MV6700AGR LED Red Diffused SMD Equivalent & Substitute Parts

Part Overview

The MV6700AGR is a red diffused LED indicator manufactured by Everlight Electronics Co Ltd, designed for surface mount applications in 2-SMD gull wing configuration. This component is classified as an active product with full RoHS3 compliance and unlimited moisture sensitivity rating (MSL 1). The MV6700AGR operates at 1.8V forward voltage with 10mA test current, delivering 3mcd luminous intensity through a diffused red lens with 50° viewing angle and 635nm peak wavelength.

Substitute parts are necessary when original inventory is unavailable, when alternative mounting technologies are required for specific PCB designs, or when performance parameters must be adjusted for particular application requirements while maintaining functional compatibility.

Key Parameters

Parameter	MV6700AGR Value	Substitution Relevance
Color	Red	Critical - must match for visual indication consistency
Lens Transparency	Diffused	Critical - affects light distribution and viewing characteristics
Voltage - Forward (Vf) (Typ)	1.8V	Critical - determines circuit compatibility and current limiting requirements
Current - Test	10mA	Critical - establishes operating point and power dissipation
Millicandela Rating	3mcd	Important - defines brightness level for visibility requirements
Wavelength - Peak	635nm	Important - specifies red color spectrum for application matching
Mounting Type	Surface Mount	Critical - determines PCB assembly compatibility
Package / Case	2-SMD, Gull Wing	Critical - physical footprint and soldering method
Lens Size	1.90mm Dia	Important - affects viewing angle and optical performance
Viewing Angle	50°	Important - determines directional light emission characteristics
RoHS Status	ROHS3 Compliant	Critical - regulatory compliance requirement
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Important - affects storage and handling requirements

Substitute Part Grouping Explanation

Substitution logic for the MV6700AGR is based on strict parameter matching within the following categories:

Primary Substitution Criteria (Must Match):

Color: Red
Lens Transparency: Diffused
Voltage - Forward (Vf): 1.8V ±0.2V tolerance range
Current - Test: 10mA
Mounting Type: Surface Mount
Package / Case: 2-SMD, Gull Wing configuration
RoHS Status: ROHS3 Compliant

Secondary Compatibility Parameters (Allowable Variation):

Millicandela Rating: 3mcd baseline; substitutes with 10mcd acceptable for higher brightness applications
Wavelength - Peak: 635nm baseline; 626nm acceptable within red spectrum
Lens Size: 1.90mm baseline; 1.78mm acceptable with minor optical adjustment
Viewing Angle: 50° baseline; 90° acceptable for wider distribution applications
Moisture Sensitivity Level: MSL 1 preferred; MSL 2A acceptable with appropriate storage protocols

Non-Substitutable Parameters:

Surface mount technology requirement is absolute; through-hole axial components cannot substitute
2-SMD gull wing package is specific; alternative SMD configurations (yoke bend, right angle) are not direct substitutes for this application

The following Broadcom HLMP-6xxx series components meet the primary substitution criteria with surface mount gull wing configuration: HLMP-6000-E0011, HLMP-6300-F0011, and HLMP-6300-F0021.

Parameter Comparison

Parameter	MV6700AGR	HLMP-6000-E0011	HLMP-6300-F0011	HLMP-6300-F0021
Manufacturer	Everlight Electronics	Broadcom Limited	Broadcom Limited	Broadcom Limited
Color	Red	Red	Red	Red
Lens Transparency	Diffused	Diffused	Diffused	Diffused
Voltage - Forward (Vf) (Typ)	1.8V	1.6V	1.8V	1.8V
Current - Test	10mA	10mA	10mA	10mA
Millicandela Rating	3mcd	1.2mcd	10mcd	10mcd
Wavelength - Peak	635nm	655nm	635nm	635nm
Mounting Type	Surface Mount	Surface Mount	Surface Mount	Surface Mount
Package / Case	2-SMD, Gull Wing	2-SMD, Gull Wing	2-SMD, Gull Wing	2-SMD, Yoke Bend
Lens Size	1.90mm Dia	1.78mm Dia	1.78mm Dia	1.78mm Dia
Viewing Angle	50°	90°	90°	90°
RoHS Status	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant
Moisture Sensitivity Level (MSL)	1 (Unlimited)	2A (4 Weeks)	2A (4 Weeks)	2A (4 Weeks)
Inventory Status	898 Pcs New Original	1340 Pcs New Original	4336 Pcs New Original	9390 Pcs New Original

Engineering Selection Recommendations

HLMP-6300-F0011 (Primary Substitute - Gull Wing SMD)

HLMP-6300-F0011 is the optimal substitute for MV6700AGR when direct package compatibility is required. Both components feature 2-SMD gull wing surface mount configuration with identical physical dimensions (2.08mm L x 2.21mm W, 2.92mm height). Electrical parameters align precisely: 1.8V forward voltage matches the original specification, 10mA test current is identical, and 635nm peak wavelength ensures color consistency. The 10mcd brightness rating provides enhanced luminous intensity compared to the original 3mcd, offering improved visibility margin in applications. Both components maintain ROHS3 compliance. The primary consideration is moisture sensitivity: HLMP-6300-F0011 carries MSL 2A (4 weeks) versus MV6700AGR's MSL 1 (unlimited), requiring adherence to standard moisture control protocols during storage and assembly. Inventory availability is strong at 4336 pieces.

