IACM-5 AC Input Module Equivalent & Substitute Parts

Part Overview

The IACM-5 is an AC Input Module manufactured by TE Connectivity Potter & Brumfield Relays, designed to convert 120VAC input signals to 5VDC output for control and logic applications. This module operates at 6mA input current with 18mA output current capacity and features 20ms turn-on and 30ms turn-off response times. The product is Active status and ROHS3 Compliant, making it suitable for current procurement and deployment in industrial control systems. Equivalent substitute parts are identified to provide alternative sourcing options when the primary part is unavailable or when packaging requirements differ.

Substiute Parts

IACM-5

TE Connectivity Potter & Brumfield RelaysIn Stock: 936IACM-5 Datasheet

Current PartRFQ

M-IAC5

Sensata-CrydomIn Stock: 1024M-IAC5 Datasheet

DirectRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution eligibility for the IACM-5 is determined by strict equivalence across the following critical parameters:

Input Specifications: Voltage input must be 120VAC with input current of 6mA. These parameters define the signal detection capability and must match exactly for direct substitution.

Output Specifications: Output voltage must be 5VDC. Output current capacity must be sufficient to support the application load. The IACM-5 provides 18mA output current.

Timing Characteristics: Turn-on and turn-off response times define system responsiveness. The IACM-5 specifies 20ms turn-on and 30ms turn-off times.

Form Factor: Mini style and yellow color are physical identifiers that support mechanical compatibility in standard mounting configurations.

Compliance: ROHS3 Compliant status is required for regulatory alignment in current manufacturing environments.

The M-IAC5 from Sensata-Crydom meets all critical electrical input and output voltage specifications. Output current capacity is 16mA, which is lower than the IACM-5's 18mA rating. Turn-off time is 20ms compared to the IACM-5's 30ms, representing faster response. These differences must be evaluated against specific application requirements.

Parameter Comparison

Engineering Selection Recommendations

Both the IACM-5 and M-IAC5 are Active status products with ROHS3 Compliance, confirming suitability for current industrial applications and regulatory requirements.

IACM-5 Selection Criteria: Choose the IACM-5 when output current capacity of 18mA is required and turn-off response time of 30ms aligns with system timing specifications. Bulk packaging is appropriate for high-volume procurement or internal inventory management.

M-IAC5 Selection Criteria: The M-IAC5 is suitable when output current requirements do not exceed 16mA and faster turn-off response of 20ms is compatible with application timing. Tray packaging supports smaller quantity orders or just-in-time supply chain models.

Both modules accept identical 120VAC input signals and produce 5VDC output, ensuring functional compatibility at the signal interface level. Differences in output current capacity and turn-off timing must be evaluated against specific load and timing requirements of the target application.

Frequently Asked Questions (FAQ)

Q: Can the M-IAC5 directly replace the IACM-5 in all applications?

A: Direct replacement is possible only when the application output current requirement does not exceed 16mA and the faster 20ms turn-off time is acceptable. Applications requiring the full 18mA output current capacity or the 30ms turn-off timing of the IACM-5 require evaluation of the M-IAC5's reduced specifications.

Q: What is the significance of the packaging difference between Bulk and Tray?

A: Bulk packaging is used for large quantity orders and internal stock management, while Tray packaging is designed for smaller quantity shipments and automated handling systems. The packaging format does not affect electrical performance or functional compatibility.

Q: Are both modules compliant with current regulatory standards?

A: Yes. Both the IACM-5 and M-IAC5 are ROHS3 Compliant, confirming compliance with current environmental and hazardous substance restrictions applicable to electronic components.

Q: What are the critical parameters that must match for substitution?

A: Input voltage (120VAC), input current (6mA), and output voltage (5VDC) must match exactly. Output current capacity and timing characteristics must be evaluated against application requirements to determine if differences are acceptable.

Q: Do both modules have the same physical form factor?

A: Yes. Both modules are Mini style with yellow color, ensuring mechanical compatibility in standard mounting configurations and visual identification consistency.
