MP6543GL-Z Equivalent & Substitute Parts

Part Overview

The MP6543GL-Z is an active, fully integrated multiphase motor driver PMIC manufactured by Monolithic Power Systems Inc. This component functions as a three-phase power stage with integrated control and power delivery for brushless DC (BLDC) motor applications. The device operates across a 3V to 12V supply range with 2A output current capability and is housed in a 24-QFN (3x4) surface mount package.

Substitute parts are necessary when the primary part number becomes unavailable due to inventory constraints, supply chain disruptions, or specific packaging and delivery requirements. All substitute parts listed maintain identical electrical specifications and functional performance while differing only in packaging format (Cut Tape versus Tape & Reel) and internal device variants.

Substiute Parts

MP6543GL-Z

Monolithic Power Systems Inc.In Stock: 55299MP6543GL-Z Datasheet

Current PartRFQ

MP6543AGL-P

Monolithic Power Systems Inc.In Stock: 1182MP6543AGL-P Datasheet

Parametric EquivalentRFQ

MP6543AGL-Z

Monolithic Power Systems Inc.In Stock: 5803MP6543AGL-Z Datasheet

Parametric EquivalentRFQ

MP6543BGL-P

Monolithic Power Systems Inc.In Stock: 1580MP6543BGL-P Datasheet

Parametric EquivalentRFQ

MP6543BGL-Z

Monolithic Power Systems Inc.In Stock: 5607MP6543BGL-Z Datasheet

Parametric EquivalentRFQ

MP6543GL-P

Monolithic Power Systems Inc.In Stock: 1433MP6543GL-P Datasheet

Parametric EquivalentRFQ

Key Parameters

Substitute Part Grouping Explanation

All substitute parts for the MP6543GL-Z share the same base product number (MP6543) and maintain identical electrical and functional specifications. Substitution is determined by the following parameters:

Electrical Equivalence Criteria:

• Output current: 2A
• Supply voltage range: 3V ~ 12V
• Operating temperature range: -40°C ~ 125°C (TJ)
• Output configuration: Half Bridge (3)
• Interface: PWM
• Technology: NMOS

Physical Equivalence Criteria:

• Package type: 24-VFQFN Exposed Pad
• Supplier device package: 24-QFN (3x4)
• Mounting type: Surface Mount

Regulatory Equivalence Criteria:

• RoHS3 Compliance
• REACH Unaffected status
• MSL Level 1 (Unlimited)

The substitute parts differ only in packaging format (Cut Tape versus Tape & Reel) and internal device variant designations (A or B series). These differences do not affect electrical performance or functional compatibility in circuit applications.

Parameter Comparison

Engineering Selection Recommendations

All substitute parts are manufactured by Monolithic Power Systems Inc. and maintain active product status. Each part is ROHS3 compliant and REACH unaffected, meeting current regulatory requirements for electronic component manufacturing and distribution.

Selection between the MP6543GL-Z and its substitutes should be based on packaging requirements and inventory availability:

Cut Tape (CT) Packaging Options:

• MP6543GL-Z: Primary part number with highest inventory (55200 pcs)
• MP6543BGL-P: Alternative Cut Tape variant (1512 pcs)
• MP6543BGL-Z: Alternative Cut Tape variant (5514 pcs)

Tape & Reel (TR) Packaging Options:

• MP6543AGL-P: Tape & Reel variant (1149 pcs)
• MP6543AGL-Z: Tape & Reel variant (5746 pcs)
• MP6543GL-P: Tape & Reel variant (1421 pcs)

All parts are electrically and functionally equivalent for BLDC motor driver applications requiring 2A output current, 3V to 12V supply operation, and PWM control interface in a 24-QFN surface mount package.
