Equivalent & Substitute Parts for ESLM03200

Part Overview

The Amphenol PCD ESLM03200 is a 3-position, horizontal, through-hole terminal block designed for wire-to-board connections in PCB applications. It features a 5.08mm (0.200") pitch and supports a current rating of 13.5A at 300V, accommodating wire gauges from 14 to 30 AWG. Given procurement lead times, inventory variations, and potential sourcing constraints, it can be necessary to identify alternate terminal blocks with matching critical parameters to ensure uninterrupted production and design continuity.

Substiute Parts

ESLM03200

Amphenol PCDIn Stock: 1016ESLM03200 Datasheet

Current PartRFQ

282837-3

TE Connectivity AMP ConnectorsIn Stock: 229749282837-3 Datasheet

SimilarRFQ

EDZ250/3

On Shore Technology Inc.In Stock: 5269EDZ250/3 Datasheet

SimilarRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution is permitted only when the substitute terminal block matches key functional and physical attributes required for compatibility in the original design. For the terminal block category, the primary substitution criteria are: number of positions per level, pin pitch, mating orientation, mounting type, current and voltage ratings, supported wire gauge, wire termination method, and compliance or certification status. All this information is directly sourced from the device datasheets and provided specifications.

Parameter Comparison

Engineering Selection Recommendations

All referenced terminal block part numbers, including Amphenol PCD ESLM03200, TE Connectivity AMP Connectors 282837-3, and On Shore Technology Inc. EDZ250/3, are listed as Active products with RoHS compliance and MSL rating of 1 (Unlimited). All have ECCN classification EAR99 and HTSUS code 8536.90.4000. Substitution should use only those parts that match the compliance status and certification information provided.

Frequently Asked Questions (FAQ)

Q1: What criteria determine whether a terminal block is a valid substitute for ESLM03200?
A1: Substitution is based strictly on matching positions per level, pitch, mating orientation, mounting type, current and voltage ratings, wire terminations, and compliance with RoHS and MSL ratings.

Q2: Does the package type (Tray vs. Bulk) affect substitution?
A2: Package type is not a functional parameter and does not affect electrical or mechanical compatibility for the referenced substitutes.

Q3: Are color or housing material differences relevant to substitution?
A3: Only electrical, mechanical, and compliance parameters provided are considered valid criteria. Color and minor housing material variations are not used for substitution decisions.

Q4: Will substituting terminal blocks affect regulatory certifications or compliance?
A4: All listed substitutes are RoHS compliant, have MSL 1 (Unlimited), ECCN EAR99, and the same HTSUS classification, matching the compliance criteria of the main part.

Q5: How should wire gauge range differences be treated between substitutes?
A5: Only the wire gauge ranges provided are considered; parts must support wire sizes within the specified ranges to be listed as substitutes.
