GL-2030FV-30 AC Power Connector Equivalent & Substitute Parts

Part Overview

The GL-2030FV-30 is a Power Entry Connector Receptacle manufactured by KEMET, designed for IEC 320-C14 panel mount applications with male blades. This component functions as a filtered AC power inlet for commercial equipment requiring EMI/RFI suppression. The part is classified as Last Time Buy, indicating discontinued production status. Identifying equivalent substitute parts is necessary to ensure continued component availability for maintenance, repair, and new design implementations.

Substiute Parts

GL-2030FV-30

KEMETIn Stock: 1123GL-2030FV-30 Datasheet

Current PartRFQ

F2199CA03

Curtis IndustriesIn Stock: 1104F2199CA03 Datasheet

SimilarRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution eligibility for the GL-2030FV-30 is determined by strict alignment of the following critical parameters:

Mandatory Matching Parameters:

• Connector Style: IEC 320-C14
• Connector Type: Receptacle, Male Blades
• Number of Positions: 3
• Filter Type: Filtered (EMI, RFI) - Commercial
• Current Rating - Filter: 3A
• Mounting Type: Panel Mount, Flange
• Termination: Quick Connect - 0.250" (6.3mm)
• Accommodates a Fuse: No

The substitute part F2199CA03 manufactured by Curtis Industries satisfies all mandatory parameters, establishing functional and mechanical equivalence for direct replacement applications.

Parameter Comparison

Engineering Selection Recommendations

The F2199CA03 from Curtis Industries is a direct functional equivalent to the GL-2030FV-30. Selection criteria are based on the following factors:

Product Status Consideration: The GL-2030FV-30 carries Last Time Buy status, indicating end-of-life production. The F2199CA03 maintains Active product status, ensuring ongoing availability and supply chain continuity.

Compliance and Certification: Both parts maintain ROHS3 compliance and REACH Unaffected status. The F2199CA03 carries expanded regulatory approval including CE certification in addition to CSA, TUV, and UL certifications present on the GL-2030FV-30.

Electrical and Mechanical Compatibility: All critical parameters align identically between the two parts, including connector style, current rating, filtering characteristics, and termination specifications. Panel mount flange configuration and quick connect termination ensure mechanical interchangeability.

Inventory Availability: The F2199CA03 is available in stock (995 Pcs), providing immediate procurement capability for replacement and new applications.

Frequently Asked Questions (FAQ)

Q: Can F2199CA03 be used as a direct replacement for GL-2030FV-30 in existing equipment?

A: Yes. The F2199CA03 matches all critical electrical and mechanical parameters of the GL-2030FV-30, including connector style, current rating, filter type, mounting configuration, and termination method. Panel mount flange dimensions and quick connect terminal specifications are identical.

Q: What is the difference in packaging between these parts?

A: The GL-2030FV-30 is supplied in Tray packaging, while the F2199CA03 is supplied in Box packaging. This difference affects logistics and storage but does not impact component functionality or compatibility.

Q: Are there differences in regulatory approvals between the two parts?

A: The F2199CA03 includes CE certification in addition to the CSA, TUV, and UL certifications shared with the GL-2030FV-30. Both parts maintain ROHS3 compliance and REACH Unaffected status.

Q: Why is the GL-2030FV-30 marked as Last Time Buy?

A: Last Time Buy status indicates that KEMET has discontinued production of this part. The GL-2030FV-30 remains available in current inventory (1026 Pcs), but no future production is planned. The F2199CA03 provides continuity for applications requiring this connector type.

Q: Are the current ratings identical between both parts?

A: Yes. Both the GL-2030FV-30 and F2199CA03 are rated for 3A at the filter stage, with identical filtering characteristics for EMI/RFI suppression in commercial applications.

Q: What are the panel cutout requirements for installation?

A: Both parts accommodate Variable Size panel cutout dimensions. Installation procedures should reference the specific manufacturer documentation for the selected part to ensure proper flange alignment and panel thickness compatibility.
