E3C-GF4 Equivalent & Substitute Parts

Part Overview

The Omron E3C-GF4 is a standard sensor amplifier with bracket mount configuration, designed for photoelectric sensing applications requiring 12V to 24V DC supply with PNP output. This component is classified as obsolete, making identification of functionally equivalent alternatives essential for system maintenance, redesign, and procurement planning. The E3C-GF4 delivers 50 mA supply current and operates across -10°C to 55°C, serving as a reliable interface between photoelectric sensors and control systems in industrial automation environments.

Substiute Parts

E3C-GF4

Omron Automation and SafetyIn Stock: 896E3C-GF4 Datasheet

Current PartRFQ

E3C-JB4P

Omron Automation and SafetyIn Stock: 1123E3C-JB4P Datasheet

SimilarRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution eligibility for the E3C-GF4 is determined by strict alignment of the following critical parameters:

• Voltage Supply Range: 12V ~ 24V (must match exactly)
• Output Type: PNP (must match exactly)
• Current Supply: 50 mA (must match exactly)
• Operating Temperature Range: -10°C ~ 55°C (TA) (must match exactly)
• Amplifier Type: Standard (must match exactly)
• Series: E3C (must match exactly)

The E3C-JB4P qualifies as a functional substitute based on identical electrical specifications across all critical parameters. The primary difference lies in mounting configuration: the E3C-GF4 uses bracket mount, while the E3C-JB4P employs DIN rail mounting. This distinction affects installation methodology but does not alter electrical performance or sensor interface compatibility.

Parameter Comparison

Engineering Selection Recommendations

The E3C-JB4P is the qualified substitute for the obsolete E3C-GF4 based on identical electrical and functional specifications. The E3C-JB4P maintains active product status with Omron, ensuring ongoing availability and support. Both components share identical voltage supply range, output type, current supply, and operating temperature specifications, confirming electrical compatibility.

The E3C-JB4P carries ROHS3 compliance and REACH affected status, providing enhanced environmental and regulatory alignment compared to the E3C-GF4's vendor-undefined REACH status. Both components are classified as MSL 1 (Unlimited), indicating no moisture sensitivity constraints during storage or handling.

Selection between these components depends solely on installation environment requirements: bracket mount configuration for the E3C-GF4 versus DIN rail mounting for the E3C-JB4P. Electrical performance and sensor interface characteristics remain identical across both options.

Frequently Asked Questions (FAQ)

Q: Can the E3C-JB4P directly replace the E3C-GF4 in existing installations?

A: Electrical substitution is complete. Physical installation requires adaptation from bracket mount to DIN rail mounting. Connector interfaces and signal specifications are identical.

Q: What are the critical parameters that determine substitution eligibility?

A: Voltage supply range (12V ~ 24V), output type (PNP), current supply (50 mA), operating temperature range (-10°C ~ 55°C), amplifier type (Standard), and series designation (E3C) must match exactly for functional equivalence.

Q: Why is the E3C-GF4 classified as obsolete?

A: Product status reflects Omron's discontinuation of this specific model. The E3C-JB4P represents the active alternative within the E3C series maintaining identical electrical specifications.

Q: Are there compliance differences between the E3C-GF4 and E3C-JB4P?

A: The E3C-JB4P provides ROHS3 compliance and REACH affected status. The E3C-GF4 lists REACH status as vendor undefined. Both components share identical ECCN and HTSUS classifications.

Q: What is the inventory status for these components?

A: The E3C-GF4 maintains 859 pieces in new original stock. The E3C-JB4P has 1015 pieces available in bulk packaging, supporting higher-volume procurement requirements.
