C14 configuration with 3 positions, include commercial-grade EMI/RFI filtering, on-off switching, and twin fused accommodation. Electrical performance is functionally equivalent.

Q: How do packaging differences affect procurement?

A: PE890206 is supplied in Bulk packaging (969 units available), while FN388-6-22 is supplied in Tray packaging (651 units available). Bulk packaging typically offers cost advantages for high-volume applications, while tray packaging may provide better component protection during storage and handling.

Q: Are both parts compliant with the same regulatory standards?

A: Both parts hold CSA and UL certifications. PE890206 additionally carries CE and TUV approvals. FN388-6-22 carries VDE approval. All certifications are current and valid for their respective markets.

Q: What termination method should I select for my application?

A: Selection depends on existing wiring harness infrastructure. Quick Connect terminals (PE890206) are suitable for applications using 0.110" (2.8mm) spade connectors. Solder eyelet termination (FN388-6-22) requires direct wire soldering to the connector terminals.
