MPX2053GVP Equivalent & Substitute Parts

Part Overview

The MPX2053GVP is a vented gauge pressure sensor manufactured by NXP USA Inc., designed for board mount applications requiring precise pressure measurement in the 7.25 PSI (50 kPa) range. This component features a Wheatstone Bridge output configuration with temperature compensation and operates across an extended temperature range of -40°C to 125°C. The part is currently classified as obsolete, making identification of functionally equivalent alternatives essential for ongoing system support and new design implementations.

Substiute Parts

MPX2053GVP

NXP USA Inc.In Stock: 830MPX2053GVP Datasheet

Current PartRFQ

MPX2050GP

NXP USA Inc.In Stock: 1483MPX2050GP Datasheet

Parametric EquivalentRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution eligibility for the MPX2053GVP is determined by strict equivalence across the following critical parameters:

• Operating Pressure: 7.25 PSI (50 kPa)
• Maximum Pressure: 29.01 PSI (200 kPa)
• Output Type: Wheatstone Bridge
• Output Range: 0 mV ~ 40 mV (10V)
• Supply Voltage: 10V ~ 16V
• Pressure Type: Vented Gauge
• Port Size: Male - 0.19" (4.93 mm) Tube
• Port Style: Barbed
• Operating Temperature: -40°C ~ 125°C
• Package / Case: 4-SIP Module
• Mounting Type: Through Hole
• Termination Style: PC Pin
• Temperature Compensation: Required

The MPX2050GP meets all these criteria and qualifies as a parametric equivalent substitute. The primary distinction is product status: MPX2050GP is active in production, whereas MPX2053GVP is obsolete.

Parameter Comparison

Engineering Selection Recommendations

The MPX2050GP is the direct parametric equivalent for the obsolete MPX2053GVP. Both components maintain identical electrical and mechanical specifications across all critical parameters. The MPX2050GP is currently in active production status, ensuring long-term availability and supply chain continuity.

Both parts maintain ROHS3 compliance and REACH unaffected status, satisfying regulatory requirements for current manufacturing standards. The MPX2050GP is supplied in tray packaging, which may differ from the original part's packaging configuration but does not affect functional compatibility or performance characteristics.

Frequently Asked Questions (FAQ)

Q: Can MPX2050GP be used as a direct replacement for MPX2053GVP?

A: Yes. The MPX2050GP meets all electrical and mechanical specifications of the MPX2053GVP, including pressure range, output characteristics, supply voltage, port configuration, and operating temperature range. Both components are identical in functional performance.

Q: What is the primary reason to substitute MPX2053GVP with MPX2050GP?

A: The MPX2053GVP is classified as obsolete, while the MPX2050GP is in active production. This substitution ensures continued component availability and supply chain reliability for new designs and system maintenance.

Q: Are there any differences in compliance or certifications between these parts?

A: Both parts maintain ROHS3 compliance and REACH unaffected status. No compliance differences exist between the two components.

Q: Does the packaging difference (tray for MPX2050GP) affect compatibility?

A: Packaging format does not affect electrical or mechanical compatibility. The tray packaging of MPX2050GP is a supply-chain consideration only and does not impact component performance or board-level integration.

Q: What are the critical parameters that define substitution eligibility for this pressure sensor?

A: Substitution eligibility is determined by equivalence in operating pressure (7.25 PSI), maximum pressure (29.01 PSI), output type (Wheatstone Bridge), output range (0-40 mV at 10V), supply voltage (10-16V), port configuration (male barbed 0.19" tube), operating temperature range (-40°C to 125°C), package type (4-SIP module), and temperature compensation feature.
