JR13WR-5P(71) Equivalent & Substitute Parts

Part Overview

The JR13WR-5P(71) is a 5-position circular connector receptacle with male pins, manufactured by Hirose Electric Co Ltd. This panel-mount connector features solder cup termination, aluminum alloy construction with black chromium finish, and silver-plated contacts. It is rated for 5A at 100VAC or 140VDC with IP67/IP68 ingress protection suitable for automotive, industrial, and telecommunications applications.

The JR13WR-5P(71) is classified as obsolete. Identifying equivalent substitute parts ensures design continuity and supply chain reliability for applications currently using this connector.

Substiute Parts

JR13WR-5P(71)

Hirose Electric Co LtdIn Stock: 912JR13WR-5P(71) Datasheet

Current PartRFQ

JR13WR-5P(31)

Hirose Electric Co LtdIn Stock: 923JR13WR-5P(31) Datasheet

DirectRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution of the JR13WR-5P(71) is based on electrical and mechanical compatibility within the JR-W series. The substitute part JR13WR-5P(31) maintains identical specifications across all critical parameters that determine functional interchangeability:

• Connector type, pin configuration, and position count
• Shell size, material composition, and finish specifications
• Mounting method, fastening mechanism, and orientation
• Electrical ratings (current, voltage, temperature range)
• Ingress protection and flammability certification
• Contact material and finish specifications

The primary distinction is product status: JR13WR-5P(31) is active production, whereas JR13WR-5P(71) is obsolete. Both parts are manufactured by Hirose Electric Co Ltd within the same JR-W series.

Parameter Comparison

Engineering Selection Recommendations

The JR13WR-5P(31) is the direct substitute for the obsolete JR13WR-5P(71). Both connectors are manufactured by Hirose Electric Co Ltd and share identical electrical, mechanical, and environmental specifications. The JR13WR-5P(31) is in active production status, ensuring long-term availability and supply chain continuity.

The JR13WR-5P(31) carries RoHS compliance certification, providing additional regulatory alignment for new designs and manufacturing processes. Both parts maintain EAR99 export classification and identical HTSUS commodity codes.

For applications currently specified with JR13WR-5P(71), direct substitution with JR13WR-5P(31) is supported across all electrical, mechanical, and environmental operating parameters.

Frequently Asked Questions (FAQ)

Q: Are JR13WR-5P(71) and JR13WR-5P(31) electrically interchangeable?

A: Yes. Both connectors are rated for 5A at 100VAC or 140VDC with identical contact materials, finishes, and thickness specifications. Operating temperature range, voltage withstand, and current capacity are identical.

Q: What is the difference between these two part numbers?

A: The primary difference is product status. JR13WR-5P(71) is obsolete; JR13WR-5P(31) is in active production. JR13WR-5P(31) includes RoHS compliance certification. All other specifications are identical.

Q: Can I use JR13WR-5P(31) in place of JR13WR-5P(71) in existing designs?

A: Yes. The connectors are mechanically and electrically identical. Panel mounting, flange configuration, solder cup termination, and keyed orientation are the same. No design modifications are required.

Q: Are there packaging differences between these parts?

A: JR13WR-5P(71) is supplied in standard packaging; JR13WR-5P(31) is supplied in bulk packaging. Both are new original stock from Hirose Electric Co Ltd.

Q: Do both connectors meet the same environmental and compliance standards?

A: Yes. Both are rated IP67/IP68 for ingress protection, UL94 V-0 for flammability, and EAR99 for export classification. JR13WR-5P(31) additionally carries RoHS compliance.
