H-2000L LED RED CLEAR 5MM ROUND T/H Equivalent & Substitute Parts

Part Overview

The H-2000L is a red LED indication component manufactured by Stanley Electric Co, designed for through-hole mounting in 5mm T-1 3/4 form factor applications. This part operates at 1.8V forward voltage with a 2000mcd luminous intensity and 647nm dominant wavelength. The H-2000L is classified as obsolete, making identification of functionally equivalent substitute components necessary for ongoing design support, production continuity, and system maintenance.

Key Parameters

Parameter	H-2000L Value	Specification Basis
Color	Red	Visual indication requirement
Lens Size	5mm, T-1 3/4	Physical form factor and mounting compatibility
Lens Style	Round with Domed Top	Optical and mechanical design
Lens Transparency	Clear	Optical transmission characteristic
Mounting Type	Through Hole	PCB assembly method
Package / Case	Radial	Lead configuration
Voltage - Forward (Vf) Typical	1.8V	Circuit design parameter
Current - Test	20mA	Operating current specification
Millicandela Rating	2000mcd	Luminous intensity
Wavelength - Dominant	647nm	Color specification
Viewing Angle	10°	Optical beam pattern
Height (Max)	10.70mm	Physical clearance requirement

Substitute Part Grouping Explanation

Substitute parts for the H-2000L are identified based on strict parameter alignment within the following categories:

Primary Substitution Criteria:

Color: Red (mandatory match)
Lens Size: 5mm or T-1 3/4 form factor (mandatory match)
Mounting Type: Through Hole (mandatory match)
Package / Case: Radial (mandatory match)
Lens Style: Round with Domed Top (mandatory match)
Lens Transparency: Clear (mandatory match)

Secondary Compatibility Parameters:

Voltage - Forward (Vf): Range 1.8V to 2.2V (acceptable operational variance)
Current - Test: 20mA (standard test condition)
Wavelength - Dominant: 623nm to 648nm (red spectrum range)

Substitute Classification:

Direct Substitutes (Closest electrical and mechanical alignment):

TLDR5800 (Vishay): Vf 1.8V, 2500mcd, 648nm wavelength, 8° viewing angle
7343-2SURC/H2/S400-A8 (Everlight): Vf 2V, 2000mcd, 624nm wavelength, 30° viewing angle

Compatible Substitutes (Acceptable parameter variance within operational limits):

151053RS03000 (Würth Elektronik): Vf 1.9V, 5000mcd, 623nm wavelength, 30° viewing angle
333-2SURC/S400-A8 (Everlight): Vf 2V, 5000mcd, 624nm wavelength, 10° viewing angle
383-2SURC/S400-A6 (Everlight): Vf 2V, 6300mcd, 624nm wavelength, 6° viewing angle
383-2SURC/S530-A3 (Everlight): Vf 2V, 2500mcd, 624nm wavelength, 6° viewing angle
383-2SURC/S530-A6 (Everlight): Vf 2V, 6300mcd, 624nm wavelength, 6° viewing angle
7343-2SURC/H2/S400-A7 (Everlight): Vf 2V, 1600mcd, 624nm wavelength, 30° viewing angle

Limited Compatibility (Significant parameter deviation):

383-2SDRC/S530-A4 (Everlight): Vf 2V, 2780mcd, 639nm wavelength, 6° viewing angle, narrower viewing angle
5219464F (Dialight): Vf 2.2V, 125mcd, 635nm wavelength, 24° viewing angle, significantly lower luminous intensity

Parameter Comparison

Part Number	Manufacturer	Vf (Typ)	mcd	Wavelength (nm)	Viewing Angle	Height (Max)	Product Status	RoHS Status
H-2000L	Stanley Electric Co	1.8V	2000	647	10°	10.70mm	Obsolete	Not specified
TLDR5800	Vishay Semiconductor Opto	1.8V	2500	648	8°	13.00mm	Active	ROHS3 Compliant
151053RS03000	Würth Elektronik	1.9V	5000	623	30°	8.85mm	Active	ROHS3 Compliant
333-2SURC/S400-A8	Everlight Electronics	2V	5000	624	10°	8.90mm	Active	ROHS3 Compliant
383-2SDRC/S530-A4	Everlight Electronics	2V	2780	639	6°	8.90mm	Active	Not specified
383-2SURC/S400-A6	Everlight Electronics	2V	6300	624	6°	8.90mm	Active	ROHS3 Compliant
383-2SURC/S530-A3	Everlight Electronics	2V	2500	624	6°	8.90mm	Active	ROHS3 Compliant
383-2SURC/S530-A6	Everlight Electronics	2V	6300	624	6°	8.90mm	Active	Not specified
5219464F	Dialight	2.2V	125	635	24°	8.81mm	Active	ROHS3 Compliant
7343-2SURC/H2/S400-A7	Everlight Electronics	2V	1600	624	30°	8.85mm	Active	ROHS3 Compliant
7343-2SURC/H2/S400-A8	Everlight Electronics	2V	2000	624	30°	8.85mm	Active	ROHS3 Compliant

Engineering Selection Recommendations

For Direct Replacement (Minimum Design Modification):

TLDR5800 (Vishay Semiconductor Opto Division) is the primary direct substitute. This part maintains the 1.8V forward voltage specification of the H-2000L, ensuring compatibility with existing circuit designs without modification. The TLDR5800 provides 2500mcd luminous intensity compared to the H-2000L's 2000mcd, representing a 25% increase in brightness within acceptable operational parameters. The wavelength specification of 648nm is within the red spectrum range and visually indistinguishable from the original 647nm. The TLDR5800 is Active status with ROHS3 compliance and unlimited moisture sensitivity rating (MSL 1), supporting long-term supply chain continuity.

