M22-2525005 Equivalent & Substitute Parts

Part Overview

The M22-2525005 is a rectangular connector header manufactured by Harwin Inc., designed for through-hole board-to-board applications with 100 positions at 2.00mm pitch. This connector features male pins with gold-plated mating contacts, phosphor bronze material, and operates across -40°C to 105°C. The part is classified as obsolete, making equivalent substitutes necessary for new designs and ongoing production support.

Key Parameters

Parameter	M22-2525005 Value
Pitch - Mating	0.079" (2.00mm)
Number of Positions	100
Number of Rows	2
Connector Type	Header, Cuttable
Contact Type	Male Pin
Mounting Type	Through Hole
Termination	Solder
Contact Material	Phosphor Bronze
Contact Finish - Mating	Gold
Current Rating	1A per Contact
Operating Temperature	-40°C ~ 105°C
Material Flammability Rating	UL94 V-0
RoHS Status	ROHS3 Compliant

Substitute Part Grouping Explanation

Substitution for the M22-2525005 is determined by strict alignment of core electrical and mechanical parameters:

Primary Substitution Criteria:

Pitch - Mating: 0.079" (2.00mm) — exact match required
Number of Positions: 100 — exact match required
Number of Rows: 2 — exact match required
Connector Type: Header, Cuttable — exact match required
Contact Type: Male Pin — exact match required
Mounting Type: Through Hole — exact match required
Termination: Solder — exact match required
Contact Material: Phosphor Bronze — exact match required
Material Flammability Rating: UL94 V-0 — exact match required
RoHS Status: ROHS3 Compliant — exact match required

Secondary Variation Parameters (Allowed Differences):

Contact Finish - Mating: Gold or Tin acceptable
Contact Length - Mating: Variation permitted within mechanical envelope
Contact Length - Post: Variation permitted based on application requirements
Overall Contact Length: Variation permitted
Insulation Material: Polyamide (PA6T) or Liquid Crystal Polymer (LCP) acceptable
Operating Temperature: Higher range acceptable (-55°C ~ 125°C exceeds -40°C ~ 105°C requirement)
Current Rating: Higher rating acceptable (3A exceeds 1A requirement)

The M22-2025005 (Harwin Inc., active status) is a direct manufacturer upgrade. The MTMM series (Samtec Inc., active status) provides cross-manufacturer alternatives with enhanced electrical performance and extended temperature range.

