M40-6201546 Equivalent & Substitute Parts

Part Overview

The M40-6201546 is a 15-position rectangular connector receptacle manufactured by Harwin Inc., designed for surface mount applications with outer shroud contacts. This component is classified as obsolete, which necessitates identification of active equivalent parts to maintain design continuity and ensure supply chain availability for new production runs and field replacements.

Substiute Parts

M40-6201546

Harwin Inc.In Stock: 723M40-6201546 Datasheet

Current PartRFQ

M40-6201546R

Harwin Inc.In Stock: 702M40-6201546R Datasheet

MFR RecommendedRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution eligibility for the M40-6201546 is determined by strict equivalence across the following critical parameters:

• Connector type and shroud configuration (Receptacle, Outer Shroud Contacts)
• Contact count and arrangement (15 positions, 2 rows)
• Contact pitch (0.039" / 1.00mm)
• Mounting technology (Surface Mount)
• Contact finish specification (Tin, 80.0µin thickness)
• Mechanical envelope (4.3mm mated stacking height, 0.130" height above board)
• Functional features (Board Guide, Solder Retention)
• Regulatory compliance (ROHS3, REACH Unaffected)

The M40-6201546R qualifies as a direct substitute based on full alignment with all specified parameters. The primary distinction is product status: the original part is obsolete, while the substitute is active.

Parameter Comparison

Engineering Selection Recommendations

The M40-6201546R is the direct equivalent for the obsolete M40-6201546. Both parts maintain identical electrical and mechanical specifications, with full parameter alignment across connector configuration, contact arrangement, pitch, mounting method, and contact finish.

The M40-6201546R carries active product status, ensuring ongoing manufacturer support, availability, and compliance maintenance. Both parts satisfy ROHS3 and REACH regulatory requirements, with no compliance differentiation between the original and substitute.

Selection of the M40-6201546R eliminates obsolescence risk while preserving complete design compatibility with existing applications and PCB layouts designed for the M40-6201546.

Frequently Asked Questions (FAQ)

Q: Can the M40-6201546R be used as a direct replacement for the M40-6201546?

A: Yes. The M40-6201546R is electrically and mechanically identical to the M40-6201546 across all specified parameters, including contact count, pitch, mounting type, and mechanical envelope. No design modifications are required.

Q: What is the primary reason for substitution?

A: The M40-6201546 is classified as obsolete. The M40-6201546R is the active equivalent, ensuring supply chain continuity and manufacturer support.

Q: Are there any compliance differences between these parts?

A: No. Both parts are ROHS3 compliant and REACH unaffected. Regulatory status is identical.

Q: Will the M40-6201546R fit existing PCB layouts designed for the M40-6201546?

A: Yes. Mechanical envelope specifications are identical, including mated stacking height (4.3mm) and height above board (0.130"). PCB footprints and assembly processes require no modification.

Q: Are the contact finish specifications the same?

A: Yes. Both parts feature tin contact finish with 80.0µin (2.03µm) thickness, ensuring equivalent electrical performance and solderability.
