MMT-102-01-T-SH-TR Equivalent & Substitute Parts

Part Overview

The MMT-102-01-T-SH-TR is an active surface mount rectangular connector header manufactured by Samtec Inc. This 2-position, right-angle header operates across -55°C to 105°C and is designed for board-to-board or cable applications with a 3A current rating. Finding equivalent and substitute parts is necessary to ensure design flexibility, manage supply chain continuity, and accommodate manufacturing process variations while maintaining electrical and mechanical compatibility.

Substiute Parts

MMT-102-01-T-SH-TR

Samtec Inc.In Stock: 962MMT-102-01-T-SH-TR Datasheet

Current PartRFQ

MMT-102-01-T-SH-P-TR

Samtec Inc.In Stock: 1637MMT-102-01-T-SH-P-TR Datasheet

SimilarRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution eligibility for the MMT-102-01-T-SH-TR is determined by strict equivalence across the following critical parameters:

• Connector Type: Header
• Contact Type: Male Pin
• Number of Positions: 2
• Pitch - Mating: 0.079" (2.00mm)
• Mounting Type: Surface Mount, Right Angle
• Termination: Solder
• Current Rating: 3A
• Operating Temperature: -55°C ~ 105°C
• Material Flammability Rating: UL94 V-0
• RoHS Status: ROHS3 Compliant
• Moisture Sensitivity Level: 1 (Unlimited)

The identified substitute part maintains all critical electrical and mechanical parameters, with the only documented difference being the inclusion of a Pick and Place feature in the substitute variant.

Parameter Comparison

Engineering Selection Recommendations

Both MMT-102-01-T-SH-TR and MMT-102-01-T-SH-P-TR are active products from Samtec Inc. with identical electrical and mechanical specifications. Both are ROHS3 compliant and carry UL94 V-0 material flammability certification. The MMT-102-01-T-SH-P-TR variant includes Pick and Place capability, which may provide manufacturing process advantages in automated assembly environments. Selection between these parts should be based on assembly process requirements and current inventory availability.

Frequently Asked Questions (FAQ)

Q: Are MMT-102-01-T-SH-TR and MMT-102-01-T-SH-P-TR electrically interchangeable?

A: Yes. Both parts share identical electrical specifications including 2-position configuration, 0.079" (2.00mm) pitch, 3A current rating, and -55°C to 105°C operating temperature range.

Q: What is the difference between these two part numbers?

A: The MMT-102-01-T-SH-P-TR includes Pick and Place features. All other electrical, mechanical, and compliance parameters are identical.

Q: Can I use MMT-102-01-T-SH-P-TR as a direct replacement for MMT-102-01-T-SH-TR?

A: Yes. The substitute part maintains all critical parameters required for board-to-board or cable applications with identical current handling, temperature range, and compliance certifications.

Q: Are both parts available in the same packaging?

A: Yes. Both parts are supplied in Tape & Reel (TR) packaging format.

Q: Do both parts have the same moisture sensitivity level?

A: Yes. Both parts are rated MSL 1 (Unlimited), indicating no moisture sensitivity restrictions.
