DH2CB1AA Equivalent & Substitute Parts

Part Overview

The DH2CB1AA is a snap action SPDT switch manufactured by ZF Electronics, designed for chassis mount applications with a 500mA DC current rating at 30V. This component features a round pin plunger actuator and solder lug termination, suitable for applications requiring momentary on-off switching functionality. The part is currently obsolete, making identification of functionally equivalent alternatives essential for design continuity and procurement planning.

Substiute Parts

DH2CB1AA

ZF ElectronicsIn Stock: 1431DH2CB1AA Datasheet

Current PartRFQ

DHGC-B1AA

ZF ElectronicsIn Stock: 936DHGC-B1AA Datasheet

MFR RecommendedRFQ

DHGC-C5AA

ZF ElectronicsIn Stock: 1211DHGC-C5AA Datasheet

MFR RecommendedRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitute parts for the DH2CB1AA are identified based on strict electrical and mechanical parameter matching. The following criteria determine substitution eligibility:

Critical Matching Parameters:

• Circuit configuration: SPDT
• Current rating: 500mA DC
• Voltage rating: 30V DC
• Actuator type: Round pin plunger
• Mounting type: Chassis mount
• Termination style: Solder lug
• Switch function: Momentary (On-Mom)

Both substitute parts (DHGC-B1AA and DHGC-C5AA) are manufactured by ZF Electronics and maintain identical electrical specifications to the original DH2CB1AA. These parts are currently in active production status, ensuring long-term availability and supply chain continuity.

Parameter Comparison

Engineering Selection Recommendations

The DH2CB1AA is obsolete and no longer available from the manufacturer. Both DHGC-B1AA and DHGC-C5AA are direct functional equivalents with active production status, ensuring procurement viability for new designs and replacement applications.

DHGC-B1AA is suitable for applications requiring immediate availability with confirmed inventory of 829 pieces.

DHGC-C5AA offers higher inventory levels (1,105 pieces) and includes documented ECCN and HTSUS classifications, supporting applications with regulatory or export documentation requirements.

Both substitutes maintain identical electrical performance specifications and are manufactured by the same original equipment manufacturer, ensuring compatibility with existing circuit designs and mechanical assemblies.
