MUC-20PFFR-JS7001 Equivalent & Substitute Parts

Part Overview

The MUC-20PFFR-JS7001 is a USB 2.0 micro AB receptacle connector manufactured by Amphenol LTW, designed for surface mount, right-angle applications. This connector features a 5-position configuration with IP67 ingress protection rating, suitable for dust-tight and waterproof applications. The part is classified as obsolete, necessitating identification of active equivalent alternatives to maintain design continuity and ensure supply chain availability for new production and field replacements.

Substiute Parts

MUC-20PFFR-JS7001

Amphenol LTWIn Stock: 40112MUC-20PFFR-JS7001 Datasheet

Current PartRFQ

MUC-20PFFR-JS7002

Amphenol LTWIn Stock: 6389MUC-20PFFR-JS7002 Datasheet

SimilarRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution of the MUC-20PFFR-JS7001 is determined by strict equivalence across the following critical parameters:

Mandatory Matching Parameters:

• Connector Type: USB - micro AB
• Number of Contacts: 5
• Gender: Receptacle
• USB Specification: USB 2.0
• Mounting Type: Surface Mount, Right Angle
• Mounting Feature: Horizontal
• Termination: Solder
• Ingress Protection: IP67
• Operating Temperature Range: -30°C ~ 85°C
• Number of Ports: 1
• Mating Cycles: 10000
• Contact Finish: Gold
• Shell/Shielding Material: Steel, Stainless
• Insulation Color: Black

The MUC-20PFFR-JS7001 shares the same base product number (MUC-20PFFR) with its substitute, confirming core mechanical and electrical compatibility. The substitute part maintains all critical functional parameters while offering improved product status and compliance certifications.

Parameter Comparison

Engineering Selection Recommendations

The MUC-20PFFR-JS7002 is the direct substitute for the obsolete MUC-20PFFR-JS7001. Both connectors share identical mechanical and electrical specifications, including connector type, contact configuration, mounting orientation, and environmental protection rating.

Product Status Consideration: The MUC-20PFFR-JS7001 is classified as obsolete, while the MUC-20PFFR-JS7002 maintains active product status. For new designs and ongoing production, the MUC-20PFFR-JS7002 is the appropriate selection to ensure long-term supply chain continuity and manufacturer support.

Compliance Advantage: The substitute part carries ROHS3 compliance certification compared to RoHS compliance for the main part, representing enhanced regulatory alignment. The substitute also includes REACH Unaffected status, providing additional environmental compliance documentation.

Mechanical Differentiation: The primary mechanical distinction is the mounting feature: the main part includes a Board Guide, while the substitute incorporates a Board Lock mechanism. Both features serve to secure the connector to the PCB during assembly; the Board Lock provides enhanced retention characteristics.

Current Rating Documentation: The substitute part explicitly specifies current ratings of 1A and 1.8A, whereas the main part does not document this parameter. This specification clarification in the substitute part provides additional design verification data.