Parameter Comparison

Parameter	M22-2525005	M22-2025005	MTMM-150-02-G-D-115	MTMM-150-02-G-D-127	MTMM-150-02-G-D-151	MTMM-150-02-T-D-120	MTMM-150-02-T-D-146	MTMM-150-03-G-D-126	MTMM-150-03-G-D-150-001	MTMM-150-03-S-D-132	MTMM-150-04-G-D-120
Manufacturer	Harwin Inc.	Harwin Inc.	Samtec Inc.	Samtec Inc.	Samtec Inc.	Samtec Inc.	Samtec Inc.	Samtec Inc.	Samtec Inc.	Samtec Inc.	Samtec Inc.
Product Status	Obsolete	Active	Active	Active	Active	Active	Active	Active	Active	Active	Active
Pitch - Mating	0.079" (2.00mm)	0.079" (2.00mm)	0.079" (2.00mm)	0.079" (2.00mm)	0.079" (2.00mm)	0.079" (2.00mm)	0.079" (2.00mm)	0.079" (2.00mm)	0.079" (2.00mm)	0.079" (2.00mm)	0.079" (2.00mm)
Number of Positions	100	100	100	100	100	100	100	100	100	100	100
Number of Rows	2	2	2	2	2	2	2	2	2	2	2
Connector Type	Header, Cuttable	Header, Cuttable	Header, Cuttable	Header, Cuttable	Header, Cuttable	Header, Cuttable	Header, Cuttable	Header, Cuttable	Header, Cuttable	Header, Cuttable	Header, Cuttable
Contact Type	Male Pin	Male Pin	Male Pin	Male Pin	Male Pin	Male Pin	Male Pin	Male Pin	Male Pin	Male Pin	Male Pin
Mounting Type	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole
Termination	Solder	Solder	Solder	Solder	Solder	Solder	Solder	Solder	Solder	Solder	Solder
Contact Material	Phosphor Bronze	Phosphor Bronze	Phosphor Bronze	Phosphor Bronze	Phosphor Bronze	Phosphor Bronze	Phosphor Bronze	Phosphor Bronze	Phosphor Bronze	Phosphor Bronze	Phosphor Bronze
Contact Finish - Mating	Gold	Gold	Gold	Gold	Gold	Tin	Tin	Gold	Gold	Gold	Gold
Contact Length - Mating	0.138" (4.60mm)	0.138" (4.60mm)	0.115" (2.92mm)	0.127" (3.23mm)	0.151" (3.84mm)	0.120" (3.05mm)	0.146" (3.71mm)	0.126" (3.20mm)	0.150" (3.81mm)	0.132" (3.35mm)	0.120" (3.05mm)
Contact Length - Post	0.091" (2.30mm)	0.134" (3.40mm)	0.081" (2.06mm)	0.069" (1.75mm)	0.045" (1.14mm)	0.076" (1.93mm)	0.050" (1.27mm)	0.117" (2.97mm)	0.093" (2.35mm)	0.111" (2.82mm)	0.144" (3.66mm)
Overall Contact Length	0.287" (7.30mm)	0.331" (8.40mm)	0.255" (6.48mm)	0.255" (6.48mm)	0.255" (6.48mm)	0.255" (6.48mm)	0.255" (6.48mm)	0.302" (7.67mm)	0.302" (7.67mm)	0.302" (7.67mm)	0.323" (8.20mm)
Insulation Height	0.059" (1.50mm)	0.059" (1.50mm)	0.059" (1.50mm)	0.059" (1.50mm)	0.059" (1.50mm)	0.059" (1.50mm)	0.059" (1.50mm)	0.059" (1.50mm)	0.059" (1.50mm)	0.059" (1.50mm)	0.059" (1.50mm)
Insulation Material	Polyamide (PA6T), Nylon 6T	Polyamide (PA6T), Nylon 6T	Liquid Crystal Polymer (LCP)	Liquid Crystal Polymer (LCP)	Liquid Crystal Polymer (LCP)	Liquid Crystal Polymer (LCP)	Liquid Crystal Polymer (LCP)	Liquid Crystal Polymer (LCP)	Liquid Crystal Polymer (LCP)	Liquid Crystal Polymer (LCP)	Liquid Crystal Polymer (LCP)
Operating Temperature	-40°C ~ 105°C	-40°C ~ 105°C	-55°C ~ 125°C	-55°C ~ 125°C	-55°C ~ 125°C	-55°C ~ 105°C	-55°C ~ 105°C	-55°C ~ 125°C	-55°C ~ 125°C	-55°C ~ 125°C	-55°C ~ 125°C
Material Flammability Rating	UL94 V-0	UL94 V-0	UL94 V-0	UL94 V-0	UL94 V-0	UL94 V-0	UL94 V-0	UL94 V-0	UL94 V-0	UL94 V-0	UL94 V-0
Current Rating	1A per Contact	1A per Contact	3A	3A	3A	3A	3A	3A	3A	3A	3A
RoHS Status	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant
Inventory Status	778 Pcs New Original	1358 Pcs New Original	1017 Pcs New Original	766 Pcs New Original	1059 Pcs New Original	1012 Pcs New Original	1094 Pcs New Original	714 Pcs New Original	804 Pcs New Original	768 Pcs New Original	659 Pcs New Original

Engineering Selection Recommendations

M22-2025005 (Harwin Inc., Active Status)

The M22-2025005 is the manufacturer-recommended direct upgrade from the obsolete M22-2525005. Both parts share identical core specifications: 100-position, 2.00mm pitch, male pin header with through-hole solder termination. The M22-2025005 maintains the same operating temperature range (-40°C ~ 105°C), gold contact finish, and UL94 V-0 flammability rating. The primary difference is extended contact post length (0.134" vs. 0.091"), resulting in increased overall contact length (0.331" vs. 0.287"). This part is actively manufactured and recommended for direct replacement in existing designs.

