BTH-050-01-F-D-A-TR Equivalent & Substitute Parts

Part Overview

The BTH-050-01-F-D-A-TR is a 100 position connector header manufactured by Samtec Inc., designed for surface mount applications with outer shroud contacts and gold plating. This rectangular connector operates at 0.020" (0.50mm) pitch with a 2-row configuration and board guide features. The part maintains Active product status with full RoHS3 compliance and unlimited moisture sensitivity rating (MSL 1). Substitute parts are identified when packaging formats differ or when equivalent parametric specifications are required for procurement flexibility and supply chain continuity.

Substiute Parts

BTH-050-01-F-D-A-TR

Samtec Inc.In Stock: 1035BTH-050-01-F-D-A-TR Datasheet

Current PartRFQ

BTH-050-01-F-D-A

Samtec Inc.In Stock: 1646BTH-050-01-F-D-A Datasheet

MFR RecommendedRFQ

BTH-050-01-F-D-A-K-TR

Samtec Inc.In Stock: 1325BTH-050-01-F-D-A-K-TR Datasheet

Parametric EquivalentRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitute parts for the BTH-050-01-F-D-A-TR are identified based on identical electrical and mechanical parameters while accommodating different packaging formats. The substitution logic is structured as follows:

Primary Substitution Criteria (Must Match):

• Manufacturer: Samtec Inc.
• Series: BTH
• Number of Positions: 100
• Pitch: 0.020" (0.50mm)
• Number of Rows: 2
• Connector Type: Header, Outer Shroud Contacts
• Mounting Type: Surface Mount
• Contact Finish: Gold
• Contact Finish Thickness: 3.00µin (0.076µm)
• Height Above Board: 0.168" (4.27mm)
• Mated Stacking Heights: 5mm
• Features: Board Guide
• RoHS Status: ROHS3 Compliant
• MSL Rating: 1 (Unlimited)

Variable Parameter (Allows Substitution):

• Packaging Format: Tape & Reel (TR) or Tray

The BTH-050-01-F-D-A-TR (Tape & Reel packaging) is substitutable with BTH-050-01-F-D-A (Tray packaging) and BTH-050-01-F-D-A-K-TR (Tape & Reel packaging with alternate configuration). All three parts share identical electrical and mechanical specifications; differences exist only in packaging and handling methods.

Parameter Comparison

Engineering Selection Recommendations

All three parts—BTH-050-01-F-D-A-TR, BTH-050-01-F-D-A, and BTH-050-01-F-D-A-K-TR—are functionally equivalent for circuit design and electrical performance. Selection between them is determined by procurement requirements and assembly process specifications:

BTH-050-01-F-D-A-TR (Tape & Reel): Suitable for high-volume automated assembly operations requiring reel-fed component handling. Tape & Reel packaging optimizes pick-and-place machine compatibility and reduces manual handling.

BTH-050-01-F-D-A (Tray): Suitable for lower-volume production runs or manual assembly processes. Tray packaging provides component accessibility for hand placement and inspection.

BTH-050-01-F-D-A-K-TR (Tape & Reel): Alternate Tape & Reel configuration offering equivalent performance to BTH-050-01-F-D-A-TR with identical electrical and mechanical specifications.

All parts maintain Active product status, full RoHS3 compliance, and unlimited moisture sensitivity rating (MSL 1), ensuring regulatory compliance and long-term availability.

Frequently Asked Questions (FAQ)

Q: Can BTH-050-01-F-D-A-TR be replaced with BTH-050-01-F-D-A?

A: Yes. Both parts are electrically and mechanically identical. The difference is packaging format: BTH-050-01-F-D-A-TR uses Tape & Reel packaging, while BTH-050-01-F-D-A uses Tray packaging. Selection depends on assembly process requirements and handling methods.

Q: What is the difference between Tape & Reel and Tray packaging?

A: Tape & Reel packaging winds components on a continuous tape suitable for automated pick-and-place machines. Tray packaging places components in individual compartments for manual or semi-automated handling. Both formats contain identical components with no electrical or mechanical differences.

Q: Are all three substitute parts suitable for the same PCB design?

A: Yes. All three parts—BTH-050-01-F-D-A-TR, BTH-050-01-F-D-A, and BTH-050-01-F-D-A-K-TR—share identical electrical and mechanical specifications. PCB footprints, mounting requirements, and electrical performance are equivalent across all three part numbers.

Q: Does packaging format affect component performance or reliability?

A: No. Packaging format affects only handling, storage, and assembly processes. Electrical performance, mechanical dimensions, contact finish, and reliability characteristics are identical regardless of packaging type.

Q: Are all substitute parts RoHS3 compliant?

A: Yes. BTH-050-01-F-D-A-TR, BTH-050-01-F-D-A, and BTH-050-01-F-D-A-K-TR are all ROHS3 compliant with identical regulatory status and certifications.

Q: What is the MSL rating for these connectors?

A: All three parts carry MSL 1 (Unlimited) rating, indicating no moisture sensitivity restrictions during storage or handling.