For Applications Tolerating Forward Voltage Increase (1.8V to 2V):

7343-2SURC/H2/S400-A8 (Everlight Electronics) provides an exact 2000mcd luminous intensity match to the H-2000L. This part operates at 2V forward voltage, requiring circuit verification to confirm the 0.2V increase does not exceed design margins. The 7343-2SURC/H2/S400-A8 offers a 30° viewing angle compared to the H-2000L's 10°, providing wider light distribution. This part is Active status with ROHS3 compliance.

For Applications Requiring Higher Luminous Intensity:

333-2SURC/S400-A8 (Everlight Electronics) and 383-2SURC/S400-A6 (Everlight Electronics) provide 5000mcd and 6300mcd respectively, supporting applications requiring increased brightness. Both operate at 2V forward voltage. The 333-2SURC/S400-A8 maintains the 10° viewing angle of the H-2000L, while the 383-2SURC/S400-A6 provides a narrower 6° viewing angle. Both are Active status with ROHS3 compliance.

Compliance Considerations:

All recommended substitute parts are ROHS3 compliant and carry EAR99 ECCN classification, matching the regulatory status of the H-2000L. All substitute parts are classified as REACH Unaffected. Moisture sensitivity levels for active substitutes are specified as MSL 1 (Unlimited), supporting standard storage and handling conditions.

Frequently Asked Questions (FAQ)

Q: Can TLDR5800 be used as a direct drop-in replacement for H-2000L?

A: Yes. The TLDR5800 maintains the 1.8V forward voltage specification and 5mm T-1 3/4 through-hole radial package of the H-2000L. No circuit modification is required. The 2500mcd luminous intensity is 25% higher than the H-2000L's 2000mcd, which is acceptable for indication applications. The 648nm wavelength is within the red spectrum and visually equivalent to the 647nm original specification.

Q: What is the impact of forward voltage differences between H-2000L (1.8V) and substitute parts operating at 2V?

A: A 0.2V increase in forward voltage requires circuit verification. For series resistor-limited designs, the higher forward voltage reduces current through the resistor, potentially decreasing LED brightness. For constant-current driver designs, the voltage difference is absorbed by the driver circuit with no impact on LED current or brightness. Verify your circuit topology before substitution.

Q: Why do some substitutes have significantly higher millicandela ratings (5000mcd to 6300mcd) compared to H-2000L (2000mcd)?

A: Higher millicandela ratings indicate greater luminous intensity. These parts are suitable for applications requiring brighter indication or longer viewing distances. If your application requires the original 2000mcd specification, select 7343-2SURC/H2/S400-A8 (2000mcd) or 383-2SURC/S530-A3 (2500mcd) instead.

Q: What is the significance of viewing angle differences (6° to 30°)?

A: Viewing angle defines the cone of light distribution. The H-2000L specifies 10°, providing a narrow, focused beam. Substitutes with 6° viewing angles provide even narrower beams suitable for precise indicator positioning. Substitutes with 30° viewing angles provide wider light distribution, suitable for applications where the LED is not directly facing the observer. Verify your optical design requirements before selecting a substitute with significantly different viewing angle.

Q: Are all substitute parts RoHS compliant?

A: All recommended substitute parts are ROHS3 compliant. The H-2000L's RoHS status is not specified in the provided data. All substitutes carry REACH Unaffected status, matching the regulatory classification of the H-2000L.

Q: What is the physical height difference between H-2000L (10.70mm) and substitutes?

A: Most substitutes are shorter (8.85mm to 8.90mm) than the H-2000L (10.70mm), except TLDR5800 (13.00mm). Verify PCB clearance and mechanical constraints in your design. Shorter substitutes may require lead bending adjustment if the original design relied on the H-2000L's specific height for positioning.

Q: Can 5219464F (Dialight) be used as a substitute?

A: 5219464F is not recommended as a primary substitute. This part operates at 2.2V forward voltage and provides only 125mcd luminous intensity, representing a 93.75% reduction compared to the H-2000L's 2000mcd. This part is suitable only for applications where significantly reduced brightness is acceptable and the higher forward voltage is compatible with circuit design.

Q: What inventory status should I consider when selecting a substitute?

A: TLDR5800 has 7632 pcs in stock, providing the highest availability among direct substitutes. 7343-2SURC/H2/S400-A8 has 889 pcs in stock. Everlight parts range from 640 to 906 pcs in stock. Verify current inventory with your supplier before finalizing design selection.
