D09S23B6GL4ALF Equivalent & Substitute Parts
Part Overview
The D09S23B6GL4ALF is a 9-position D-Sub receptacle connector manufactured by Amphenol ICC (FCI) in the Delta D series. This right-angle, through-hole solder connector features female sockets with tin-plated steel shell and gold-plated contacts. The part is currently obsolete, necessitating identification of equivalent and substitute components for ongoing system support and new designs.
Substiute Parts
Key Parameters
| Parameter | Value |
|---|---|
| Manufacturer Part Number | D09S23B6GL4ALF |
| Manufacturer | Amphenol ICC (FCI) |
| Connector Type | Receptacle, Female Sockets |
| Number of Positions | 9 |
| Shell Size | 1 (DE, E) |
| Mounting Type | Through Hole, Right Angle |
| Termination | Solder |
| Current Rating | 5A |
| Voltage Rating | 300V |
| Operating Temperature | -55°C ~ 125°C |
| Shell Material, Finish | Steel, Tin Plated |
| Contact Finish | Gold or Gold, GXT™ |
| Contact Material | Phosphor Bronze |
| Dielectric Material | Polyester |
| Flange Feature | Housing/Shell (M3) |
| Product Status | Obsolete |
Substitute Part Grouping Explanation
Substitution for the D09S23B6GL4ALF is determined by the following critical parameters:
Connector Configuration Requirements:
- Connector type: Receptacle, Female Sockets
- Number of positions: 9
- Shell size: 1 (DE, E)
- Mounting type: Through Hole, Right Angle
- Termination method: Solder
Electrical & Environmental Requirements:
- Current rating: 5A minimum
- Voltage rating: 300V minimum
- Operating temperature range: -55°C to 125°C
- Material flammability: UL94 V-0
Physical & Material Requirements:
- Shell material: Steel
- Contact material: Phosphor Bronze or equivalent copper alloy
- Dielectric material: Polyester, PBT, or equivalent thermoplastic
- Backset spacing: 0.409" (10.40mm)
Substitutes are grouped into two categories:
Category 1 - Direct Receptacle Equivalents: Parts maintaining receptacle configuration with compatible electrical and mechanical specifications.
Category 2 - Complementary Plug Connectors: HARTING-manufactured plug connectors (male pins) designed for mating with D-Sub receptacles of the same shell size and position count.
Parameter Comparison
| Parameter | D09S23B6GL4ALF | D09S13A4GL00LF | D09S13F6GL00LF | 09641247232 | 09651226803 | 09651227803 | 09651236803 | 09651637813 | 09651676813 | 09661236803 |
|---|---|---|---|---|---|---|---|---|---|---|
| Manufacturer | Amphenol ICC | Amphenol ICC | Amphenol ICC | HARTING | HARTING | HARTING | HARTING | HARTING | HARTING | HARTING |
| Connector Type | Receptacle | Receptacle | Receptacle | Plug | Plug | Plug | Plug | Plug | Plug | Plug |
| Number of Positions | 9 | 9 | 9 | 9 | 9 | 9 | 9 | 9 | 9 | 9 |
| Shell Size | 1 (DE, E) | 1 (DE, E) | 1 (DE, E) | 1 (DE, E) | 1 (DE, E) | 1 (DE, E) | 1 (DE, E) | 1 (DE, E) | 1 (DE, E) | 1 (DE, E) |
| Mounting Type | Through Hole, Right Angle | Through Hole, Right Angle | Through Hole, Right Angle | Through Hole, Right Angle | Through Hole, Right Angle | Through Hole, Right Angle | Through Hole, Right Angle | Through Hole, Right Angle | Through Hole, Right Angle | Through Hole, Right Angle |
| Termination | Solder | Solder | Solder | Solder | Solder | Solder | Solder | Solder | Solder | Solder |
| Current Rating (Amps) | 5A | 5A per Contact | 5A | 7.5A | 6.5A | 6.5A | 6.5A | 6.5A | 6.5A | 7.5A |
| Voltage Rating | 300V | 300V | 300V | 100V | — | — | — | — | — | — |
| Operating Temperature | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C | -20°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C |
| Shell Material, Finish | Steel, Tin Plated | Steel, Tin-Nickel Plated | Steel, Tin Plated | Steel | Steel | Steel | Steel | Steel | Steel | Steel |
| Contact Material | Phosphor Bronze | Phosphor Bronze | Brass | Copper Alloy | Copper Alloy | Copper Alloy | Copper Alloy | Copper Alloy | Copper Alloy | Copper Alloy |
| Dielectric Material | Polyester | Polybutylene Terephthalate (PBT) | Thermoplastic | Polycyclohexylenedimethylene Terephthalate (PCT) | Polybutylene Terephthalate (PBT), Polyester, Glass Filled | Polybutylene Terephthalate (PBT), Polyester, Glass Filled | Polybutylene Terephthalate (PBT), Polyester, Glass Filled | Polybutylene Terephthalate (PBT), Polyester, Glass Filled | Polycyclohexylenedimethylene Terephthalate (PCT), Glass Filled | Polybutylene Terephthalate (PBT), Polyester, Glass Filled |
