AXT410164 Equivalent & Substitute Parts

Part Overview

The AXT410164 is a 10-position connector header manufactured by Panasonic Electric Works, designed for surface mount applications with center strip contacts and gold plating. This part operates within the P4S series and features solder retention for reliable PCB assembly.

The AXT410164 carries an obsolete product status. Identifying equivalent and substitute parts is necessary to maintain design continuity, ensure component availability, and support ongoing production requirements for legacy systems or redesigned applications.

Substiute Parts

AXT410164

Panasonic Electric WorksIn Stock: 802AXT410164 Datasheet

Current PartRFQ

AXT410124

Panasonic Electric WorksIn Stock: 26005AXT410124 Datasheet

DirectRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution eligibility for the AXT410164 is determined by strict equivalence across the following critical parameters:

• Connector Type & Configuration: Header with center strip contacts
• Electrical Specifications: 10-position, 2-row arrangement
• Pitch Specification: 0.016" (0.40mm) center-to-center spacing
• Mounting Technology: Surface mount (SMD)
• Contact Material & Finish: Gold plating
• Mechanical Dimensions: Mated stacking heights (1.5mm, 2.5mm) and height above board (0.049" / 1.25mm)
• Functional Features: Solder retention capability
• Environmental Classification: MSL 1 (Unlimited moisture sensitivity level)

The AXT410124 meets all substitution criteria as a direct equivalent within the P4S series, maintaining identical electrical and mechanical specifications while offering active product status and improved availability.

Parameter Comparison

Engineering Selection Recommendations

The AXT410124 is the direct substitute for the AXT410164. Both parts share identical electrical and mechanical specifications within the P4S series. The primary distinction is product lifecycle status: AXT410164 is obsolete while AXT410124 maintains active production status.

The AXT410124 provides additional compliance documentation through RoHS certification, supporting modern regulatory requirements. Packaging availability for AXT410124 includes Cut Tape (CT) and Digi-Reel® options, accommodating both manual and automated assembly workflows.

For applications requiring the AXT410164, transition to AXT410124 presents no functional or dimensional constraints. PCB layout, mating interface specifications, and assembly processes remain unchanged.

Frequently Asked Questions (FAQ)

Q: Are AXT410164 and AXT410124 electrically interchangeable?

A: Yes. Both parts feature identical 10-position, 2-row configurations with 0.016" (0.40mm) pitch, gold-plated center strip contacts, and surface mount technology. Electrical performance and signal integrity characteristics are equivalent.

Q: What are the mechanical compatibility considerations?

A: Mechanical compatibility is complete. Both parts share identical mated stacking heights (1.5mm, 2.5mm), height above board (0.049" / 1.25mm), and solder retention features. No PCB redesign or connector interface modification is required.

Q: Why is AXT410164 listed as obsolete?

A: Product obsolescence reflects manufacturing lifecycle decisions by Panasonic Electric Works. The AXT410124 remains in active production and serves the same functional requirements.

Q: Does packaging format affect substitution eligibility?

A: No. Packaging format (Cut Tape, Digi-Reel, or bulk) does not affect electrical or mechanical compatibility. Selection depends on assembly process requirements and inventory management practices.

Q: Is RoHS compliance a substitution requirement?

A: RoHS compliance is not a substitution requirement for functional equivalence. However, AXT410124 provides RoHS Compliant certification, supporting applications with regulatory compliance mandates.

Q: What is the MSL rating significance?

A: Both parts carry MSL 1 (Unlimited) classification, indicating no moisture sensitivity constraints during storage, handling, or assembly. Standard component storage conditions apply.
