BTE-040-02-F-D-A-TR Equivalent & Substitute Parts

Part Overview

The BTE-040-02-F-D-A-TR is an 80-position rectangular connector header manufactured by Samtec Inc., designed for surface mount applications with outer shroud contacts and gold plating. This connector is classified as Active product status and is fully ROHS3 compliant. Alternative packaging configurations of this connector are available to accommodate different procurement, inventory, and assembly requirements while maintaining identical electrical and mechanical specifications.

Substiute Parts

BTE-040-02-F-D-A-TR

Samtec Inc.In Stock: 858BTE-040-02-F-D-A-TR Datasheet

Current PartRFQ

BTE-040-02-F-D-A

Samtec Inc.In Stock: 1284BTE-040-02-F-D-A Datasheet

MFR RecommendedRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution between BTE-040-02-F-D-A-TR and BTE-040-02-F-D-A is determined by packaging configuration only. Both parts share identical electrical and mechanical specifications:

• Number of positions: 80
• Pitch: 0.031" (0.80mm)
• Number of rows: 2
• Connector type: Header, Outer Shroud Contacts
• Mounting type: Surface Mount
• Contact finish: Gold at 3.00µin thickness
• Mated stacking height: 8.03mm
• Height above board: 0.278" (7.06mm)
• Board guide feature: Present
• RoHS and MSL compliance: Identical

The only difference is packaging: BTE-040-02-F-D-A-TR is supplied in Tape & Reel format, while BTE-040-02-F-D-A is supplied in Tray format. This distinction affects procurement logistics and automated assembly compatibility but does not alter component functionality or performance.

Parameter Comparison

Engineering Selection Recommendations

Both BTE-040-02-F-D-A-TR and BTE-040-02-F-D-A are Active status products with full ROHS3 compliance and unlimited moisture sensitivity rating. Selection between these parts should be based on assembly and procurement requirements:

BTE-040-02-F-D-A-TR (Tape & Reel packaging) is suitable for high-volume automated pick-and-place assembly operations where tape-fed component handling is standard.

BTE-040-02-F-D-A (Tray packaging) is suitable for manual assembly, lower-volume production runs, or procurement scenarios where tray format is preferred.

Both parts maintain identical electrical performance, mechanical fit, and compliance certifications. The choice between them does not affect circuit design, PCB layout, or functional specifications.

Frequently Asked Questions (FAQ)

Q: Are BTE-040-02-F-D-A-TR and BTE-040-02-F-D-A electrically identical?

A: Yes. Both parts have identical electrical specifications including 80 positions, 0.031" pitch, gold contact finish at 3.00µin thickness, and all other electrical parameters.

Q: What is the only difference between these two parts?

A: The packaging format. BTE-040-02-F-D-A-TR is supplied in Tape & Reel format, while BTE-040-02-F-D-A is supplied in Tray format.

Q: Can I use BTE-040-02-F-D-A in place of BTE-040-02-F-D-A-TR in my assembly?

A: Yes, provided your assembly process can accommodate tray-packaged components. The connector itself is functionally identical.

Q: Can I use BTE-040-02-F-D-A-TR in place of BTE-040-02-F-D-A?

A: Yes, provided your assembly process can accommodate tape-and-reel packaged components. The connector itself is functionally identical.

Q: Do these parts have the same PCB footprint?

A: Yes. Both parts have identical mechanical dimensions, mounting type, and board guide features, resulting in the same PCB footprint.

Q: Are both parts ROHS3 compliant?

A: Yes. Both BTE-040-02-F-D-A-TR and BTE-040-02-F-D-A are ROHS3 compliant.

Q: What is the moisture sensitivity level for both parts?

A: Both parts have MSL 1 (Unlimited), indicating no moisture sensitivity restrictions.
