LCAX8-56F-L Equivalent & Substitute Parts

Part Overview

The LCAX8-56F-L is a rectangular tongue terminal connector manufactured by Panduit Corp, designed for 8 AWG wire termination onto a 5/16 stud. This component is classified as obsolete, which necessitates identification of active equivalent parts to maintain supply chain continuity. The terminal features non-insulated copper construction with electro-tin contact finish, suitable for applications requiring reliable electrical connections in free-hanging or in-line mounting configurations.

Substiute Parts

LCAX8-56F-L

Panduit CorpIn Stock: 1250LCAX8-56F-L Datasheet

Current PartRFQ

LCAX8-56-L

Panduit CorpIn Stock: 1055LCAX8-56-L Datasheet

SimilarRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution of the LCAX8-56F-L is determined by strict equivalence across the following critical parameters:

Wire gauge (8 AWG) and stud size (5/16) establish the primary electrical and mechanical interface requirements. Terminal type (rectangular tongue), termination method (crimp, barrel), and contact specifications (copper with electro-tin finish) must remain identical to ensure functional compatibility. Dimensional parameters including ring ID (0.340"), barrel ID (0.180"), barrel OD (0.270"), tab thickness (0.050"), and width (0.560") define the physical fit within the assembly. Insulation status (non-insulated) and color (red) are preserved across substitutes. Compliance certifications (ROHS3, REACH Unaffected) must be maintained.

The substitute part LCAX8-56-L matches all critical parameters with the exception of product status (active versus obsolete) and packaging configuration (bulk versus original packaging). The mounting type differs slightly (free hanging in-line versus free hanging in-line with right angle option on the main part), and overall length specification is provided for the substitute.

Parameter Comparison

Engineering Selection Recommendations

The LCAX8-56-L serves as the direct substitute for the obsolete LCAX8-56F-L. Both components maintain identical electrical and mechanical specifications across all critical parameters: 8 AWG wire gauge, 5/16 stud interface, rectangular tongue terminal type, crimp barrel termination, and copper construction with electro-tin finish.

The primary distinction is product status: LCAX8-56-L is currently active in Panduit's product line, ensuring ongoing availability and supply chain reliability. Both parts carry ROHS3 compliance and REACH unaffected status, meeting current regulatory requirements.

The mounting type specification differs between the two parts. The main part (LCAX8-56F-L) includes right angle mounting capability in addition to free hanging in-line configuration, while the substitute (LCAX8-56-L) specifies free hanging in-line mounting only. This difference requires verification against specific application mounting requirements.

Packaging differs between the parts: the main part is supplied in original packaging, while the substitute is available in bulk packaging. This distinction affects inventory management and handling procedures but does not impact electrical or mechanical performance.

Frequently Asked Questions (FAQ)

Q: Can LCAX8-56-L directly replace LCAX8-56F-L in all applications?

A: LCAX8-56-L matches all critical electrical and mechanical parameters with LCAX8-56F-L. However, the mounting type specification differs. The main part supports both free hanging in-line and right angle mounting, while the substitute supports free hanging in-line mounting only. Verify that your application does not require right angle mounting capability before substitution.

Q: What are the key parameters that determine substitution eligibility?

A: Wire gauge (8 AWG), stud size (5/16), terminal type (rectangular tongue), termination method (crimp barrel), contact material (copper), contact finish (electro-tin), insulation status (non-insulated), and all dimensional specifications (ring ID, barrel ID, barrel OD, tab thickness, width) must match exactly. Compliance certifications (ROHS3, REACH) must be maintained.

Q: Does the packaging difference affect component performance?

A: No. Packaging configuration (original versus bulk) does not affect electrical or mechanical performance. The difference is administrative and relates to inventory handling and supply chain logistics only.

Q: Are both parts compliant with current regulations?

A: Yes. Both LCAX8-56F-L and LCAX8-56-L are ROHS3 compliant and REACH unaffected, meeting current regulatory requirements for electronic components.

Q: Why is the main part listed as obsolete?

A: The LCAX8-56F-L is classified as obsolete in Panduit's product portfolio. The LCAX8-56-L represents the active equivalent, ensuring continued availability and support for applications requiring this terminal specification.

Q: What is the difference in overall length between the two parts?

A: The main part (LCAX8-56F-L) does not specify overall length in the provided data. The substitute (LCAX8-56-L) specifies 1.320" (33.53mm) overall length. Confirm that this dimension is compatible with your application space constraints.
