LCAX650-38H-6 Equivalent & Substitute Parts

Part Overview

The LCAX650-38H-6 is a terminal connector manufactured by Panduit Corp, classified as a rectangular tongue terminal designed for 650 MCM (kcmil) wire gauge applications with a 3/8 stud connection. This component is part of the Pan-Lug™ series and features a non-insulated copper construction with electro-tin contact finish. The part is currently listed as obsolete, necessitating identification of active equivalent alternatives to maintain supply chain continuity for applications requiring this terminal specification.

Substiute Parts

LCAX650-38H-6

Panduit CorpIn Stock: 1191LCAX650-38H-6 Datasheet

Current PartRFQ

LCAX650-38-6

Panduit CorpIn Stock: 799LCAX650-38-6 Datasheet

SimilarRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution of the LCAX650-38H-6 is determined by strict equivalence across the following critical parameters:

Wire Gauge Compatibility: The substitute part must accommodate 650 MCM (kcmil) wire gauge to ensure proper current-carrying capacity and mechanical fit within the barrel crimp area.

Stud/Tab Size: The 3/8 stud specification is mandatory for mechanical compatibility with mating hardware and assembly configurations.

Terminal Geometry: Rectangular tongue terminal type with single stud hole configuration must be maintained to ensure proper mounting and electrical connection.

Electrical Characteristics: Copper contact material with electro-tin finish ensures equivalent electrical conductivity and corrosion resistance properties.

Mechanical Dimensions: Barrel inner diameter (1.050"), barrel outer diameter (1.350"), ring inner diameter (0.410"), and tab thickness (0.300") must remain constant to maintain crimp tool compatibility and mechanical integrity.

Regulatory Compliance: ROHS3 compliance and REACH unaffected status must be preserved for applications subject to environmental regulations.

The LCAX650-38-6 meets all these criteria and is identified as the active equivalent substitute for the obsolete LCAX650-38H-6.

Parameter Comparison

Engineering Selection Recommendations

The LCAX650-38-6 is the direct equivalent substitute for the obsolete LCAX650-38H-6. Both components share identical electrical and mechanical specifications across all critical parameters that determine functional compatibility.

Product Status Consideration: The LCAX650-38-6 maintains active product status with Panduit Corp, ensuring continued availability and manufacturing support. The LCAX650-38H-6 is obsolete and no longer manufactured.

Regulatory Compliance: Both parts maintain ROHS3 compliance and REACH unaffected status, satisfying environmental and regulatory requirements for applications in regulated industries.

Packaging Difference: The LCAX650-38-6 is supplied in bulk packaging, whereas the original part number does not specify packaging format. This distinction does not affect electrical or mechanical performance.

Mounting Configuration Difference: The LCAX650-38H-6 specifies 45° angle mounting type, while the LCAX650-38-6 specifies free hanging (in-line) mounting type. This difference reflects the physical orientation capability of the terminal but does not alter the core electrical or mechanical compatibility for applications where the mounting angle is not a constraint.

For applications requiring the specific 45° angle mounting configuration of the original part, the mounting angle difference must be evaluated against application requirements.

Frequently Asked Questions (FAQ)

Q: Can LCAX650-38-6 be used as a direct replacement for LCAX650-38H-6?

A: Yes. The LCAX650-38-6 is electrically and mechanically equivalent to the LCAX650-38H-6 across all critical parameters including wire gauge, stud size, barrel dimensions, and contact specifications. The primary difference is product status (active versus obsolete) and mounting configuration (free hanging in-line versus 45° angle).

Q: What is the significance of the mounting type difference between these parts?

A: The LCAX650-38H-6 is specified for 45° angle mounting, while the LCAX650-38-6 is specified for free hanging (in-line) mounting. This refers to the physical orientation of the terminal during installation. Applications requiring a specific mounting angle must evaluate whether the in-line configuration of the substitute part is compatible with the assembly design.

Q: Are the electrical characteristics identical between these parts?

A: Yes. Both parts feature copper contact material with electro-tin finish, identical barrel dimensions (1.050" ID, 1.350" OD), and equivalent current-carrying capacity for 650 MCM wire gauge applications.

Q: What is the difference in packaging between these parts?

A: The LCAX650-38-6 is supplied in bulk packaging. Packaging format does not affect the electrical or mechanical performance of the terminal itself.

Q: Are both parts compliant with environmental regulations?

A: Yes. Both the LCAX650-38H-6 and LCAX650-38-6 are ROHS3 compliant and REACH unaffected, meeting environmental regulatory requirements.

Q: Why is the LCAX650-38H-6 listed as obsolete?

A: The LCAX650-38H-6 is no longer manufactured by Panduit Corp. The LCAX650-38-6 represents the active product line continuation with equivalent specifications.

Q: Can these terminals be used with the same crimp tools?

A: Yes. Both terminals feature identical barrel dimensions and tab thickness, ensuring compatibility with the same crimp tool specifications for 650 MCM wire gauge applications.

Q: What wire gauge does this terminal accommodate?

A: Both the LCAX650-38H-6 and LCAX650-38-6 are designed for 650 MCM (kcmil) wire gauge applications.
