FCC17B25SN280 Equivalent & Substitute Parts

Part Overview

The FCC17B25SN280 is a 25 Position D-Sub Receptacle connector manufactured by Amphenol ICC (Commercial Products). This through-hole solder-terminated connector features female sockets in a 2-row configuration with Shell Size 3 (DB, B) layout. The part is classified as obsolete, necessitating identification of active equivalent and substitute components for ongoing design and procurement requirements. Substitute parts must maintain electrical and mechanical compatibility while meeting current product availability and compliance standards.

Key Parameters

Parameter	FCC17B25SN280 Value
Connector Type	Receptacle, Female Sockets
Number of Positions	25
Number of Rows	2
Shell Size, Connector Layout	3 (DB, B)
Mounting Type	Through Hole
Termination	Solder
Current Rating (Amps)	5A
Voltage Rating	200V
Operating Temperature Range	-40°C ~ 85°C
Contact Finish	Gold
Shell Material, Finish	Steel, Tin Plated
Flange Feature	Housing/Shell (Unthreaded)

Substitute Part Grouping Explanation

Substitution eligibility for the FCC17B25SN280 is determined by the following critical parameters:

Primary Compatibility Criteria:

Connector Type: Receptacle, Female Sockets
Number of Positions: 25
Number of Rows: 2
Shell Size, Connector Layout: 3 (DB, B)
Mounting Type: Through Hole
Termination: Solder

Secondary Compatibility Criteria:

Current Rating: Minimum 5A
Voltage Rating: Minimum 200V (or unspecified, indicating general-purpose rating)
Operating Temperature Range: Must encompass or exceed -40°C ~ 85°C
Contact Finish: Gold
Material Flammability Rating: UL94 V-0

Substitute parts are grouped into two categories:

Category 1: Direct Equivalents (Same Mounting Type) Parts with identical through-hole vertical solder mounting and unthreaded housing/shell flange feature. These include FCE17B25SN280, 205738-3, 205738-7, 5205738-1, and 5205738-3.

Category 2: Functional Equivalents (Panel Mount Variants) Parts with panel mount through-hole capability and alternative flange features (board-side or mating-side 4-40 threaded). These include 172-025-283L001, 172-025-283L011, 172-025-283L021, and 172-025-283L031 from NorComp Inc.

Parameter Comparison

Part Number	Manufacturer	Connector Type	Positions	Rows	Shell Size	Mounting Type	Termination	Current Rating (A)	Voltage Rating (V)	Operating Temp (°C)	Contact Finish	Shell Material, Finish	Flange Feature	Product Status	RoHS Status
FCC17B25SN280	Amphenol ICC	Receptacle, Female Sockets	25	2	3 (DB, B)	Through Hole	Solder	5	200	-40 ~ 85	Gold	Steel, Tin Plated	Housing/Shell (Unthreaded)	Obsolete	RoHS non-compliant
FCE17B25SN280	Amphenol ICC	Receptacle, Female Sockets	25	2	3 (DB, B)	Through Hole	Solder	5	—	-40 ~ 85	Gold	Steel, Tin Plated	Housing/Shell (Unthreaded)	Active	RoHS Compliant
205738-3	TE Connectivity AMP	Receptacle, Female Sockets	25	2	3 (DB, B)	Through Hole	Solder	6	125	-55 ~ 105	Gold	Steel, Yellow Chromate Plated Zinc	Housing/Shell (Unthreaded)	Active	RoHS non-compliant
205738-7	TE Connectivity AMP	Receptacle, Female Sockets	25	2	3 (DB, B)	Through Hole	Solder	6	125	-55 ~ 105	Gold	Steel, Yellow Chromate Plated Zinc	Housing/Shell (Unthreaded)	Active	RoHS non-compliant
5205738-1	TE Connectivity AMP	Receptacle, Female Sockets	25	2	3 (DB, B)	Through Hole	Solder	6	125	-55 ~ 105	Gold	Steel, Yellow Chromate Plated Zinc	Housing/Shell (Unthreaded)	Active	ROHS3 Compliant
5205738-3	TE Connectivity AMP	Receptacle, Female Sockets	25	2	3 (DB, B)	Through Hole	Solder	6	125	-55 ~ 105	Gold	Steel, Yellow Chromate Plated Zinc	Housing/Shell (Unthreaded)	Active	RoHS Compliant
172-025-283L001	NorComp Inc.	Receptacle, Female Sockets	25	2	3 (DB, B)	Panel Mount, Through Hole	Solder	5	—	-50 ~ 125	Gold	Steel, Nickel Plated	Housing/Shell (Unthreaded)	Active	ROHS3 Compliant
172-025-283L011	NorComp Inc.	Receptacle, Female Sockets	25	2	3 (DB, B)	Panel Mount, Through Hole	Solder	5	—	-50 ~ 125	Gold	Steel, Nickel Plated	Board Side (4-40)	Active	ROHS3 Compliant
172-025-283L021	NorComp Inc.	Receptacle, Female Sockets	25	2	3 (DB, B)	Panel Mount, Through Hole	Solder	5	—	-50 ~ 125	Gold	Steel, Nickel Plated	Board Side (4-40)	Active	ROHS3 Compliant
172-025-283L031	NorComp Inc.	Receptacle, Female Sockets	25	2	3 (DB, B)	Panel Mount, Through Hole	Solder	5	—	-50 ~ 125	Gold	Steel, Nickel Plated	Mating Side (4-40)	Active	ROHS3 Compliant

Engineering Selection Recommendations

For Direct Replacement (Identical Mounting Configuration):

FCE17B25SN280 is the primary recommended substitute. This Amphenol ICC part maintains identical electrical and mechanical specifications to the FCC17B25SN280 while offering active product status and RoHS compliance. The FCE17 series represents the current-generation equivalent within the same manufacturer's product line.

