MMF003153 Strain Gauge Equivalent & Substitute Parts

Part Overview

The MMF003153 is a Tee Rosette Strain Gauge manufactured by Micro-Measurements (Division of Vishay Precision Group). This component is designed for multi-axis strain measurement applications requiring simultaneous data collection across three perpendicular directions. The part operates within a ±5% strain range with 350 Ohm resistance and is rated for temperatures from -100°F to 350°F (-75°C to 175°C).

The MMF003153 is classified as obsolete. Locating equivalent substitute parts is necessary to maintain design continuity and ensure availability for new production builds, repairs, and system upgrades where this gauge configuration is specified.

Substiute Parts

MMF003153

Micro-Measurements (Division of Vishay Precision Group)In Stock: 1102MMF003153 Datasheet

Current PartRFQ

MMF403924

VPG Micro-MeasurementsIn Stock: 854MMF403924 Datasheet

MFR RecommendedRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution of the MMF003153 is determined by strict equivalence across the following critical parameters:

Electrical Specifications: Resistance value (350 Ohms), strain range (±5%), and operating temperature range (-100°F to 350°F) must remain constant. These parameters define the gauge's measurement capability and environmental suitability.

Mechanical Specifications: Pattern type (Tee Rosette), active dimensions per section (0.125" × 0.165"), and overall pattern footprint (0.325" × 0.365") must match exactly. These dimensions ensure physical compatibility with mounting fixtures and data acquisition systems designed for the original part.

Series Classification: The CEA series designation confirms the gauge family and construction method.

Compliance Requirements: RoHS compliance and Moisture Sensitivity Level 1 status must be maintained for regulatory and reliability purposes.

The substitute part MMF403924 meets all these criteria while offering improved product status and enhanced resistance tolerance.

Parameter Comparison

Engineering Selection Recommendations

Primary Substitute: MMF403924

The MMF403924 is the direct equivalent substitute for the MMF003153. All critical electrical and mechanical parameters are identical, ensuring drop-in compatibility with existing designs and measurement systems.

Advantages of MMF403924:

The substitute part offers active product status, indicating current manufacturing support and long-term availability. Resistance tolerance is improved to ±0.2% compared to the original ±0.4%, providing enhanced measurement precision. ROHS3 compliance represents current regulatory alignment, whereas the original part carries RoHS Compliant status. Both parts maintain identical Moisture Sensitivity Level 1 classification.

Selection Basis:

Selection of MMF403924 is based on functional equivalence across all specified parameters combined with superior product lifecycle status and compliance posture. The improved resistance tolerance provides additional measurement accuracy without requiring design modification.

Frequently Asked Questions (FAQ)

Q: Can MMF403924 be used as a direct replacement for MMF003153 in existing assemblies?

A: Yes. All critical dimensions, electrical specifications, and operating parameters are identical. The substitute part requires no design changes or recalibration of measurement systems.

Q: What is the difference in resistance tolerance between these parts?

A: The MMF003153 specifies ±0.4% resistance tolerance, while MMF403924 specifies ±0.2%. The substitute part offers tighter tolerance, resulting in improved measurement accuracy and reduced calibration drift over time.

Q: Are there packaging differences between MMF003153 and MMF403924?

A: The original part is packaged as a unit quantity of 5 pieces. The substitute part is supplied in bulk packaging. Both contain identical gauge components; packaging format differs only in presentation and handling.

Q: Does the substitute part meet current regulatory requirements?

A: Yes. MMF403924 carries ROHS3 Compliant status, representing current regulatory alignment. The original MMF003153 carries RoHS Compliant status. Both parts are compliant with applicable environmental regulations.

Q: Are the operating temperature ranges identical?

A: Yes. Both parts operate across the identical temperature range of -100°F to 350°F (-75°C to 175°C), ensuring equivalent thermal performance in all specified applications.

Q: What is the significance of the CEA series designation?

A: The CEA series identifies the gauge family and construction methodology. Both parts belong to the CEA series, confirming identical gauge design and manufacturing process.

Q: Why is the original part classified as obsolete?

A: The MMF003153 is no longer in active production. The MMF403924 represents the current production equivalent, ensuring continued availability and manufacturing support for this gauge configuration.
