NHSC1003R9J Equivalent & Substitute Parts

Part Overview

The NHSC1003R9J is a 3.9 Ohms ±5% 100W wirewound chassis mount resistor manufactured by TE Connectivity Passive Product. This component is designed for high-power applications requiring stable resistance performance across extended temperature ranges. The part is classified as obsolete, necessitating identification of active equivalent alternatives for ongoing procurement and system maintenance.

Substiute Parts

NHSC1003R9J

TE Connectivity Passive ProductIn Stock: 868NHSC1003R9J Datasheet

Current PartRFQ

HSC1003R9J

TE Connectivity Passive ProductIn Stock: 750HSC1003R9J Datasheet

Parametric EquivalentRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution of the NHSC1003R9J is determined by strict equivalence across all critical electrical and mechanical parameters. The substitute part must maintain identical specifications for resistance value, tolerance, power rating, temperature coefficient, operating temperature range, physical dimensions, and mounting configuration. These parameters ensure functional and mechanical compatibility within the original application circuit and mechanical assembly.

The HSC1003R9J qualifies as a direct parametric equivalent based on matching all specified electrical characteristics and physical dimensions. The substitution is valid across the following key parameters:

• Resistance: 3.9 Ohms
• Tolerance: ±5%
• Power Rating: 100W
• Wirewound composition
• Temperature Coefficient: ±50ppm/°C
• Operating Temperature: -55°C ~ 200°C
• Aluminum housing with flanged mounting
• Identical physical dimensions and lead configuration

Parameter Comparison

Engineering Selection Recommendations

The HSC1003R9J is the direct substitute for the obsolete NHSC1003R9J. Both parts are manufactured by TE Connectivity Passive Product and share identical electrical and mechanical specifications. The primary distinction is product status: the NHSC1003R9J is obsolete, while the HSC1003R9J maintains active production status.

The HSC1003R9J provides enhanced compliance through ROHS3 certification, compared to the RoHS compliance of the original part. This upgrade in regulatory compliance supports long-term supply chain continuity and regulatory alignment for new designs and system updates.

Both parts are suitable for applications requiring 100W power dissipation at 3.9 Ohms resistance with stable performance across the -55°C to 200°C operating temperature range. The identical physical dimensions and flanged mounting configuration ensure direct mechanical and electrical interchangeability within existing circuit board layouts and mechanical assemblies.

Frequently Asked Questions (FAQ)

Q: Can the HSC1003R9J be used as a direct replacement for the NHSC1003R9J?

A: Yes. The HSC1003R9J is a direct parametric equivalent. All electrical specifications (resistance, tolerance, power rating, temperature coefficient, operating temperature range) and mechanical dimensions are identical. The HSC1003R9J is the active production alternative to the obsolete NHSC1003R9J.

Q: What is the difference between NHSC1003R9J and HSC1003R9J?

A: The primary difference is product status. The NHSC1003R9J is obsolete, while the HSC1003R9J is active. The HSC1003R9J also carries ROHS3 compliance versus RoHS compliance for the original part. All electrical and mechanical parameters are identical.

Q: Are the physical dimensions identical between these parts?

A: Yes. Both parts share identical dimensions: 2.579" L x 1.870" W (65.50mm x 47.50mm) with a maximum seated height of 1.024" (26.00mm). The flanged mounting configuration and solder lug lead style are identical, ensuring direct mechanical compatibility.

Q: What is the resistance tolerance for these parts?

A: Both parts have a tolerance of ±5%, meaning the actual resistance value will fall within the range of 3.705 Ohms to 4.095 Ohms.

Q: What is the operating temperature range?

A: Both parts operate across the temperature range of -55°C to 200°C with a temperature coefficient of ±50ppm/°C.

Q: Are these parts RoHS compliant?

A: Yes. The NHSC1003R9J is RoHS Compliant. The HSC1003R9J is ROHS3 Compliant, providing enhanced regulatory alignment for current procurement requirements.

Q: What packaging is available for the HSC1003R9J?

A: The HSC1003R9J is available in Bulk packaging, compared to the standard packaging of the NHSC1003R9J.