HLMP-6000-E0011 (Alternative Substitute - Gull Wing SMD, Lower Voltage)

HLMP-6000-E0011 provides gull wing SMD compatibility with identical package footprint. Forward voltage is 1.6V, requiring circuit verification to confirm adequate current limiting and proper LED operation within the application's voltage tolerance. Millicandela rating of 1.2mcd is lower than the original 3mcd specification, suitable only for applications where reduced brightness is acceptable. Peak wavelength of 655nm represents a slight shift toward longer wavelengths within the red spectrum. MSL 2A rating applies. This substitute is appropriate when lower forward voltage operation is beneficial for power management or when brightness reduction is acceptable.

HLMP-6300-F0021 (Alternative Substitute - Yoke Bend SMD)

HLMP-6300-F0021 matches electrical specifications (1.8V, 10mA, 10mcd, 635nm) and maintains gull wing SMD surface mount technology. However, the package configuration is 2-SMD yoke bend rather than standard gull wing, resulting in different lead geometry and PCB footprint. This component is not a direct substitute for standard gull wing applications but serves as an alternative when yoke bend lead configuration is compatible with the PCB design. MSL 2A rating applies. Inventory availability is excellent at 9390 pieces.

Compliance and Certification Status

All recommended substitutes maintain ROHS3 compliance and EAR99 export classification matching the original MV6700AGR. REACH unaffected status applies to Broadcom components. No additional certifications or regulatory modifications are required for substitution.

Frequently Asked Questions (FAQ)

Q: Can HLMP-6000-E0011 substitute for MV6700AGR in all applications?

A: HLMP-6000-E0011 is compatible for surface mount gull wing applications but requires circuit verification. The 1.6V forward voltage differs from the original 1.8V specification. Verify that the application's current limiting circuit accommodates this lower voltage without exceeding 10mA test current. The 1.2mcd brightness is significantly lower than the original 3mcd; confirm that reduced luminous intensity is acceptable for the intended indication function.

Q: What is the impact of MSL 2A rating on HLMP-6300-F0011 compared to MV6700AGR's MSL 1?

A: MSL 2A (4 weeks) requires moisture control during storage and assembly. Components must be stored in dry conditions and used within 4 weeks of package opening. Standard moisture barrier bags with desiccant are appropriate. MSL 1 (unlimited) components have no moisture sensitivity restrictions. For high-volume production or extended storage, implement standard moisture management protocols. This does not affect electrical performance or reliability after assembly.

Q: Are the 1.90mm and 1.78mm lens diameter differences significant?

A: Lens diameter affects optical performance and viewing characteristics. The 1.90mm diameter (MV6700AGR) versus 1.78mm diameter (HLMP substitutes) represents a minor reduction. This may result in slightly different light distribution patterns and viewing angle characteristics. For applications where precise optical performance is critical, conduct visual testing to confirm acceptability. For standard indication applications, this difference is typically negligible.

Q: Why does HLMP-6300-F0021 have a different package designation (yoke bend) than the standard gull wing?

A: Yoke bend configuration features different lead geometry compared to standard gull wing. The leads are bent in a yoke pattern rather than straight gull wing configuration, resulting in a different PCB footprint. HLMP-6300-F0021 is not a direct footprint substitute for standard gull wing applications. Verify PCB design compatibility before selection. Use only if the PCB layout specifically accommodates yoke bend lead geometry.

Q: Can I use HLMP-6300-F0011 as a drop-in replacement without circuit modifications?

A: HLMP-6300-F0011 is a direct electrical and mechanical substitute for MV6700AGR. Both operate at 1.8V forward voltage with 10mA test current, ensuring compatibility with existing current limiting circuits. The 2-SMD gull wing package footprint is identical. No circuit modifications are required. Standard moisture handling protocols for MSL 2A components apply during assembly.

Q: What is the viewing angle difference between MV6700AGR (50°) and HLMP substitutes (90°)?

A: Viewing angle defines the cone of light emission. MV6700AGR's 50° angle provides more directional, concentrated light output. HLMP substitutes with 90° viewing angle distribute light more widely. For applications requiring concentrated light in a specific direction, the 50° angle is preferred. For applications requiring broader light distribution, the 90° angle is advantageous. Verify application requirements before selection based on intended viewing geometry.

Q: Are all recommended substitutes available in the same packaging format (bulk)?

A: MV6700AGR is supplied in bulk packaging. HLMP-6000-E0011 is available in tape & reel (TR) format. HLMP-6300-F0011 is available in cut tape (CT) & Digi-Reel format. HLMP-6300-F0021 is available in tape & reel (TR) format. Verify packaging compatibility with your procurement and assembly processes. Bulk packaging may require special order or minimum quantity adjustments.