| Backset Spacing | 0.409" (10.40mm) | 0.409" (10.40mm) | 0.409" (10.40mm) | — | 0.409" (10.40mm) | 0.409" (10.40mm) | 0.409" (10.40mm) | 0.409" (10.40mm) | 0.409" (10.40mm) | 0.409" (10.40mm) |
| Product Status | Obsolete | Active | Active | Active | Active | Active | Active | Active | Active | Active |
| RoHS Status | — | ROHS3 Compliant | RoHS Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
Engineering Selection Recommendations
For Direct Receptacle Replacement:
D09S13A4GL00LF and D09S13F6GL00LF are active-status receptacle alternatives maintaining the 9-position, shell size 1 (DE, E) configuration with identical mounting and termination specifications. Both support the full -55°C to 125°C operating range and meet UL94 V-0 flammability requirements. D09S13A4GL00LF carries ROHS3 compliance and REACH affected status. D09S13F6GL00LF provides RoHS compliance with brass contact material and thermoplastic dielectric. Both parts are currently in stock with higher inventory availability than the obsolete main part.
For Complementary Plug Connectors:
HARTING-manufactured plug connectors (09651226803, 09651227803, 09651236803, 09651637813, 09651676813, 09661236803) are designed for mating with D-Sub receptacles of matching shell size and position count. These parts maintain the 9-position, shell size 1 (DE, E) configuration with through-hole, right-angle solder termination. All HARTING plugs support the -55°C to 125°C operating temperature range and carry ROHS3 compliance. Current ratings range from 6.5A to 7.5A, exceeding the 5A specification of the main part. Selection among HARTING options depends on specific contact form requirements (stamped or machined), flange features, and dielectric material specifications.
Frequently Asked Questions (FAQ)
Q: Can D09S13A4GL00LF directly replace D09S23B6GL4ALF in existing designs?
A: Yes. Both are 9-position D-Sub receptacles with identical shell size (1/DE, E), mounting type (through-hole, right-angle), and termination method (solder). Operating temperature ranges, current ratings, and voltage ratings are compatible. The primary difference is shell finish (tin-nickel plated versus tin plated) and dielectric material (PBT versus polyester). D09S13A4GL00LF is active-status and currently in stock.
Q: What is the functional difference between receptacle and plug connectors in this product family?
A: Receptacles (female sockets) receive mating plugs (male pins). The D09S23B6GL4ALF is a receptacle. HARTING plug connectors listed are complementary components designed to mate with receptacles of the same shell size and position count. Receptacles and plugs are not interchangeable; both are required for complete connector pairs.
Q: Are HARTING plug connectors compatible with the D09S23B6GL4ALF receptacle?
A: Yes. All listed HARTING plugs maintain the 9-position, shell size 1 (DE, E) configuration required for mating with D-Sub receptacles of this specification. Mechanical and electrical compatibility is ensured through standardized D-Sub connector geometry and pin assignments.
Q: What compliance certifications apply to substitute parts?
A: D09S13A4GL00LF carries ROHS3 compliance and REACH affected status. D09S13F6GL00LF is RoHS compliant. All HARTING plug connectors are ROHS3 compliant and REACH unaffected. All parts meet UL94 V-0 flammability requirements.
Q: How do contact material differences affect part selection?
A: The main part uses phosphor bronze contacts. D09S13A4GL00LF maintains phosphor bronze; D09S13F6GL00LF uses brass. HARTING plugs use copper alloy contacts. All materials support the specified electrical performance and operating temperature range. Contact material selection may depend on specific application requirements for corrosion resistance or contact wear characteristics.
Q: What packaging options are available for substitute parts?
A: D09S13A4GL00LF is supplied in trays. D09S13F6GL00LF is supplied in trays. HARTING plug connectors are supplied in bulk packaging. Packaging selection depends on assembly process requirements and inventory management practices.
Q: Are there inventory considerations when selecting substitutes?
A: D09S13A4GL00LF has 2821 pieces in stock. D09S13F6GL00LF has 985 pieces in stock. HARTING plug connectors range from 788 to 1167 pieces in stock. The original D09S23B6GL4ALF has 1023 pieces available as new original stock despite obsolete status.
