GT8E-6P-DSA Equivalent & Substitute Parts

Part Overview

The GT8E-6P-DSA is a rectangular connector header manufactured by Hirose Electric Co Ltd, designed for through-hole mounting with 6 positions at 0.079" (2.00mm) pitch. This connector features a shrouded 4-wall design with solder termination and latch lock fastening, suitable for board-to-cable/wire applications.

The GT8E-6P-DSA is classified as obsolete. Locating active equivalent parts ensures design continuity and supply chain reliability for new production runs and maintenance applications.

Substiute Parts

GT8E-6P-DSA

Hirose Electric Co LtdIn Stock: 1106GT8E-6P-DSA Datasheet

Current PartRFQ

GT8E-6P-DSA(55)

Hirose Electric Co LtdIn Stock: 1239GT8E-6P-DSA(55) Datasheet

MFR RecommendedRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution of the GT8E-6P-DSA is determined by strict equivalence across the following critical parameters:

• Connector type (Header)
• Contact type (Male Pin)
• Number of positions (6)
• Pitch - mating (0.079" / 2.00mm)
• Mounting type (Through Hole)
• Shrouding configuration (Shrouded - 4 Wall)
• Termination method (Solder)
• Fastening type (Latch Lock)
• Contact material (Brass)
• Contact finish (Tin on both mating and post surfaces)
• Insulation material compatibility
• Physical dimensions (insulation height, contact length)

The GT8E-6P-DSA(55) meets all these criteria and is classified as an active product, making it a direct functional equivalent suitable for replacement in new designs and production applications.

Parameter Comparison

Engineering Selection Recommendations

The GT8E-6P-DSA(55) is the direct active equivalent for the obsolete GT8E-6P-DSA. Both parts share identical mechanical and electrical interface specifications, ensuring pin-for-pin and footprint compatibility.

The GT8E-6P-DSA(55) offers the following advantages for new designs and production applications:

• Active product status with established supply chain availability
• ROHS3 compliance, meeting current environmental regulations
• Documented operating temperature range (-40°C ~ 105°C) and electrical ratings (1A at 250VAC)
• Enhanced solder retention feature compared to the original board guide design
• Polyamide (PA) nylon insulation material, providing improved mechanical durability

For legacy systems currently using the GT8E-6P-DSA, the GT8E-6P-DSA(55) provides a direct replacement without requiring PCB redesign or connector interface modifications.

Frequently Asked Questions (FAQ)

Q: Can GT8E-6P-DSA(55) be used as a direct replacement for GT8E-6P-DSA?

A: Yes. Both parts are mechanically and electrically identical in all critical interface parameters: 6-position header, 2.00mm pitch, through-hole mounting, shrouded 4-wall design, solder termination, and latch lock fastening. The GT8E-6P-DSA(55) is the active production equivalent.

Q: What is the difference between the insulation materials?

A: The original GT8E-6P-DSA uses Polybutylene Terephthalate (PBT), while the GT8E-6P-DSA(55) uses Polyamide (PA) nylon. Both materials are suitable for the specified application and environmental conditions. The nylon formulation in the substitute part provides enhanced mechanical properties.

Q: Are there any PCB footprint changes?

A: No. The GT8E-6P-DSA(55) maintains identical physical dimensions, including insulation height (0.476" / 12.10mm) and contact post length (0.118" / 3.00mm). Existing PCB designs require no modification.

Q: What compliance certifications apply to the substitute part?

A: The GT8E-6P-DSA(55) is ROHS3 compliant and REACH unaffected. It maintains the same ECCN (EAR99) and HTSUS (8536.69.4040) classifications as the original part.

Q: Are operating temperature and electrical ratings specified for the original part?

A: The GT8E-6P-DSA datasheet does not document operating temperature range or electrical ratings. The GT8E-6P-DSA(55) specifies -40°C ~ 105°C operating temperature and 1A at 250VAC electrical ratings, which are standard for this connector series.

Q: What is the moisture sensitivity level?

A: Both parts carry MSL 1 (Unlimited), indicating no moisture sensitivity restrictions for storage, handling, or assembly.
