JBXHC2G08FSSDSR Equivalent & Substitute Parts

Part Overview

The JBXHC2G08FSSDSR is an 8-position circular connector receptacle manufactured by Souriau-Sunbank by Eaton. This female socket connector features solder cup termination, gold-plated mating contacts, and is rated for 10A at 830V. The connector is designed for panel mount applications with bulkhead mounting capability and provides IP68 ingress protection. The product is currently active in production with 931 units in stock. Equivalent and substitute parts are identified when alternative connectors meet the functional requirements for specific applications while maintaining compliance with relevant electrical and mechanical standards.

Substiute Parts

JBXHC2G08FSSDSR

Souriau-Sunbank by EatonIn Stock: 1029JBXHC2G08FSSDSR Datasheet

Current PartRFQ

1424177

Phoenix ContactIn Stock: 23771424177 Datasheet

SimilarRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution of the JBXHC2G08FSSDSR is evaluated based on the following critical parameters:

Functional Equivalence Criteria:

• Connector type must be receptacle with female sockets
• Position count must be 8
• Contact finish must be gold-plated for mating surfaces
• Termination must support solder connection methods
• Mounting configuration must support panel mount installation

Electrical Compatibility Criteria:

• Current rating must meet or exceed 10A
• Voltage rating must meet or exceed 830V
• Operating temperature range must encompass -40°C to 125°C

Environmental & Compliance Criteria:

• Ingress protection rating must be IP67 or higher
• Material flammability rating must be UL94 V-0
• RoHS3 compliance required

The substitute part 1424177 (Phoenix Contact DSI series) shares the core functional characteristics of an 8-position female socket receptacle with gold-plated contacts and solder termination. However, this substitute exhibits reduced electrical ratings (0.5A at 50VAC/60VDC versus 10A at 830V) and a lower ingress protection rating (IP67 versus IP68), making it suitable only for applications with lower power requirements and less stringent environmental sealing demands.

Parameter Comparison

Engineering Selection Recommendations

Primary Part Selection (JBXHC2G08FSSDSR): The JBXHC2G08FSSDSR is the specified component for applications requiring high-voltage operation (830V), high-current capacity (10A), extended temperature range (-40°C to 125°C), and maximum ingress protection (IP68). This connector is suitable for industrial, instrumentation, medical, and telecommunications applications. The product maintains active production status with ROHS3 compliance and REACH unaffected designation.

Substitute Part Consideration (1424177): The Phoenix Contact 1424177 is applicable only in applications where electrical requirements are significantly reduced. The 0.5A current rating and 50VAC/60VDC voltage specification restrict this substitute to low-power signal and data applications. The IP67 rating remains suitable for most sealed environments, though not equivalent to IP68. The operating temperature maximum of 85°C limits use in high-temperature applications. This substitute maintains ROHS3 compliance but carries REACH affected status, requiring additional regulatory review for specific end-use applications.

Selection Logic: Choose the JBXHC2G08FSSDSR for standard industrial and high-power applications. Select the 1424177 substitute only when application requirements explicitly permit reduced electrical ratings and lower temperature operation, and when REACH affected status is acceptable for the end application.

Frequently Asked Questions (FAQ)

Q: Can the 1424177 substitute directly replace the JBXHC2G08FSSDSR in all applications?

A: No. The 1424177 has significantly reduced electrical ratings (0.5A versus 10A; 50VAC/60VDC versus 830V). Direct substitution is only valid for applications with low-power requirements that do not exceed these electrical limits.

Q: What is the primary difference in ingress protection between these connectors?

A: The JBXHC2G08FSSDSR provides IP68 (dust tight, waterproof) protection, while the 1424177 provides IP67 (dust tight, waterproof). IP68 offers a higher sealing standard suitable for submersion applications.

Q: Are both connectors RoHS compliant?

A: Both connectors are ROHS3 compliant. However, the 1424177 carries REACH affected status, while the JBXHC2G08FSSDSR is REACH unaffected. Applications subject to REACH regulations must account for this difference.

Q: What is the temperature operating range difference?

A: The JBXHC2G08FSSDSR operates from -40°C to 125°C, while the 1424177 operates from -40°C to 85°C. Applications requiring operation above 85°C require the primary part.

Q: Do both connectors use the same termination method?

A: Both use solder termination. The JBXHC2G08FSSDSR specifies solder cup termination, while the 1424177 specifies solder termination. Both are compatible with standard solder assembly processes.

Q: What is the difference in fastening type?

A: The JBXHC2G08FSSDSR uses push-pull fastening, while the 1424177 uses push-twist fastening. These represent different mating and unmating mechanisms and are not interchangeable in the field.

Q: Are the shell sizes compatible?

A: The JBXHC2G08FSSDSR uses shell size 2, while the 1424177 uses M12-8. These are different mechanical form factors and are not physically interchangeable.
