IPD1-24-S-R Equivalent & Substitute Parts

Part Overview

The IPD1-24-S-R is a 24-position rectangular connector housing manufactured by Samtec Inc. as part of the Mini Mate® IPD1 series. This receptacle connector features a 0.100" (2.54mm) pitch and is designed for free-hanging, in-line applications with crimp termination and latch lock fastening. The part is actively produced and ROHS3 compliant, making it suitable for applications requiring standard rectangular connector housings with female socket contacts.

Substitute parts are identified when equivalent electrical and mechanical parameters are met, allowing for component interchangeability in designs where specific manufacturer preference is not mandated.

Substiute Parts

IPD1-24-S-R

Samtec Inc.In Stock: 979IPD1-24-S-R Datasheet

Current PartRFQ

2-104257-3

TE Connectivity AMP ConnectorsIn Stock: 7852-104257-3 Datasheet

Parametric EquivalentRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitute parts for the IPD1-24-S-R are identified based on strict equivalence of the following critical parameters:

• Connector Type: Receptacle
• Contact Type: Female Socket
• Number of Positions: 24
• Pitch: 0.100" (2.54mm)
• Number of Rows: 1
• Mounting Type: Free Hanging (In-Line)
• Contact Termination: Crimp
• Fastening Type: Latch Lock
• RoHS Status: ROHS3 Compliant
• Moisture Sensitivity Level: 1 (Unlimited)

The substitute part 2-104257-3 meets all these electrical and mechanical criteria, establishing functional interchangeability for applications where these parameters define the design requirement.

Parameter Comparison

Engineering Selection Recommendations

Both the IPD1-24-S-R and 2-104257-3 are active products with ROHS3 compliance and MSL 1 ratings, confirming their suitability for current production applications. The primary distinction between these parts is insulation material composition and color. The IPD1-24-S-R uses Polyamide (PA66), Nylon 6/6, while the 2-104257-3 uses Thermoplastic insulation. Both materials are suitable for standard rectangular connector applications. The operating temperature range is specified for the TE Connectivity part (-65°C ~ 105°C) but not provided for the Samtec part. Selection between these substitutes should be based on design requirements for insulation material, color specification, and temperature operating range if critical to the application.

Frequently Asked Questions (FAQ)

Q: Can the 2-104257-3 be used as a direct replacement for the IPD1-24-S-R?

A: Yes, the 2-104257-3 meets all critical electrical and mechanical parameters: 24-position receptacle, 0.100" pitch, female socket contacts, crimp termination, latch lock fastening, and equivalent compliance ratings. Both parts are ROHS3 compliant with MSL 1 ratings.

Q: What are the differences between these two parts?

A: The primary differences are insulation material (Polyamide PA66 versus Thermoplastic), housing color (White versus Black), and specified operating temperature range (-65°C ~ 105°C for the TE part). These differences do not affect electrical or mechanical interchangeability for standard applications.

Q: Are contacts included with these connector housings?

A: No. Both the IPD1-24-S-R and 2-104257-3 are housings only. Contacts must be sourced separately and crimped into the housing.

Q: Do these parts have the same pitch and position count?

A: Yes. Both parts feature 24 positions with a 0.100" (2.54mm) pitch in a single-row configuration, ensuring mechanical and electrical compatibility.

Q: What is the significance of MSL 1 rating?

A: MSL 1 (Moisture Sensitivity Level 1) indicates unlimited shelf life with no special moisture control requirements during storage or handling, making these parts suitable for standard warehouse and production environments.