MTMM Series (Samtec Inc., Active Status)

The MTMM-150 series provides cross-manufacturer alternatives with enhanced electrical performance. All MTMM variants meet the core substitution criteria: 100-position, 2.00mm pitch, male pin header, through-hole solder termination, phosphor bronze contacts, and UL94 V-0 flammability rating. Key advantages include higher current rating (3A vs. 1A per contact) and extended operating temperature range (-55°C ~ 125°C for gold-plated variants, -55°C ~ 105°C for tin-plated variants). MTMM parts use Liquid Crystal Polymer (LCP) insulation instead of polyamide, offering improved dimensional stability.

Contact Length Variants:

MTMM parts are available in multiple contact length configurations to accommodate different PCB thicknesses and mating depths:

MTMM-150-02-G-D-115, -127, -151: 2-row configuration with varying mating contact lengths (0.115" to 0.151")
MTMM-150-03-G-D-126, -150-001, -03-S-D-132: 3-row configuration with extended overall contact length (0.302" vs. 0.255")
MTMM-150-04-G-D-120: 4-row configuration with maximum overall contact length (0.323")

Contact Finish Selection:

Gold-plated variants (MTMM-150-02-G-D, MTMM-150-03-G-D, MTMM-150-04-G-D) provide superior corrosion resistance and are recommended for general applications. Tin-plated variants (MTMM-150-02-T-D) offer cost optimization for non-corrosive environments with reduced operating temperature range (-55°C ~ 105°C).

Frequently Asked Questions (FAQ)

Q: Can M22-2025005 be used as a direct replacement for M22-2525005?

A: Yes. The M22-2025005 is the manufacturer-recommended active replacement. Both parts share identical pitch (2.00mm), position count (100), row configuration (2), contact type (male pin), mounting method (through-hole), and termination (solder). The M22-2025005 has extended contact post length, which does not affect compatibility with standard mating connectors.

Q: What are the key differences between Harwin M22 and Samtec MTMM series?

A: Both series meet the core 100-position, 2.00mm pitch, male pin header specification. Primary differences include: (1) Current rating: MTMM provides 3A per contact vs. M22 1A per contact; (2) Operating temperature: MTMM gold-plated variants extend to -55°C ~ 125°C vs. M22 -40°C ~ 105°C; (3) Insulation material: MTMM uses Liquid Crystal Polymer (LCP) vs. M22 polyamide (PA6T); (4) Contact finish options: MTMM offers both gold and tin finishes; M22-2025005 is gold-only.

Q: How do I select the correct MTMM contact length variant?

A: Contact length selection depends on PCB thickness and connector mating depth requirements. MTMM-150-02 variants (overall length 0.255") are suitable for standard PCB applications. MTMM-150-03 variants (overall length 0.302") accommodate thicker PCBs or deeper mating requirements. MTMM-150-04 variant (overall length 0.323") provides maximum engagement depth. Consult PCB layout and mating connector specifications to determine appropriate variant.

Q: Are all substitute parts RoHS3 compliant?

A: Yes. M22-2025005 and all MTMM-150 variants are ROHS3 compliant, meeting the same regulatory requirements as the original M22-2525005.

Q: What is the difference between gold-plated and tin-plated MTMM contacts?

A: Gold-plated MTMM variants (MTMM-150-02-G-D, MTMM-150-03-G-D, MTMM-150-04-G-D) provide superior corrosion resistance and extended operating temperature range (-55°C ~ 125°C). Tin-plated variants (MTMM-150-02-T-D) operate at -55°C ~ 105°C and are suitable for cost-sensitive applications in non-corrosive environments.

Q: Can MTMM-150-03-G-D-150-001 be used if only 99 positions are loaded?

A: MTMM-150-03-G-D-150-001 is specified with 99 positions loaded. This variant is suitable only for applications requiring 99-position configuration. For full 100-position requirements, use MTMM-150-03-G-D-126 or other variants with all 100 positions loaded.

Q: What is the inventory availability for these parts?

A: M22-2025005 has 1358 pieces in stock. MTMM variants range from 659 to 1094 pieces in stock. All parts are listed as new original inventory.
