CONSMA001-SMD SMA Connector Receptacle Equivalent & Substitute Parts

Part Overview

The CONSMA001-SMD is an SMA connector receptacle manufactured by TE Connectivity Linx, designed for RF coaxial applications requiring 50-ohm impedance. This surface-mount female socket connector operates across frequencies up to 18 GHz and is rated for operating temperatures from -65°C to 165°C. The part is Active in product status with RoHS compliance and unlimited moisture sensitivity level (MSL 1), making it suitable for industrial and commercial RF applications. Substitute parts are identified to provide alternative sourcing options while maintaining electrical and mechanical compatibility.

Substiute Parts

CONSMA001-SMD

TE Connectivity LinxIn Stock: 1136CONSMA001-SMD Datasheet

Current PartRFQ

CONSMA001-SMD-G

TE Connectivity LinxIn Stock: 4189CONSMA001-SMD-G Datasheet

DirectRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitute parts for the CONSMA001-SMD are identified based on strict equivalence across the following critical parameters:

• Connector Style: SMA
• Connector Type: Receptacle, Female Socket
• Impedance: 50 Ohms
• Mounting Type: Surface Mount
• Contact Termination: Solder
• Shield Termination: Solder
• Frequency - Max: 18 GHz
• Operating Temperature Range: -65°C to 165°C
• Mating Cycles: 500
• RoHS Status: RoHS Compliant
• Moisture Sensitivity Level: 1 (Unlimited)

The substitute part CONSMA001-SMD-G maintains all electrical and mechanical specifications identical to the main part. The primary difference is packaging format (Bulk versus Bag) and housing/body finish color (Gold versus Nickel), which do not affect functional compatibility or performance in RF applications.

Parameter Comparison

Engineering Selection Recommendations

Both CONSMA001-SMD and CONSMA001-SMD-G are Active products with identical RoHS compliance and REACH status. Selection between these parts should be based on packaging requirements and inventory availability rather than electrical performance, as all RF and mechanical specifications are equivalent.

The CONSMA001-SMD-G offers higher inventory availability (4150 pcs) compared to CONSMA001-SMD (1064 pcs) and is supplied in Bulk packaging. The CONSMA001-SMD is supplied in Bag packaging. The difference in housing finish (Gold versus Nickel) and body finish does not impact electrical performance or environmental compliance for RF applications operating within the specified frequency and temperature ranges.

Frequently Asked Questions (FAQ)

Q: Are CONSMA001-SMD and CONSMA001-SMD-G electrically interchangeable?

A: Yes. Both parts maintain identical electrical specifications including 50-ohm impedance, 18 GHz maximum frequency, solder termination, and operating temperature range of -65°C to 165°C. They are direct functional equivalents for RF circuit applications.

Q: What is the difference between the two part numbers?

A: The primary differences are packaging format (Bag versus Bulk) and housing/body finish color (Nickel versus Gold). These differences do not affect electrical performance or mechanical compatibility in RF applications.

Q: Can I substitute CONSMA001-SMD-G for CONSMA001-SMD in production?

A: Yes, provided your procurement and assembly processes accommodate the Bulk packaging format of CONSMA001-SMD-G. The electrical and mechanical specifications are fully equivalent.

Q: Are both parts RoHS compliant?

A: Yes. Both CONSMA001-SMD and CONSMA001-SMD-G are RoHS Compliant and REACH Unaffected, meeting regulatory requirements for industrial and commercial applications.

Q: What is the moisture sensitivity level for these connectors?

A: Both parts have Moisture Sensitivity Level 1 (Unlimited), indicating no special moisture control requirements during storage, handling, or assembly.

Q: What is the maximum mating cycle rating?

A: Both parts are rated for 500 mating cycles, defining the expected mechanical durability of the connector interface.
