LZP-W0MD00-0000 LED Module Equivalent & Substitute Parts

Part Overview

The LZP-W0MD00-0000 is an ams OSRAM LuxiGen™ RGBW LED module featuring red, green, blue, and cool white (6500K) color channels in a round configuration. This module is classified as obsolete, making identification of active equivalent parts essential for ongoing production and design continuity. The substitute part LZP-W0MD00-0000_G2 represents the manufacturer-recommended active replacement, maintaining functional compatibility while offering updated specifications and current availability.

Substiute Parts

LZP-W0MD00-0000

ams OSRAMIn Stock: 904LZP-W0MD00-0000 Datasheet

Current PartRFQ

LZP-W0MD00-0000_G2

ams-OSRAM USA INC.In Stock: 1118LZP-W0MD00-0000_G2 Datasheet

MFR RecommendedRFQ

Key Parameters

Substitute Part Grouping Explanation

The LZP-W0MD00-0000_G2 qualifies as a manufacturer-recommended substitute based on the following substitution criteria:

Matching Parameters:

• RGBW color channel configuration (Red, Green, Blue, White)
• Round module geometry
• Domed lens type
• Maximum current rating (1A)
• RoHS3 compliance
• REACH unaffected status
• ECCN EAR99 classification
• HTSUS 8541.41.0000 tariff code

Status Transition: The substitute part transitions from obsolete (LZP-W0MD00-0000) to active product status (LZP-W0MD00-0000_G2), ensuring long-term supply chain viability and manufacturer support.

Parameter Comparison

Engineering Selection Recommendations

Primary Selection: LZP-W0MD00-0000_G2

The LZP-W0MD00-0000_G2 is the manufacturer-recommended substitute and should be selected for new designs and production continuity. This part maintains active product status with ams-OSRAM USA INC., ensuring ongoing technical support, supply availability, and compliance documentation.

Mechanical Considerations: The substitute exhibits dimensional variations (47.00mm diameter vs. 49.00mm, 8.10mm height vs. 7.62mm). Mechanical integration must account for these changes in mounting fixtures, optical paths, and thermal management designs.

Compliance Status: Both parts maintain EAR99 export classification and HTSUS 8541.41.0000 tariff coding, ensuring consistent regulatory treatment across supply chain transitions.

Frequently Asked Questions (FAQ)

Q: Can LZP-W0MD00-0000_G2 directly replace LZP-W0MD00-0000 in existing designs?

A: Functional compatibility is established through matching RGBW color configuration, round geometry, and domed lens type. Mechanical integration requires evaluation due to dimensional differences (diameter and height variations). Optical performance and thermal characteristics must be assessed within the specific application context.

Q: What are the key substitution criteria for this LED module category?

A: Substitution is determined by color channel configuration (RGBW), physical form factor (round), lens type (domed), and maximum current rating (1A). These parameters define functional interchangeability for the LuxiGen™ product family.

Q: Why is the original part classified as obsolete?

A: Product status reflects manufacturer lifecycle decisions. The LZP-W0MD00-0000_G2 represents the active continuation of this product line, ensuring supply chain continuity and access to current manufacturing processes.

Q: Are there dimensional constraints for substitution?

A: Yes. The substitute part measures 47.00mm diameter (vs. 49.00mm) and 8.10mm height (vs. 7.62mm). Applications with tight mechanical tolerances or specific optical requirements must validate these dimensional changes.

Q: What compliance certifications apply to both parts?

A: Both parts maintain EAR99 export classification and HTSUS 8541.41.0000 tariff coding. RoHS3 compliance is documented for the original part; compliance status for the substitute should be confirmed through current technical documentation.
