DPP2S1K-F Equivalent & Substitute Parts

Part Overview

The DPP2S1K-F is a 10000 pF film capacitor manufactured by Cornell Dubilier Electronics (CDE) in the DPP series. This radial polypropylene metallized capacitor operates at 250V DC and 140V AC, designed for high-frequency and switching applications. The component is currently in active production status with 977 units in stock. Substitute parts are identified when equivalent capacitance and dielectric material specifications are maintained while accommodating different voltage ratings, tolerances, or application requirements within the same product category.

Substiute Parts

DPP2S1K-F

Cornell Dubilier Electronics (CDE)In Stock: 1011DPP2S1K-F Datasheet

Current PartRFQ

715P10354JD3

Cornell Dubilier Electronics (CDE)In Stock: 1137715P10354JD3 Datasheet

SimilarRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution of the DPP2S1K-F is permissible when the following core parameters remain constant or are exceeded:

Fixed Parameters (Must Match):

• Capacitance: 10000 pF
• Dielectric Material: Polypropylene (PP), Metallized
• Mounting Type: Through Hole
• Termination: PC Pins
• Package / Case: Radial

Allowable Variations:

• Voltage Rating - DC: May be equal to or greater than 250V
• Voltage Rating - AC: May be equal to or greater than 140V
• Tolerance: May be tighter (lower percentage) than ±10%
• Operating Temperature Range: May be equal to or narrower than -55°C ~ 105°C
• RoHS and REACH Compliance: Must maintain or exceed current compliance status

The substitute part 715P10354JD3 meets these criteria with higher voltage ratings (400V DC, 200V AC), tighter tolerance (±5%), and equivalent capacitance and dielectric specifications.

Parameter Comparison

Engineering Selection Recommendations

Primary Part - DPP2S1K-F:

• Select when operating temperature range of -55°C to 105°C is required
• Select when lead spacing of 10.00mm (0.394") is specified in PCB layout
• Select when compact radial form factor with 15.00mm length is required
• Active production status with 977 units in stock

Substitute Part - 715P10354JD3:

• Select when higher voltage margin is required (400V DC vs. 250V DC)
• Select when tighter capacitance tolerance (±5%) is specified
• Select when lead spacing of 9.52mm (0.375") accommodates PCB design
• Select when maximum operating temperature does not exceed 85°C
• Active production status with 1031 units in stock
• Orange Drop® series designation indicates audio and high-pulse application optimization

Both parts maintain ROHS3 compliance and REACH unaffected status. Physical dimension differences require PCB layout verification before substitution.

Frequently Asked Questions (FAQ)

Q: Can the 715P10354JD3 directly replace the DPP2S1K-F in all applications?

A: Direct replacement is possible only when the application does not require the full -55°C to 105°C operating temperature range of the DPP2S1K-F. The 715P10354JD3 operates to 85°C maximum. Additionally, PCB layout must accommodate the different lead spacing (9.52mm vs. 10.00mm) and physical dimensions (17.80mm length vs. 15.00mm length).

Q: What is the significance of the tighter tolerance on the 715P10354JD3?

A: The 715P10354JD3 provides ±5% tolerance compared to ±10% on the DPP2S1K-F. This tighter tolerance results in more precise capacitance values and may be required in applications with strict frequency or filtering specifications. Both parts maintain the same 10000 pF nominal capacitance.

Q: Are there physical space constraints when substituting these parts?

A: Yes. The DPP2S1K-F measures 15.00mm length with 10.00mm lead spacing, while the 715P10354JD3 measures 17.80mm length with 9.52mm lead spacing. PCB layout verification is required to confirm the substitute part fits within available space and lead hole positioning.

Q: Do both parts meet the same regulatory requirements?

A: Yes. Both the DPP2S1K-F and 715P10354JD3 are ROHS3 compliant and REACH unaffected, meeting equivalent environmental and regulatory standards.

Q: What is the primary advantage of selecting the 715P10354JD3?

A: The 715P10354JD3 provides higher voltage ratings (400V DC and 200V AC) and tighter capacitance tolerance (±5%), offering greater design margin and precision. This is particularly beneficial in high-pulse and switching applications where voltage stress and capacitance accuracy are critical.

Q: Can the DPP2S1K-F be used in applications requiring the full temperature range to 105°C?

A: Yes. The DPP2S1K-F is rated to 105°C and is the appropriate selection for applications requiring this extended upper temperature limit. The 715P10354JD3 is limited to 85°C maximum.
