LCAS3/0-56F-X Equivalent & Substitute Parts

Part Overview

The LCAS3/0-56F-X is a rectangular tongue terminal connector manufactured by Panduit Corp, designed for 3/0 AWG wire gauge applications with a 5/16 stud connection. This component is classified as obsolete, indicating discontinuation from active production. The part functions as a crimp barrel terminal for high-amperage electrical connections in industrial and power distribution applications. Due to its obsolete status, identification of active equivalent parts is necessary to maintain supply chain continuity and ensure project completion without design modifications.

Substiute Parts

LCAS3/0-56F-X

Panduit CorpIn Stock: 1010LCAS3/0-56F-X Datasheet

Current PartRFQ

LCA3/0-56F-X

Panduit CorpIn Stock: 992LCA3/0-56F-X Datasheet

SimilarRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution eligibility for the LCAS3/0-56F-X is determined by strict equivalence across all critical electrical and mechanical parameters. The substitute part must match the following criteria:

Wire gauge specification of 3/0 AWG ensures compatibility with the intended conductor cross-section. The 5/16 stud size establishes the connection interface and cannot be altered. Terminal type classification as rectangular tongue defines the physical form factor and mounting configuration. Termination method as crimp barrel specifies the assembly process and electrical connection mechanism. Dimensional parameters including tab thickness (0.130"), barrel inner diameter (0.510"), barrel outer diameter (0.640"), and ring inner diameter (0.340") establish mechanical fit and electrical performance boundaries. Contact material composition of copper and electro-tin finish ensure electrical conductivity and corrosion resistance. Non-insulated classification indicates the absence of dielectric coating. ROHS3 compliance confirms environmental regulatory adherence.

The substitute part LCA3/0-56F-X meets all these parameters and is classified as active product status, providing continued availability and supply chain reliability.

Parameter Comparison

Engineering Selection Recommendations

The LCA3/0-56F-X is the direct equivalent substitute for the obsolete LCAS3/0-56F-X. Both parts are manufactured by Panduit Corp and belong to the Pan-Lug™ series. The substitute part maintains identical electrical and mechanical specifications across all critical parameters, ensuring direct interchangeability without circuit or assembly modifications.

The primary distinction between the two parts is product status: LCAS3/0-56F-X is obsolete, while LCA3/0-56F-X is active. This status change reflects manufacturing continuity and ongoing availability. Both parts carry ROHS3 compliance certification, confirming adherence to environmental and hazardous substance restrictions. The substitute part is available in bulk packaging with 971 pieces in current inventory, providing supply security for production requirements.

Selection of the LCA3/0-56F-X substitute eliminates obsolescence risk and ensures long-term component availability for maintenance, repair, and new production applications.
