BK/1A3400-10 Equivalent & Substitute Parts

Part Overview

The BK/1A3400-10 is a fuse clip cartridge designed for 30 A applications with through-hole PCB mounting. This component is classified as obsolete, necessitating identification of equivalent substitute parts for ongoing design requirements and procurement needs. The part accommodates 10mm diameter cartridge fuses in a horizontal orientation with PC pin termination.

Substiute Parts

BK/1A3400-10

Eaton - Electronics DivisionIn Stock: 962BK/1A3400-10 Datasheet

Current PartRFQ

BK/1A3400-09-R

Eaton - Electronics DivisionIn Stock: 16164BK/1A3400-09-R Datasheet

SimilarRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitute parts for the BK/1A3400-10 are identified based on compatibility within the 1AXXXX series and alignment of critical mechanical and electrical parameters. The primary substitution criteria include:

Mechanical Compatibility:

• Fuse size: 0.394" Dia (10mm)
• Mounting type: Through Hole
• Orientation: Horizontal
• Termination style: PC Pin
• Fuseholder type: Clip
• Number of circuits: 1

Electrical Compatibility:

• Series designation: 1AXXXX
• Fuse type: Cartridge
• For use with 13/32" Dia Fuses

The substitute part BK/1A3400-09-R maintains full mechanical compatibility and operates within the same product family. The primary difference is the current rating specification, which is a design parameter that must be evaluated against application requirements.

Parameter Comparison

Engineering Selection Recommendations

The BK/1A3400-09-R is available as an active product from Eaton - Electronics Division, addressing the obsolescence status of the BK/1A3400-10. Both parts maintain identical mechanical specifications and operate within the same product series.

Product Status Consideration: The BK/1A3400-09-R carries active product status with significantly higher inventory availability (16,109 pieces), compared to the obsolete BK/1A3400-10 (948 pieces).

Compliance Status: The BK/1A3400-09-R meets ROHS3 compliance and is REACH unaffected, providing enhanced regulatory alignment for new designs and procurement cycles.

Current Rating Differential: The substitute part is rated for 20 A operation, compared to the 30 A rating of the main part. This parameter difference requires evaluation against circuit protection requirements and application current specifications.