For RoHS Compliance Requirements:

5205738-3 (TE Connectivity AMP Connectors, AMPLIMITE HDP-20 series) provides RoHS compliance with active product status. This part exceeds the original voltage rating (125V vs. 200V specification) and current rating (6A vs. 5A), supporting broader application compatibility. Operating temperature range extends to -55°C ~ 105°C, exceeding the original -40°C ~ 85°C specification.

5205738-1 offers identical electrical and mechanical characteristics to 5205738-3 with ROHS3 compliance and active status, differentiated by packaging (Bulk vs. Tube).

For Panel Mount Applications:

The NorComp Inc. 172-025 series (172-025-283L001, 172-025-283L011, 172-025-283L021, 172-025-283L031) provides panel mount through-hole capability with ROHS3 compliance and active product status. Selection among these variants depends on flange feature requirements:

172-025-283L001: Unthreaded housing/shell flange (closest to original mounting style)
172-025-283L011 and 172-025-283L021: Board-side 4-40 threaded flange
172-025-283L031: Mating-side 4-40 threaded flange

For Legacy Non-Compliant Applications:

205738-3 and 205738-7 (TE Connectivity AMP Connectors, AMPLIMITE HDP-20 series) maintain RoHS non-compliant status matching the original part, with active product availability and enhanced electrical ratings.

Frequently Asked Questions (FAQ)

Q: Can FCE17B25SN280 be used as a direct replacement for FCC17B25SN280?

A: Yes. FCE17B25SN280 maintains identical connector type, position count, row configuration, shell size, mounting type, termination method, current rating, and operating temperature range. The primary difference is product status (Active vs. Obsolete) and RoHS compliance (Compliant vs. non-compliant). Both are Amphenol ICC products with compatible electrical and mechanical specifications.

Q: What is the difference between the TE Connectivity 205738 and 5205738 series?

A: Both series are AMPLIMITE HDP-20 D-Sub receptacles with identical electrical and mechanical specifications (25 positions, 2 rows, Shell Size 3, 6A current rating, 125V voltage rating, -55°C ~ 105°C operating range). The primary distinction is RoHS compliance status: 205738 series is RoHS non-compliant, while 5205738 series is ROHS3 compliant. Packaging differs between variants (Bulk, Tube).

Q: Are NorComp 172-025 series connectors compatible with the original FCC17B25SN280 mounting?

A: NorComp 172-025 series connectors are functionally equivalent in electrical specifications and connector configuration (25 positions, 2 rows, Shell Size 3, 5A current rating, solder termination). However, they feature panel mount through-hole capability with alternative flange options (unthreaded housing, board-side 4-40, or mating-side 4-40), whereas the original FCC17B25SN280 is vertical through-hole with unthreaded housing. Selection depends on specific mounting requirements.

Q: What is the significance of the flange feature differences in the 172-025 series?

A: Flange feature determines the mechanical mounting interface. 172-025-283L001 features unthreaded housing/shell flange, providing the closest mechanical compatibility to the original FCC17B25SN280. 172-025-283L011 and 172-025-283L021 feature board-side 4-40 threaded flanges for panel-mount applications with fastening on the circuit board side. 172-025-283L031 features mating-side 4-40 threaded flange for fastening on the connector mating side. Selection depends on available mounting space and fastening requirements.

Q: Does the voltage rating difference between FCC17B25SN280 (200V) and substitute parts affect compatibility?

A: Substitute parts with lower voltage ratings (125V for TE Connectivity series, unspecified for Amphenol FCE17 and NorComp 172-025 series) are suitable for applications operating at or below their rated voltage. For applications requiring 200V operation, verify that the substitute part's voltage rating meets or exceeds the application requirement. Unspecified voltage ratings in active products typically indicate general-purpose industrial ratings suitable for standard signal applications.

Q: What packaging options are available for substitute parts?

A: Packaging varies by manufacturer and part number. Amphenol FCE17B25SN280 is supplied in standard packaging. TE Connectivity 205738 series is supplied in Bulk packaging, while 5205738-1 is supplied in Bulk and 5205738-3 is supplied in Tube. NorComp 172-025 series is supplied in Tray packaging. Packaging selection affects quantity per container and handling requirements but does not affect electrical or mechanical compatibility.

Q: Are there compliance differences between substitute options?

A: Yes. FCC17B25SN280 is RoHS non-compliant. FCE17B25SN280 is RoHS Compliant. TE Connectivity 205738 series is RoHS non-compliant, while 5205738 series is ROHS3 Compliant. NorComp 172-025 series is ROHS3 Compliant. For applications requiring RoHS compliance, select from FCE17B25SN280, 5205738-1, 5205738-3, or NorComp 172-025 variants. For legacy applications permitting non-compliant components, 205738 series remains available.
