DRV8847RTER Equivalent & Substitute Parts

Part Overview

The DRV8847RTER is an active, fully integrated bipolar motor driver from Texas Instruments designed for brushed DC and stepper motor applications. This Power Management IC combines control and power stage functionality in a compact 16-WQFN (3x3) surface mount package with exposed pad. The device operates across supply voltages of 0V to 5V and supports load voltages from 2.7V to 18V, delivering 2A output current through a half-bridge (4) output configuration with PWM interface control.

Identifying equivalent and substitute parts is necessary to address inventory constraints, procurement lead times, packaging format requirements, and supply chain optimization while maintaining identical electrical and mechanical performance characteristics.

Substiute Parts

DRV8847RTER

Texas InstrumentsIn Stock: 2470DRV8847RTER Datasheet

Current PartRFQ

DRV8847RTET

Texas InstrumentsIn Stock: 1500DRV8847RTET Datasheet

Parametric EquivalentRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitute parts for the DRV8847RTER are identified based on strict parametric equivalence across all critical electrical and mechanical specifications. The substitution logic is based on the following key parameters that must remain identical:

Electrical Parameters:

• Motor Type (Bipolar stepper and brushed DC capability)
• Output Configuration (Half Bridge with 4 outputs)
• Interface Protocol (PWM control)
• Output Current Rating (2A)
• Supply Voltage Range (0V ~ 5V)
• Load Voltage Range (2.7V ~ 18V)
• Operating Temperature Range (-40°C ~ 125°C)

Mechanical Parameters:

• Package Type (16-WQFN with exposed pad)
• Physical Dimensions (3x3 mm)
• Mounting Technology (Surface Mount)

Compliance Parameters:

• RoHS3 Compliance
• REACH Unaffected Status
• MSL Rating (1 - Unlimited)
• Product Status (Active)

Parts are grouped as substitutes only when all parameters listed above match exactly. Packaging format (bulk versus tape & reel) does not affect electrical or mechanical compatibility and represents the only allowable variation within the substitute group.

Parameter Comparison

Engineering Selection Recommendations

The DRV8847RTET is a direct parametric equivalent to the DRV8847RTER. Both devices are manufactured by Texas Instruments, carry Active product status, and maintain identical electrical specifications, mechanical dimensions, and compliance certifications.

Selection Basis:

The only distinction between these parts is packaging format. The DRV8847RTER is supplied in bulk packaging, while the DRV8847RTET is supplied in Tape & Reel (TR) format. This difference does not affect electrical performance, thermal characteristics, or mechanical compatibility on the PCB.

Compliance Alignment:

Both parts maintain ROHS3 compliance, REACH Unaffected status, and MSL Level 1 (Unlimited moisture sensitivity). Both are classified under ECCN EAR99 and HTSUS 8542.39.0001, ensuring regulatory equivalence for procurement and export purposes.

Inventory Considerations:

Selection between these equivalents should be based on procurement requirements, assembly process specifications, and supply chain availability. The DRV8847RTER (bulk) contains 2400 pieces in current inventory, while the DRV8847RTET (tape & reel) contains 1400 pieces.
